MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-445 STEP 2. Check harness connector D-18 at the fuel tank Q: Is the harness connector in good condition? YES : Go to Step 3. Connector Inspection . Then go to Step 12. STEP 3. Check the fuel tank temperature sensor. (1) Disconnect the fuel tank temperature sensor connector D-18. (2) Measure the resistance between terminal No. 1 and No. 3 of the fuel tank temperature sensor. Standard value: 0.5 − 12.0 kΩ Q: Is the measured resistance between 0.5 and 12.0 k Ω? YES : Go to Step 4. Step 12. 1 2 3 4 5 AK303088 HARNESS SERVICE AB FUEL PUMP MODULE CONNECTOR: D-18 D-18 (GR) 1 2 3 4 5 AK303088 HARNESS SERVICE AB FUEL PUMP MODULE CONNECTOR: D-18 D-18 (GR) 1 2 3 4 5 AK203165 FUEL TANK TEMPERATURE AB |
