SPECIFICATIONS
TSB Revision
AUTOMATIC TRANSAXLE
23A-406
SERVICE SPECIFICATIONS
M1231000300359
LUBRICANT
M1231000400419
Transaxle assembly upper part coupling bolt <F4A5A>
73
± 10 N⋅m (54 ± 7 ft-lb)
Transaxle assembly lower part coupling bolt <F4A4B>
48
± 6 N⋅m (36 ± 4 ft-lb)
Transaxle assembly lower part coupling bolt <F4A5A>
88
± 10 N⋅m (65 ± 7 ft-lb)
Transaxle mount bracket attaching nut
58
± 7 N⋅m (43 ± 5 ft-lb)
Transaxle mount stopper attaching nut
83
± 12 N⋅m (61 ± 9 ft-lb)
Transmission fluid drain plug
32
± 2 N⋅m (23 ± 2 ft-lb)
Transmission Fluid Cooler
ATF warmer (transmission fluid cooler) bracket attaching bolt
23
± 3 N⋅m (17 ± 2 ft-lb)
ATF warmer (transmission fluid cooler) attaching bolt
23
± 3 N⋅m (17 ± 2 ft-lb)
ITEM
SPECIFICATION
ITEM
STANDARD VALUE
Transmission fluid temperature sensor k
Ω
at 0
°C (32°F)
16.7
− 20.5
at 20
°C (68°F)
7.3
− 8.9
at 40
°C (104°F)
3.4
− 4.2
at 60
°C (140°F)
1.9
− 2.2
at 80
°C (176°F)
1.0
− 1.2
at 100
°C (212°F)
0.57
− 0.69
Line pressure MPa (psi)
0.98
− 1.05 (142 − 152)
Resistance of torque converter clutch control solenoid valve coil [at 20
°C
(68
°F)] Ω
2.7
− 3.4
Resistance of low-reverse solenoid valve coil [at 20
°C (68°F)] Ω
2.7
− 3.4
Resistance of overdrive solenoid valve coil [at 20
°C (68°F)] Ω
2.7
− 3.4
Resistance of second solenoid valve coil [at 20
°C (68°F)] Ω
2.7
− 3.4
Resistance of underdrive solenoid valve coil [at 20
°C (68°F)] Ω
2.7
− 3.4
Stall speed r/min
F4A4B
2,500
− 3,000
F4A5A
2,200
− 2,700
ITEM
SPECIFIED LUBRICANT
QUANTITY
Transmission fluid dm
3
(qt)
F4A4B
DIAMOND ATF SP III
7.7 (8.1)
F4A5A
8.4 (8.9)
