SPECIFICATIONS

TSB Revision

FUEL SUPPLY

13B-17

SPECIFICATIONS

FASTENER TIGHTENING SPECIFICATION

M1135003900258

SERVICE SPECIFICATION

M1135000300031

ITEM

SPECIFICATION

Fuel level sensor

2.5

± 0.4 N⋅m (22 ± 4 in-lb)

Fuel pump module

2.5

± 0.4 N⋅m (22 ± 4 in-lb)

Fuel tank drain plug

21

± 4 N⋅m (16 ± 2 ft-lb)

Fuel tank mounting nut

26

± 4 N⋅m (19 ± 3 ft-lb)

Fuel tank rollover valve

2.5

± 0.4 N⋅m (22 ± 4 in-lb)

Fuel tank leveling valve assembly

2.5

± 0.4 N⋅m (22 ± 4 in-lb)

ITEM

STANDARD VALUE

Fuel tank differential pressure sensor output voltage V

2.0

− 3.0

NOTES

12-1

GROUP 12

CONTENTS

GENERAL DESCRIPTION. . . . . . . . .

12-2

ON-VEHICLE SERVICE. . . . . . . . . . .

12-2

ENGINE OIL CHECK  . . . . . . . . . . . . . . . . .

12-2

ENGINE OIL REPLACEMENT . . . . . . . . . .

12-3

ENGINE OIL FILTER REPLACEMENT  . . .

12-3

OIL PRESSURE CHECK  . . . . . . . . . . . . . .

12-4

ENGINE OIL COOLER . . . . . . . . . . . .

12-5

REMOVAL AND INSTALLATION . . . . . . . .

12-5

SPECIFICATIONS  . . . . . . . . . . . . . . .

12-6

FASTENER TIGHTENING
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . .

12-6

LUBRICANT  . . . . . . . . . . . . . . . . . . . . . . . .

12-6

GENERAL DESCRIPTION

TSB Revision

ENGINE LUBRICATION

12-2

.

GENERAL DESCRIPTION

M1121000100283

The lubrication method is a fully force-fed, full-flow filtration type.

ENGINE OILS

WARNING

Prolonged and repeated contact with mineral oil will result in the removal of natural fats from
the skin, leading to dryness, irritation and dermatitis. In addition, used engine oil contains
potentially harmful contaminants which may cause skin cancer. Adequate means of skin pro-
tection and washing facilities must be provided.

.

Recommended Precautions
The most effective precaution is to adapt working
practices which prevent, as far as practical, the risk
of skin contact with mineral oils i.e. use enclosed
systems for handling used engine oil and decrease
components, where practical, before handling them.

.

Other precautions:

• Avoid prolonged and repeated contact with oil,

particularly used engine oil.

• Wear protective clothing, including impervious

gloves where practical.

• Avoid contaminating clothes, particularly under

wear, with oil.

• Do not put oily rags in pockets.

• Do not wear heavily soiled clothing and oil-

soaked foot-wear. Overalls must be cleaned reg-
ularly and kept separate from personal clothing.

• Where there is a risk of eye contact, eye protec-

tion should be worn i.e. chemical goggles or face
shields. In addition, an eye wash facility should
be provided.

• Obtain First Aid treatment immediately for open

cuts and wounds.

• Wash regularly with soap and water to ensure all

oil is removed, especially before meals (skin
cleansers and nail brushes will help). After clean-
ing, apply lotion, etc., containing lanolin to
replace natural skin oils is advised.

• Do not use gasoline, kerosene, diesel fuel, gas

oil, thinners or solvents for cleaning skin.

• Apply barrier creams before each work period to

help clean the skin after work.

• If skin disorders develop, obtain medical advice

immediately.

ON-VEHICLE SERVICE

ENGINE OIL CHECK

M1121000900267

1. Pull out the oil dipstick slowly and check that the oil level is

within the marks on the oil dipstick.

2. Check that the oil is not excessively dirty, that there is no

coolant or gasoline mixed in, and that it is sufficiently thick
and slippery.

ITEMS

SPECIFICATIONS

Oil pump type

Trochoid type

Drive method

Crankshaft

ACX00892AB

GOOD

MAXIMUM

MINIMUM
