INTERIOR –

Seat

52A-12

SEAT

FRONT SEAT
REMOVAL AND INSTALLATION

Caution: SRS
Before removal of the seat equipped with the side air bag module, refer to GROUP 52B – SRS
Service Precautions and Air Bag Module.

44 Nm

2

3

2

4

5

1

29 Nm

6

44 Nm

3

Front floor
console box

44 Nm

44 Nm

6

4

5

3

29 Nm

3

1. Heated seat switch

<Vehicles with heated seat>

2. Headrestraint

Front seat assembly removal steps

3. Front seat anchor cover

4. Heated seat harness connector

<Vehicles with heated seat>

5. Side air bag module harness

connector <Vehicles with SRS side
air bag>

"

A

A

6. Front seat assembly

INSTALLATION SERVICE POINT

"

A

A

FRONT SEAT ASSEMBLY INSTALLATION

Temporarily tighten the mounting nuts and bolts, and then
tighten them to the specified torque. Note that the bolts shown
in the illustration should be tightened with no load on the
seat cushion.

INTERIOR –

Seat

52A-13

INSPECTION

HEATED SEAT SWITCH CONTINUITY CHECK

Switch
position

Terminal No.

position

1

3

4

5

–

8

9

2

–

6

Driver’s
seat
switch

HI

LO

Passen-
ger’s seat
switch

HI

LO

NOTE
To inspect the diode, match the polarity of the circuit tester
with the (+) (–) polarities in the table.

HEATER CHECK

Measure the resistance between terminals.

Standard value:

Between terminals 1 and 3: Approx. 5.4

Ω

Between terminals 1 and 2: Approx. 4.2

Ω

Between terminals 2 and 3: Approx. 9.6

Ω

INTERIOR –

Seat

52A-14

DISASSEMBLY AND REASSEMBLY

2

9

3

12

17

8

1

5

6

10

14

4

19

13

15

18

16

11

<Front view of front seat back>

<Front view of front seat cushion>

Section A–A

Section B–B

Claw

Claw

NOTE



: Hog ring positions



: Claw positions

A

A

7

B

B

B

B

1

7

19

19

Disassembly steps

1. Front seat side shield cover
2. Height adjuster lever
3. Inner seat belt
4. Reclining adjuster lever
5. Front seat hinge cover
6. Front cover
7. Recliner cover
8. Front seat cushion assembly
9. Front seat cushion cover

10. Front seat cushion pad

11. Front seat cushion frame

12. Front seat back assembly

A

A

"

13. Headrestraint guide
14. Front seat back cover
15. Front seat back pad
16. Front seat back frame
17. Release lever knob
18. Release lever trim
19. Seat slide adjuster

INTERIOR –

Seat

INTERIOR –

Seat

52A-15

REMOVAL SERVICE POINT

A

A

"

HEADRESTRAINT GUIDE REMOVAL

REAR SEAT
REMOVAL AND INSTALLATION

1

3

4

4

1

23 Nm

23 Nm

82 Nm

2

1. Headrestraint

Rear seat assembly removal steps

2. Rear seat cushion assembly
3. Rear seat back assembly
4. Rear seat stopper
