BODY  –

Door

42-8

FRONT DOOR TRIM AND WATERPROOF FILM

CLIP AND CLAW POSITIONS

Delta cover,
inner

Delta cover,
inner, door trim

Section A –  A

View B

A

A

A

A

Claws

Clips

View A

View B

NOTE

Door
trim

Door
panel

Clip

View A

BODY  –

Door

42-9

REAR DOOR TRIM AND WATERPROOF FILM

REMOVAL AND INSTALLATION

6

7

3

2

1

10

8

9

12

14

14

11

5

13

Sealant:
3M



 ATD Part No. 8625 or equivalent

8

12

9

4

4

<Vehicles without
power windows>

<Vehicles with
power windows>

Removal steps

1. Power window switch panel

assembly

2. Power window switch panel
3. Power window switch



A



4. Door inside handle cover



B



B



5. Clip



B



6. Escutcheon



B



7. Regulator handle

8. Cap
9. Door trim

10. Grip bracket

11. Door grip

12. Door lamp lense
13. Power window switch bracket



A



14. Waterproof film

BODY  –

Door

42-10

Rear
door
trim

Rear
door trim

Rear door
trim

Claw

Power window
switch panel
assembly

Claw

Cap

Claw

Cap

Door panel

C

C

Section A –  A

Section B –  B

Section C –  C

View D

View B

View C

A

A

B

B

View A

Door lamp
lense

Rear arm restraint cover

D

D

Section D –  D

Claws

Clips

View C

View D

View A

View B

NOTE

Rear
door trim

Clip

Door
lamp
lense

BODY  –

Door

42-11

REMOVAL SERVICE POINTS



A



DOOR INSIDE HANDLE COVER REMOVAL

1.

Insert the special tool between the inside handle upper
part and the inside handle cover, and then disengage
the upper claw of the inside handle.

2.

Disengage the lower claw of the inside handle in the same
manner as for the upper claw.

3.

Remove the door trim.

4.

Remove the inside handle cover from the door trim.



B



CLIP REMOVAL

Use a cloth to remove the clip as shown in the illustration.

INSTALLATION SERVICE POINTS



A



WATERPROOF FILM INSTALLATION

Apply the specified sealant to the shown positions of waterproof
film, and then attach the waterproof film.

Specified sealant: 3M



 ATD Part No. 8625 or equivalent

Caution
Be sure to apply the sealant below the inner panel water
drain holes so as not to plug them.



B



REGULATOR HANDLE/ESCUTCHEON/CLIP
INSTALLATION

1.

Install the clip and escutcheon to the regulator handle.

2.

Close the front door window glass fully, and then install
the regulator handle as shown in the illustration.

Inside handle

Section A –  A

Inside handle

cover

MB990784

A

A

Inside

handle

Inside

handle

cover

Claw

Claw

Waterproof film

Front of vehicle

3 0



Horizontal line
