ANTI-LOCK BRAKING SYSTEM (ABS) DIAGNOSIS TSB Revision ANTI-LOCK BRAKING SYSTEM (ABS) 35B-8 HOW TO DIAGNOSE THE CAN BUS LINE Required Special Tools: • MB991958: Scan Tool (MUT-III Sub Assembly) • MB991824: Vehicle Communication Interface (V.C.I.) • MB991827: MUT-III USB Cable • MB991910: MUT-III Main Harness A CAUTION To prevent damage to scan tool MB991958, always turn the matches the vehicle whose CAN bus lines will be • If they match, go to step 8. • If not, go to step 5. 5. Select "view vehicle information" button. that it matches the vehicle which is being diagnosed. • If they match, go to step 8. • If not, go to step 5. 7. Press the "OK" button. the check) and then select "OK". AC305412 AB MB991910 DATA LINK CONNECTOR MB991824 MB991827 |
