IGNITION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-41

IGNITION
COIL 2

IGNITION
COIL 3

IGNITION
COIL 4

SPARK
PLUG

SPARK
PLUG

SPARK
PLUG

COIL
DRIVER

COIL
DRIVER

COIL
DRIVER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE
Y : YELLOW     SB : SKY BLUE     BR :BROWN     O : ORANGE     GR : GRAY
R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

IGNITION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-42

IGNITION SYSTEM (CONTINUED)

ETACS-ECU

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ENGINE CONTROL MODULE

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

JOINT
CONNECTOR
(CAN2)

JOINT CONNECTOR
(CAN3)

<M/T>

NOTE

: THE TERMINAL NUMBERS DESCRIBED

IN THE CIRCUIT DIAGRAM AGREE WITH
THE NUMBERS MAKED ON THE
TRANSAXLE ASSEMBLY CONNECTOR AND
HARNESS SIDE CONNECTOR.

IGNITION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-43

JOINT
CONNECTOR
(CAN4)

CPU

SHIFT
LEVER

TRANSAXLE
ASSEMBLY

<TC-SST>

CHARGING SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-44

CHARGING SYSTEM <M/T>

M1901000703493

FUSIBLE
LINK

33

FUSIBLE
LINK

36

STATOR
COIL

STATOR
COIL

FIELD
COIL

IC VOLTAGE REGULATOR

ENGINE CONTROL
MODULE

ENGINE
COMPARTMENT

RELAY BOX

GENERATOR
