POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-26

POWER DISTRIBUTION SYSTEM <LHD> (CONTINUED)

RELAY BOX

IGNITION
SWITCH

RELAY
BOX

·CLOCK
·ROOM LAMP AND LUGGAGE
 COMPARTMENT LAMP

·ROOM LAMP
 AND LUGGAGE
 COMPARTMENT
 LAMP

·ROOM LAMP, PERSONAL LAMP
 AND LUGGAGE ROOM LAMP

·ROOM LAMP,
 PERSONAL LAMP
 AND LUGGAGE
 ROOM LAMP

·SPARE CONNECTOR
 (FOR AUDIO)

STARTING
SYSTEM

IGNITION
SYSTEM

·ENGINE
 CONTROL
 SYSTEM

·ENGINE CONTROL
 SYSTEM

·INVECS-II
 4A/T

·INVECS-II 4A/T

·INVECS-II 4A/T

·BACK-UP LAMP

·METER AND
 GAUGE
·REAR WIPER AND
 WASHER
·SUPPLEMENTAL
 RESTRAINT SYSTEM
 (SRS)

·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)

·WINDSHIELD
 WIPER AND WASHER

·ABS
·BRAKE WARNING
 LAMP
·CENTRAL DOOR
 LOCKING SYSTEM
·CHARGING
 SYSTEM
·ENGINE CONTROL
 SYSTEM
·FRONT
 FOG LAMP
·FUEL WARNING
 LAMP
·HEADLAMP
·HEADLAMP
 WASHER

·KEY REMINDER
 BUZZER
·METER AND
 GAUGE
·OIL PRESSURE
 WARNING LAMP
·POWER WINDOWS

·REAR FOG LAMP
·REAR WIPER
 AND WASHER

·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD
 WIPER AND WASHER

4

FUSIBLE
LINK

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-27

REAR WIPER
AND WASHER

·ACCESSORY
 SOCKET
·REMOTE
 CONTROLLED
 MIRROR

CIGARETTE
LIGHTER AND
ASHTRAY
ILLUMINATION
LAMP

ABS

WINDSHIELD
WIPER AND
WASHER

·FRONT
 FOG LAMP
·HEADLAMP

·REAR
 FOG LAMP
·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·WINDSHIELD
 WIPER AND WASHER

·HEADLAMP
 LEVELLING
 SYSTEM
·HEATED SEAT
·HEATER
·MANUAL AIR
 CONDITIONER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

·AUTOMATIC AIR
 CONDITIONER

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-28

POWER DISTRIBUTION SYSTEM <LHD> (CONTINUED)

REAR
WINDOW
DEFOGGER
RELAY

REAR FOG
LAMP

·AUTOMATIC AIR
 CONDITIONER
·HEATER
·MANUAL
 AIR CONDITIONER

AUTOMATIC AIR
CONDITIONER

(FUSIBLE LINK     )

1

RELAY BOX

REAR WINDOW
DEFOGGER AND
DOOR MIRROR
HEATER

·ABS
·CENTRAL DOOR
 LOCKING SYSTEM
·ENGINE CONTROL
 SYSTEM
·FRONT FOG LAMP
·HEADLAMP
·HEADLAMP WASHER
·IMMOBILIZER SYSTEM
·INVECS-II 4A/T
·KEY REMINDER BUZZER
·POWER WINDOWS
·REAR FOG LAMP
·REAR WIPER AND
 WASHER
·ROOM LAMP
 AND LUGGAGE
 COMPARTMENT LAMP
·ROOM LAMP,
 PERSONAL LAMP AND
 LUGGAGE ROOM LAMP
·SUPPLEMENTAL
 RESTRAINT SYSTEM (SRS)
·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE LAMP
 AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP AND
 HAZARD WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

FUSE

5

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-29
