RADIO WITH CD PLAYER TSB Revision CHASSIS ELECTRICAL 54A-176 STEP 10. Check the wiring harness between front door NOTE: Also check intermediate connector C-26 for loose, cor- . Q: Is the wiring harness between front door speaker (LH) connector E-10 (terminals 1 and 2) and audio amplifier (LH) should sound. NO : Repair the wiring harness. The front door speaker (LH) should sound. STEP 11. Check the front door speaker (RH). . (2) Check that the front door speaker (RH) generates noise when a five-volt voltage is applied on the front door speaker Q: Is the front door speaker (RH) generating noise? YES : Go to Step 12. speaker (RH) should sound. AC305233CC CONNECTOR: C-113 HARNESS SIDE AC305262 CONNECTOR: E-10 AP AC305231 CONNECTOR: C-26 AK ACX01868AB 5V |
