DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-140 STEP 24. Check the CAN_H line (communication line only) CAUTION A digital multimeter should be used. For details refer to . CAUTION The test wiring harness should be used. For details refer to . (1) Disconnect joint connector (3) C-02, and measure the voltage at the wiring harness side of joint connector (3) (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between joint connector (3) terminal 7 and body ground. OK: 1.0 V or less CAUTION Strictly observe the specified wiring harness repair proce- Q: Does the voltage measure 1.0 V or less? YES : If the voltage measures 1.0 V or less, go to Step 25. wiring harness between joint connector (3) and the AC305231AP CONNECTOR: C-02 AC209365 11 22 10 21 9 20 8 19 7 18 6 17 5 16 4 15 3 14 2 13 1 12 AC209365FW HARNESS SIDE: C-02 TEST HARNESS |
