LOCATION OF SYNTHETIC-RESIN PARTS

TSB Revision

SYNTHETIC-RESIN PARTS

5-3

NO PART NAME

NAME OF RESIN

ABBREVIATION

HEAT-WITHST
AND TEMP
[

°

C (

°

F)]

1

Radiator grille (Except for GTS)
(Plating)

Acrylonitrile butadiene styrene

ABS

80 (176)

2

Door mirror (Body color)

3

Radiator grille (GTS)

Acrylonitrile styrene acrylate

ASA

80 (176)

4

Radiator grille (Except for GTS)
(Material color)

5

Door mirror (Black)

6

Headlight

Polycarbonate

PC

120 (248)

7

Rear air spoiler

Polycarbonate plus Acrylonitrile
butadiene stylene

PC+ABS

80 (176)

8

Front mudguard

9

Instrument panel

10 Front bumper core

Polycarbonate plus
Polybutylene terephthalate

PC+PBT

80 (176)

11 Rear bumper core

12 Rear door outside handle

13 Front door outside handle

14 Rear bumper center bracket

Polyacetal

POM

120 (248)

15 Rear bumper side bracket

16 Inside rear view mirror

Polypropylene

PP [HCPP]

90

−

 100 (194

−



212)

17 Rear end outer plate

18 Air guide side panel

19 Front bumper fog light hole

cover

20 Air guide center panel

21 Center pillar lower trim

22 Rear splash shield

23 Rear scuff plate

24 Front scuff plate

25 Cowl side trim

26 Front splash shield

27 Front bumper face

Talc filled rubber modified
polypropylene

PP+E/P-TD

80 (176)

28 Rear bumper face

29 Rear door side protector

molding

Talc filled rubber modified
polypropylene (20%)

PP+E/P-TD20

110 (230)

30 Front door side protector

molding

LOCATION OF SYNTHETIC-RESIN PARTS

TSB Revision

SYNTHETIC-RESIN PARTS

5-4

NOTE:

.

•

If the material symbols designated by the ISO differ from
the old symbols, both are given, with the old symboling
enclosed in brackets.
ISO: International Standardization Organization.

•

A slash (/) in the material symbol indicates that two different
materials make two-layer construction. A plus sign (+) indi-
cates that the two different materials mix each other.

•

The indicated heat-withstand temperature for parts which
are composed of two or more types of material is the value
for the material with the lowest heat-withstand temperature.

•

The material symbols for synthetic-resin parts are
embossed on the parts in hidden places.

31 Instrument panel side cover

Talc filled polypropylene (10%)

PP-TD10

110

−

 120 (230

−

 248)

32 Base floor console

33 Front bumper under side cover Talc filled polypropylene (15%)

PP-TD15

110

−

 120 (230

−

 248)

34 Front deck garnish

Talc filled polypropylene (20%)

PP-TD20

120

−

 130 (248

−

 266)

35 Front delta garnish

36 License plate garnish

37 Front door lower trim

38 Rear door lower trim

39 Rear speaker garnish

40 Rear end trim cover

41 Front pillar trim

Talc filled polypropylene (25%)

PP-TD25

100 (212)

42 Center pillar upper trim

43 Rear pillar trim

44 Upper panel

45 Roof drip molding

Polyvinyl chloride

PVC

80 (176)

46 Front door center trim

47 Front door upper trim

48 Rear door center trim

49 Rear door upper trim

50 Fender hole cover

Thermoplastic elastomer

TPE

80

−

 100 (176

−



212)

NO PART NAME

NAME OF RESIN

ABBREVIATION

HEAT-WITHST
AND TEMP
[

°

C (

°

F)]

6-1

GROUP 6

BODY COLOR

CONTENTS

BODY COLOR CODE  . . . . . . . . . . . .

6-2

BODY COLOR CHARTS . . . . . . . . . .

6-2

BODY COLORING . . . . . . . . . . . . . . .

6-3

FRONT END, DOOR SASH,
WHEELHOUSE . . . . . . . . . . . . . . . . . . . . . .

6-3

BODY COLOR CODE

TSB Revision

BODY COLOR

6-2

BODY COLOR CODE

M4060001000174

1.

The body color code is imprinted on the vehicle
information code plate, which is mounted on the
front deck.

2.

The information is contained in the body color
charts.

BODY COLOR CHARTS

M4060002000199

Check the vehicle’s body color code, and then use
this body color chart to determine the refinishing
paint supplier from which the color can be pur-
chased.

NOTE: Inner Panel-Color refers to the coat color of the engine compartment, cabin and floor.

AB301315

AB

AB201902 AB

BODY COLOR CODE

COLOR

COLOR CODE

COLOR NUMBER

COMPOSITION OF FILM

SILVER

A68

AC11268

Metallic

DARK GRAY

H32

CUH10032

Pearl

BLUE

T34

CUT10034

Pearl

BEIGE

S13

CUS10013

Pearl

GRYISH GREEN

G69

CUG10069

Pearl

BLACK

X13

AC10813

Solid

WHITE

W69

AC11269

Pearl

DEEP RED

P06

CUP10006

Pearl
