Mitsubishi Galant 9G. Manual - part 207

REAR WINDOW DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-190

WINDSHIELD WIPER AND WASHER (CONTINUED)

<WITH MULTI-CENTER DISPLAY (MIDDLE) >

A/C-ECU

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

MULTI-CENTER DISPLAY UNIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

REMOTE CONTROLLED MIRROR

TSB Revision

CIRCUIT DIAGRAMS

90-191

REMOTE CONTROLLED MIRROR

M1901006500993

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI-CENTER DISPLAY
·WINDSHIELD WIPER
 AND WASHER

IGNITION
SWITCH (ACC)

JUNCTION
BLOCK

REMOTE
CONTROLLED
MIRROR SWITCH

REMOTE
CONTROLLED
MIRROR (LH)

REMOTE
CONTROLLED
MIRROR (RH)

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-192

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO

AMPLIFIER>

M1901015601388

IGNITION
SWITCH (ACC)

BATTERY

FRONT-ECU

TAILLIGHT
RELAY

WINDSHIELD
WIPER AND
WASHER

RADIO AND CD PLAYER

JOINT
CONNECTOR (1)

JUNCTION
BLOCK

RELAY
BOX

RELAY
BOX

·FOG LIGHT
·HEADLIGHT
·TAILLIGHT,
 POSITION LIGHT,
 FRONT SIDE
 MARKER LIGHT
 AND LICENSE
 PLATE LIGHT
·TURN-SIGNAL
 LIGHT AND
 HAZARD
 WARNING LIGHT
·WINDSHIELD
 WIPER AND
 WASHER

·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·WINDSHIELD WIPER
 AND WASHER

·AUTO-CRUISE
 CONTROL SYSTEM
·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·BRAKE WARNING
 LIGHT, OIL PRESSURE
 WARNING LIGHT,
 FUEL WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CHARGING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOOR AJAR WARNING
 TONE ALARM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM
 (ABS)
·ENGINE IMMOBILIZER
 SYSTEM
·FOG LIGHT
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEADLIGHT
·INVECS-II 4A/T
·LIGHTING MONITOR
 TONE ALARM
·MANUAL AIR
 CONDITIONING SYSTEM
·METER AND GAUGE
·MFI SYSTEM
·MULTI-CENTER DISPLAY
·SEAT BELT WARNING
 TONE ALARM
·SUPPLEMENTAL
 RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION
 LIGHT, FRONT SIDE
 MARKER LIGHT AND
 LICENSE PLATE LIGHT
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING
 LIGHT
·VANITY MIRROR LIGHT
·WINDSHIELD WIPER
 AND WASHER

NOTE

*

·ACCESSORY SOCKET
·AUTOMATIC AIR
 CONDITIONING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI-CENTER DISPLAY

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-193

TWEETER (LH)

FRONT DOOR
SPEAKER (LH)

FRONT DOOR
SPEAKER (RH)

TWEETER (RH)

RADIO AND CD PLAYER

RHEOSTAT

REAR
SPEAKER (LH)

REAR
SPEAKER (RH)

·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGHT
·HEATED SEAT
·INVECS-II 4A/T
·MANUAL AIR
 CONDITIONING
 SYSTEM
·METER AND GAUGE
·MULTI-CENTER DISPLAY
·REAR WINDOW
 DEFOGGER AND DOOR
 MIRROR HEATER
·RHEOSTAT
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING
 LIGHT

NOTE

:

·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·REMOTE CONTROLLED
 MIRROR

NOTE

:
