Mitsubishi Galant (2004+). Manual - part 14

HEADLIGHT SUPPORT

TSB Revision

WELDED PANEL REPLACEMENT

3-3

HEADLIGHT SUPPORT

M4030003000177

AB301051

AB

SYMBOL

OPERATION DESCRIPTION

Spot welding

MIG plug welding      : indicates two panels to be welded
                                  : indicates three panels to be welded

MIG spot welding

MIG arc welding (continuous)

Braze welding

Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded joints.)

(                                                               )

AB301050

REPAIR WELDS

A

AB

A

FENDER SHIELD

TSB Revision

WELDED PANEL REPLACEMENT

3-4

FENDER SHIELD

M4030004000169

NOTE: Refer to the Headlight Support Section on

P.3-3

 for the welding point with headlight support.

AB301052

SYMBOL

OPERATION DESCRIPTION

Spot welding

MIG plug welding      : indicates two panels to be welded
                                  : indicates three panels to be welded

MIG spot welding

MIG arc welding (continuous)

Braze welding

Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded joints.)

(                                                               )

AB

AB301094

A

AB

A

H

F

FENDER SHIELD

TSB Revision

WELDED PANEL REPLACEMENT

3-5

AB301095

B

C

D

AB

(WITH THE UPPER FRAME REMOVED)

B

E

D

G

I

J

K

C

UPPER FRAME

FENDER SHIELD

TSB Revision

WELDED PANEL REPLACEMENT

3-6

AB301088AB

E

F

G

H

I

J

LEFT SIDE ONLY

(LEFT SIDE ONLY)

M
