Mitsubishi Galant 9G. Manual - part 206

WINDSHIELD WIPER AND WASHER

TSB Revision

CIRCUIT DIAGRAMS

90-186

WINDSHIELD WIPER AND WASHER (CONTINUED)

IGNITION
SWITCH (IG1)

JUNCTION
BLOCK

JOINT
CONNECTOR (1)

INVECS-II 4A/T

OUTPUT SHAFT
SPEED SENSOR

POWERTRAIN
CONTROL
MODULE

NOTE

: WITHOUT ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
  AND ANTI-LOCK BRAKING SYSTEM (ABS)
: WITH ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
  AND ANTI-LOCK BRAKING SYSTEM (ABS)

: 2.4L ENGINE
: 3.8L ENGINE

WINDSHIELD WIPER AND WASHER

TSB Revision

CIRCUIT DIAGRAMS

90-187

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

ETACS-ECU

ABS-ECU OR
ABS/TCL-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

REAR WINDOW DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-188

REAR WINDOW DEFOGGER AND DOOR MIRROR HEATER

M1901019400082

TAILLIGHT
RELAY

FRONT-ECU

IGNITION
SWITCH (IG2)

FUSIBLE
LINK

1

RELAY
BOX

JOINT
CONNECTOR
(1)

JUNCTION
BLOCK

RHEOSTAT

JUNCTION
BLOCK

A/C-ECU

NOTE

: MANUAL AIR CONDITIONING
  SYSTEM <LOW>
: MANUAL AIR CONDITIONING
  SYSTEM <MIDDLE> OR
  AUTOMATIC AIR CONDITIONING
  SYSTEM

·AUDIO SYSTEM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGH
·HEATED SEAT
·INVECS-II 4A/T
·METER AND GAUGE
·MULTI-CENTER
 DISPLAY
·RHEOSTAT
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)
·TURN-SIGNAL
 LIGHT AND
 HAZARD WARNING
 LIGHT

REAR
WINDOW
DEFOGGER
RELAY

REAR
WINDOW
DEFOGGER

CAPACITOR

REAR WINDOW DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-189

<WITH DOOR MIRROR HEATER>

JUNCTION
BLOCK

(FUSE     )

19

REMOTE
CONTROLLED
MIRROR (LH)

REMOTE
CONTROLLED
MIRROR (RH)

MIRROR
HEATER

MIRROR
HEATER
