TECHNICAL FEATURES

GENERAL

00-3

DESIGN FEATURES

Front view

•

Bold, new Mitsubishi face, with center pillar grill
and larger, chrome triple diamond logo.

•

Bigger, richer looking headlamps.

•

Graphics reinforce the feeling of width and sub-
stance.

•

Front bumper is integrated into whole form.

Side view

•

Sleek, clean surface eliminates unnecessary
lines.  Part lines are visually aligned with design
elements.

•

Window design has a fast C-pillar graphic provid-
ing coupe like feel.

•

Wheel flares have "stretched membrane" feel to
add tension and wheel emphasis.

•

Larger wheels emphasize the driver oriented
nature of the vehicle.

Rear view

•

Simple clean surfacing provides rich surface for a
luxury image.

•

Rear bumper offset is blended at corners for inte-
grated look.

•

Width enhancing, ground hugging bumper
effects.

INTERIOR

M2000018000237

.

DESIGN FEATURES

Instrument panel

•

Simple forms combined with fine detail  and satin
grain provides precision, high-quality feel.

•

Three ring, meter bezel with ice-blue lighting and
titanium accents provide sporty feel.

•

Instrument panel arcs away from occupants at
edges for easier entry and exit.

•

Parts and details are organized in logical manner
to eliminate unnecessary lines.

Center panel

•

Modular center panel  carries home-audio brand
theme.  It is functionally positioned for ease of
use.

•

Center display is positioned up high and forward
for optimum viewing and useability.

Floor console

•

Features large, functional cupholders.

•

Includes large storage bin underneath hinging
arm rest.  Also includes tissue dispenser and pen
holder.

•

Many storage bins are provided for coins,
glasses and other items.

•

Titanium shift bezel and smaller shift knob
accents enhance sporty nature.

Door

•

Assist grip.

•

Titanium door handles and insert decorative
pieces lend a luxury touch.

•

Large, functional map pockets can hold a Tho-
mas guide.

Seat

•

Wide shoulder support and bolsters provide driv-
ing comfort.

AC306780

TECHNICAL FEATURES

GENERAL

00-4

SPACIOUS CABIN

M2000000400014

NOTE: Refer to

P.00-13

 for the body dimensions.

ENGINE

M2000020000159

2.4-L 16-valve SOHC engine

The 4G69 2.4-liter engine is available with MFI. The
engine employs Mitsubishi Innovative Valve timing
and lift Electronic Control (MIVEC).

3.8-L 24-valve SOHC engine

The 6G75 3.8-liter engine is available with MFI.

TRANSAXLE

M2000021000152

AUTOMATIC TRANSAXLE

.

<2.4L ENGINE>
Incorporates the INVECS-II 4-speed automatic
transaxle.

.

<3.8L ENGINE>
Incorporates the INVECS-II sports mode 4-speed
automatic transaxle (some as ECLIPSE).

AC308162AB

1

2

7

8

3, 4

5, 6

NO. ITEM

DIMENSION

NO. ITEM

DIMENSION

1

Head room mm
(in)

Front 1,011 (39.8)

5

Hip room mm (in)

Front 1,381 (54.4)

2

Rear

941 (37.0)

6

Rear

1,343 (52.9)

3

Shoulder room
mm (in)

Front 1,455 (57.3)

7

Leg room mm (in)

Front 1,083 (42.6)

4

Rear

1,450 (57.1)

8

Rear

940 (37.0)

TECHNICAL FEATURES

GENERAL

00-5

SUSPENSION

M2000023000158

A MacPherson strut suspension system is used, the
leading type for passenger vehicles. This makes it as
light as other passenger vehicles in its class, and the
coil springs ensure greater handling stability. The
crossmember, with a structure supporting elasticity,
also improves noise control.

Low-mount multilink independent suspension offers
handling stability and riding comfort. Crossmembers
with an elastic structure are used to reduce road
noise, making the vehicle quieter.

AC306555

SHOCK
ABSORBER

COIL SPRING

STABILIZER BAR

TOE CONTROL ARM
ASSEMBLY

LOWER ARM ASSEMBLY

UPPER ARM ASSEMBLY

TRAILING ARM
ASSEMBLY

REAR SUSPENSION
CROSSMEMBER

AB

STABILIZER BAR

COIL SPRING

STABILIZER LINK

STRUT ASSEMBLY

FRONT AXLE No.1
CROSSMEMBER

LOWER ARM ASSEMBLY

CENTER MEMBER

TECHNICAL FEATURES

GENERAL

00-6

ACTIVE SAFETY

M2000031000142

BRAKING SYSTEM

2.4L engine models come with 15-inch ventilated
disc front brakes, 3.8L engine models come with
16-inch ventilated disc front brakes, and 16-inch
solid discs rear brakes.
A 4-sensor, 4-channel Anti-lock Braking System
(ABS) with Electronic Brake-force Distribution (EBD)
is available.

TRACTION CONTROL SYSTEM (TCL)

The traction control system (TCL) controls engine
output to prevent the wheelspin of  the drive wheels
(front wheels) for improved standstill acceleration
and stability.
In general, drivers adjust pedal depression amounts
to control engine output. When an action such an
excessive pedal depression amount causes the spin
of the drive wheels (front wheels), TCL controls the
engine output instead of the driver to reduce the bur-
den on him.

AC305395

BRAKE BOOSTER

HYDRAULIC UNIT
(INTEGRATED WITH
THE ABS-ECU)

MASTER CYLINDER

FRONT DISC BRAKE

REAR DISC BRAKE

AB
