METER AND GAUGE

CIRCUIT DIAGRAMS

90-190

METER AND GAUGE <LHD> (CONTINUED)

VEHICLE
SPEED
SENSOR

(FUSE     )

2

(FUSE     )

3

ENGINE
CONTROL
SYSTEM

INVECS-II 4A/T

ENGINE-A/T-ECU

OUTPUT
SHAFT
SPEED
SENSOR

A/T
CONTROL
RELAY

INVECS-II 4A/T

NOTE

:
:

4G1
4G6

<M/T>

<A/T>

METER AND GAUGE

CIRCUIT DIAGRAMS

90-191

COMBINATION
METER

COMBINATION
METER

RHEOSTAT

RHEOSTAT

<EXCEPT WHITE METER>

<WHITE METER>

(FUSE     )

21

(FUSE     )

21

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

METER AND GAUGE

CIRCUIT DIAGRAMS

90-192

METER AND GAUGE <RHD>

M1901003502224

IGNITION
SWITCH (IG1)

COMBINATION
METER

CONTROL CIRCUIT

ENGINE
COOLANT
TEMPERATURE
GAUGE UNIT

FUEL
GAUGE
UNIT

NOTE

: SEDAN
: WAGON
: M/T
: A/T
: 4G1
: 4G6

FRONT
SIDE

·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP AND
 LIGHTING MONITOR BUZZER
·TURN-SIGNAL LAMP AND
 HAZARD WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

·FRONT FOG LAMP
·HEADLAMP
·REAR FOG LAMP
·REAR WIPER AND WASHER

METER AND GAUGE

CIRCUIT DIAGRAMS

90-193

DIAGNOSIS
CONNECTOR

RELAY
BOX

BATTERY

FRONT-ECU

TAIL
LAMP RELAY

TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER

ODO/TRIP

ENGINE
SPEED
DETECTION
CONNECTOR

ENGINE-
ECU
ENGINE-
A/T-ECU

RHEOSTAT

·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP AND
 LIGHTING MONITOR BUZZER
·WINDSHIELD WIPER
 AND WASHER

WINDSHIELD WIPER
AND WASHER

·FRONT FOG LAMP
·HEADLAMP
·HEADLAMP
 LEVELLING SYSTEM
·REAR FOG LAMP
