Mitsubishi Lancer. Manual - part 10





LOCATIONS USING URETHANE FOAM AND FOAM MATERIAL

BODY CONSTRUCTION

1-34

AB300745

AB

G

H

I

J

K

L

AB100698

AB201977AC

Centre pillar
reinforcement

Front pillar
reinforcement
upper

Side outer panel

G

High-rigidity foam

AB201981AC

Side outer panel

Rear pillar inner

Acoustic foam

H

AB201982

I

AC

Centre pillar inner

Acoustic foam

Centre pillar reinforcement

AB201057

AB202038 AB

J

Front pillar
inner lower

Front pillar
reinforcement lower

Acoustic foam

AB300946AD

K

Centre pillar
reinforcement

Urethane foam

Side sill outer
reinforcement

AB300945AC

L

Rear floor sidemember

Rear floor pan

Rear floor
side sill inner

High-rigidity
foam

LOCATIONS USING URETHANE FOAM AND FOAM MATERIAL

BODY CONSTRUCTION

1-35

AB300702 AB

<Wagon>

A

B

D

E

C

F

E

AB201973

AC

A

Front pillar inner
reinforcement (Driver's side)

Acoustic foam

Front pillar
reinforcement upper B
(Driver's side)

Front pillar
reinforcement
upper

Side roof
rail inner

AB300944

B

AB

Front pillar
inner lower

Acoustic foam

Side sill
outer
reinforce-
ment front

Side sill
reinforce-
ment
support
front

AB300943

AB

C

Sidemember
outer

High-rigidity
foam

Front sidemember
outer
reinforcement
rear B

AB300096AC

D

Front pillar
inner lower

Front pillar
reinforcement lower

Acoustic foam

Side outer panel

AB201975

AC

E

Side outer panel

Side sill
outer
reinforcement
front

High-rigidity foam

AB201976 AC

Side outer
panel

Quarter panel
inner

Acoustic foam

F

LOCATIONS USING URETHANE FOAM AND FOAM MATERIAL

BODY CONSTRUCTION

1-36

AB300746

AB

G

H

I

J

K

L

AB100698

AB201977AC

Centre pillar
reinforcement

Front pillar
reinforcement
upper

Side outer panel

G

High-rigidity foam

AB201982 AC

Centre pillar inner

Acoustic foam

H

Centre pillar reinforcement

AB201057

AB202038 AD

I

Front pillar
inner lower

Front pillar
reinforcement lower

Acoustic foam

AB300946AC

J

Centre pillar
reinforcement

Urethane foam

Side sill outer
reinforcement

AB300945AB

K

Rear floor sidemember

Rear floor pan

Rear floor
side sill inner

High-rigidity
foam

AB300947AB

L

Quarter panel inner

Quarter outer panel
lower extension

Side outer
panel

Urethane foam

STIFFENER AND DAMP SHEET APPLICATION LOCATIONS

BODY CONSTRUCTION

1-37

STIFFENER AND DAMP SHEET APPLICATION LOCATIONS

M4010008000147

Sound insulation was improved with anti-vibration
effects and heightening surface rigidity with a stiff-
ener applied on the inner side of the side outer panel,
and a damping sheet adhered to the quarter inner
panel and the inner side of the front door.

NOTE: The main contents of a stiffener are epoxy
resin. It comes in a sheet form and contains a mix-
ture of glass fiber and filler, and cures (stiffens) when
heated. It is used to improve the rigidity of the outer
panel.

AB300942 AB

Stiffener

Damp sheet

Stiffener

Damp sheet

<Front door>
