DOOR TSB Revision BODY 42-48 REMOVAL SERVICE POINT . <<A>> DOOR LOCK KEY CYLINDER ASSEMBLY 1. Create clearance between the door panel and the door outside handle to access the pin. 2. Open the pin and remove the door lock key cylinder assembly. INSTALLATION SERVICE POINTS . >>A<< DOOR CHECK INSTALLATION Install the door check so that the identification mark faces . >>B<< LOWER SASH INSTALLATION Securely insert the lower sash into the window rear sash. AC306507 AB PIN DOOR OUTSIDE DOOR LOCK KEY ITEM IDENTIFICATION Front Door Left door P4FL Right door P4FR Rear Door Left door P4RL Right door P4RR AC204902 A VIEW A IDENTIFICATION MARK AB |
