MPI –
Fuel Injector
13B-83
REMOVAL SERVICE POINT
A
DELIVERY PIPE AND FUEL INJECTOR
ASSEMBLY REMOVAL
Remove the delivery pipe (with the injectors attached to it).
Caution
Care must be taken, when removing the delivery pipe,
not to drop the injector.
INSTALLATION SERVICE POINT
A
O-RING/FUEL INJECTOR ASSEMBLY/
HIGH-PRESSURE FUEL HOSE/FUEL PRESSURE
REGULATOR INSTALLATION
1.
Apply a drop of new engine oil to the O-ring.
Caution
Be sure not to let engine oil enter the delivery pipe.
2.
While turning the injector, high-pressure fuel hose and
fuel pressure regulator to the right and left, install the
delivery pipe, while being careful not to damage the O-ring.
After installing, check that the hose turns smoothly.
3.
If it does not turn smoothly, the O-ring may be trapped,
remove the injector, high-pressure fuel hose or fuel
pressure regulator and then re-insert it into the delivery
pipe and check once again.
4.
Tighten the high-pressure fuel hose and fuel pressure
regulator to the specified torque.
Tightening torque:
5.0 Nm (High-pressure fuel hose)
8.8 Nm (Fuel pressure regulator)
