KEYLESS ENTRY SYSTEM
BODY
42-58
7. If you are using two or more transmitters or have
added a second transmitter, the next transmitter
should be registered within one minute after
registering the code for the previous transmitter.
The registration procedure is common for all the
transmitter.
8. Registration mode will be cancelled under the
following conditions:
• When the secret code for four transmitters has
been registered;
• When no secret codes have been registered for
more than one minute after the registration mode
is entered;
• When passing one minute after finishing the reg-
istration of all transmitters;
• When the V.C.I. is disconnected from the diagno-
sis connector;
• When the key is removed from the key cylinder;
9. After the registration is completed, remove the
ignition key and close all the doors, and then
check that the keyless entry system operates
normally.
TRANSMITTER
DISASSEMBLY AND REASSEMBLY
M1428002800172
Post-reassembly operation
• Transmitter operation check
AC310838
AC303199
AC304118
1
2
AF
5
3
4
6
Disassembly steps
1.
Screw
2.
Upper cover
3.
Transponder
4.
Transmitter assembly
<<
A
>>
>>
A
<<
5.
Battery
6.
Master key
DISASSEMBLY SERVICE POINT
<<A>> BATTERY REMOVAL
CAUTION
Do not allow water or dust to enter the inside of
the transmitter assembly when it is open. Also,
do not touch the precision electronic device.
