VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-19

CHASSIS NUMBER

M1001005600369

The chassis number is stamped on the front floor pan.
CODE CHART

ENGINE MODEL STAMPING

M1001005700322

The engine model is stamped on the cylinder block.
The engine model number is as shown as follow.

The engine serial number is stamped near the engine model
number.

VEHICLE IDENTIFICATION CODE PLATE

M1001005400116

The information code plate is riveted onto the cowl top outer
panel in the engine compartment.
CODE CHART

Chassis
number code

Content

CZ4A8U00001 Vehicle line

CZ4A; LANCER EVOLUTION

8U000001; Refer to 10th thru 17th digits of
VIN plate

AC608772AD

Front passenger's seat

Engine model

Engine displacement

4B11

2.0L

Engine number

AA0201 to YY9999

AC700355

No. Item

Example

Content

1

MODEL

CZ4AS

Vehicle model

MGFZL2M

Model series

2

ENGINE

4B11

Engine model

3

EXT

W69C

Exterior code

4

TRANS

W4A5A

Transaxle model

5

COLOR

W69

Body color code

6

TRIM

06E

Interior code

7

OPT

Q40

Equipment code

AC608666

MODEL

1

2

3

4

5

6

7

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-20

TIRE AND LOADING INFORMATION PLACARD

M1001015800137

The tire and loading information placard is located on the inside
sill of the driver’s door.

VEHICLE SAFETY CERTIFICATION LABEL

M1001017300020

The vehicle safety certification label is attached to the face of
the left door sill.
This label indicates the month and year of manufacture, Gross
Vehicle Weight Rating (GVWR), front and rear Gross Axle
Weight Rating (GAWR), and Vehicle Identification Number
(VIN).

NATIONAL SAFETY MARK <CANADA>

M1001017400016

The tire and loading information placard is located on the inside
sill of the driver’s door.

AC608670

AC608668AB

AC608670

AC608670AG

AC608670

AC609140AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-21

THEFT PROTECTION LABEL

M1001015700260

CAUTION

When replacing a part that has the theft protection plate,
label or stamp on it, be sure that the part has either A or B
shown in the figure. It is illegal if both A and B are
attached, or neither A nor B is attached.
In order to protect against theft, a Vehicle Identification Number
(VIN) is attached as a plate or label to the following major parts
of the engine, transaxle and main outer panels: Engine cylinder
block, Transaxle housing, Front fender, Hood, Trunk lid,
Bumpers, Side outer panel, Doors. In addition, a theft-protec-
tion label is attached to replacement parts for main outer pan-
els. The same data is stamped into replacement parts for the
engine and the transaxle.

CAUTION

Cautions regarding panel repairs:

• When repainting original parts, do so after first masking

the theft-protection label. After painting, be sure to peel
off the masking tape.

• The theft-protection label for replacement parts is cov-

ered by masking tape, so such parts can be painted as
is. The masking tape should be removed after painting
is finished.

• The theft-protection label should not be removed from

original parts or replacement parts.

.

AC704152

Theft protection plate and label

For original parts

For replacement parts

AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-22

LOCATIONS

AC710510

D

A

B

F

E

D'

AC

E'

F'

C
