BODY DIMENSIONS AND MEASUREMENT METHODS

TSB Revision

BODY DIMENSIONS

2-3

6. When measuring the suspension mounting arm, or link

mounting position, use the suspension mounting bolt, etc.
(Type B only)

7. The body center points are shown for the purpose of

checking the position of the left and right symmetry location.

AB100782AB

BOLT

MEASIREMENT POINT

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-4

TYPE A (PROJECTED DIMENSIONS)

UNDER BODY

M4020005000291

NOTE: The * mark indicates the mounting position for the frame centering gauge.

AB301135

AB

1

2

3

4

7

5

6

9

  670

(26.3)

  960

(37.7)

  393

(15.4)

  808

(31.8)

1,185

(46.5)

  940

(36.9)

  940

(36.9)

8

1,340

(52.6)

  900

(35.3)

  860

(33.8)

 207

(8.1)

  884

(34.7)

  681

(26.7)

mm (in)

10

1,010

(39.7)

1,005

(39.5)

  595

(23.4)

  798

(31.4)

  797

(31.3)

  594

(23.3)

AB301136

AB

1

2

3

4

7

1,443

(56.7)

  893

(35.1)

1,274

(50.0)

1,018

(40.0)

6

9

8

5

1,346

(53.0)

1,392

(54.7)

1,208

(47.4)

1,391

(54.6)

1,292

(50.8)

1,247

(49.0)

  904

(35.5)

1,097

(43.1)

1,236

(48.5)

1,110

(43.6)

10

No. STANDARD MEASUREMENT POINT

HOLE SHAPE SIZE mm (in)

1*

Center of front bumper mounting hole

Round

8 (0.3)

2*

Center of front sidemember inner positioning hole

Round

25 (1.0)

3*

Center of front sidemember lower brace positioning hole

Round

25 (1.0)

4*

Center of front sidemember rear (B) positioning hole

Round

25 (1.0)

5*

Center of front floor sidemember positioning hole

Round

17.5 (0.69)

6*

Center of rear seat crossmember rear side water draining hole

Oblong

21.6

×

37.5

(0.85

×

1.48)

7*

Center of rear floor sidemember water draining hole

Round

16 (0.6)

8*

Center of rear floor sidemember water draining hole

Round

16 (0.6)

9

Center of rear floor sidemember extension water draining hole

Round

15 (0.6)

10

Center of heat protector mounting hole

Round

6.6 (0.26)

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-5

AB301140

AB

1

2

3

4

7

5

6

8

9

mm (in)

 181

(7.1)

 100

(3.9)

 100

(3.9)

 100

(3.9)

 158

(6.2)

  364

(14.3)

  392

(15.4)

  393

(15.4)

  392

(15.4)

1,465

(57.5)

1,841

(72.3)

1,100

(43.2)

1,251

(49.1)

1,045

(41.0)

  292

(11.5)

  964

(37.9)

  400

(15.7)

10

AB300714AB

1

AB300715AB

2

AB300716AB

3

4

3, 4

AB300717AB

5

AB300718

AB

6

AB300719AB

7

8

7, 8

AB300725AB

9

AB300726AB

10

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-6

SUSPENSION INSTALLATION DIMENSIONS

M4020013000285

AB300664

AB

11

13

14

15

16

17

18

19

12

20

1,171

(46.0)

  928

(36.4)

  273

(10.7)

  928

(36.4)

  970

(38.1)

 129

(5.1)

  401

(15.7)

1,310

(51.4)

  784

(30.8)

1,200

(47.1)

1,245

(48.9)

  660

(25.9)

1,002

(39.3)

  473

(18.6)

  922

(36.2)

  305

(12.0)

  773

(30.3)

mm (in)

1,096

(43.0)

AB300665AB

13

14

15

17

19

20

18

16

  957

(37.6)

  967

(38.0)

1,030

(40.4)

1,305

(51.3)

1,138

(44.7)

1,071

(42.1)

 122

(4.8)

 124

(4.9)

No. STANDARD MEASUREMENT POINT

HOLE SHAPE SIZE mm (in)

4

Center of front sidemember rear (B) positioning hole

Round

25 (1.0)

5

Center of front floor sidemember positioning hole

Round

25 (1.0)

11

Center of front shock absorber mounting hole

Round

112 (4.4)

12

Center of rear shock absorber mounting hole

Round

85 (3.3)

13

Tip of front axel No.1 crossmember mounting bolt

−

−

14

Center of front suspension crossmember mounting hole

Round

17 (0.7)

15

Center of front axel crossmember stay mounting hole

Round

17 (0.7)

16

Center of trailing arm mounting hole

Round

14 (0.5)

17

Center of trailing arm mounting hole

Round

14 (0.5)

18

Center of trailing arm mounting hole

Round

14 (0.5)

19

Center of rear suspension crossmember mounting hole

Round

15 (0.6)

20

Center of rear suspension crossmember mounting hole

Round

15 (0.6)
