DOOR

TSB Revision

BODY

42-51

DOOR LOCK KEY CYLINDER SWITCH CHECK

CENTRAL DOOR LOCK SWITCH CONTINUITY
CHECK

Remove the power window switch. (Refer to

P.42-39

).

<Driver's side>

<Passenger's side>

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

2

− 3

Less than 2 ohms

NEUTRAL (OFF)

1

− 2, 2 − 3

Open circuit

UNLOCK

1

− 2

Less than 2 ohms

AC210743

1

3

2

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

5

− 12

Less than 2 ohms

OFF

5

− 12, 10 − 12

Open circuit

UNLOCK

10

− 12

Less than 2 ohms

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

1

− 2

Less than 2 ohms

OFF

1

− 2, 2 − 3

Open circuit

UNLOCK

2

− 3

Less than 2 ohms

AC210745

12

7

1

8

2

10

9

3

11

13

5

4

14

6

DOOR LOCK

SWITCH

AB

AC210746

8

3

4 5

1

2

6 7

DOOR LOCK

SWITCH

AB

DOOR

TSB Revision

BODY

42-52

WINDOW GLASS RUNCHANNEL AND DOOR OPENING WEATHERSTRIP

REMOVAL AND INSTALLATION

M1423003100319

AC306732

AC306175

AC306365

AC206032

SEALANT: 3M™ AAD PART NO. 8633
OR EQUIVALENT

AB

NOTE
        : THE CONVEX POSITION OF THE DOOR

SECTION A – A

FRONT
DOOR

<FRONT DOOR>

1

2

4

3

3

5

6

7

7

A

A

AC306372

AC306373

AC306725

AC306374

: SECTIONAL VIEW OF
  CLIP POSITION

: SECTIONAL VIEW OF
  CLIP POSITION

AB

CLIP POSITION

LH DOOR CLIPS (PINK),
RH DOOR CLIPS
(TURQUOISE)

6

REMOVAL

>>D<<

1. DOOR WINDOW GLASS

RUNCHANNEL

DOOR

TSB Revision

BODY

42-53

WATERPROOF FILM AND DOOR
PANEL CORE REMOVAL STEPS

•

DOOR TRIM ASSEMBLY (REFER
TO GROUP 52A, DOOR TRIM

P.52A-13

).

•

DOOR INSIDE HANDLE (REFER TO

P.42-46

).

2. DOOR ARMREST BRACKET

>>A<<

3. WATERPROOF FILM
4. DOOR PANEL CORE

DOOR OPENING INNER
WEATHERSTRIP REMOVAL
STEPS

•

FRONT SCUFF PLATE (REFER TO
GROUP 52A, TRIMS

P.52A-10

).

>>C<<

5. DOOR OPENING INNER

WEATHERSTRIP (BODY SIDE)
DOOR OPENING OUTER
WEATHERSTRIP REMOVAL
STEPS

•

DOOR CHECK MOUNTING BOLT
(BODY SIDE) (REFER TO

P.42-37

).

>>B<<

6. DOOR OPENING OUTER

WEATHERSTRIP
DOOR BELTLINE MOLDING
REMOVAL STEPS

•

DOOR TRIM ASSEMBLY (REFER
TO GROUP 52A, DOOR TRIM

P.52A-13

).

•

REMOTE CONTROLLED MIRROR
ASSEMBLY (REFER TO GROUP 51,
DOOR MIRROR

P.51-42

).

7. DOOR BELTLINE MOLDING

DOOR

TSB Revision

BODY

42-54

DOUBLE-SIDED TAPE POSITION

AC306726

AC306375

AC306376

AB

3 (0.12)

UNITS: mm (in)

CLIP HOLE

<FRONT DOOR>

ADHESIVE TAPE: DOUBLE-SIDED TAPE [ 7 mm (0.28 in) WIDTH, 85 mm (3.35 in) LENGTH AND 0.8 mm (0.031 in)
THICKNESS ]

DOOR OPENING OUTER
WEATHERSTRIP
