STARTING SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-37

NOTES

STARTING SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-38

STARTING SYSTEM <TC-SST>

M1901000503682

STARTER
RELAY

BATTERY

FUSIBLE
LINK

24

STARTER

STARTING SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-39

IGNITION
SWITCH (ST)

ENGINE
CONTROL
MODULE

ETACS-
ECU

JOINT
CONNECTOR
(7)

SHIFT
LEVER

SHIFT LEVER
POSITION
SWITCH (P)

SHIFT LEVER
POSITION
SWITCH (N)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

IGNITION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-40

IGNITION SYSTEM

M1901000604303

SPARK
PLUG

IGNITION
COIL 1

ENGINE
CONTROL
MODULE

FUSIBLE
LINK

36

MFI
RELAY

ENGINE
COMPARTMENT

RELAY BOX

INPUT SIGNAL

·ACCELERATOR PEDAL
 POSITION SENSOR
·CAMSHAFT POSITION
 SENSOR
·CRANKSHAFT
 POSITION SENSOR
·ENGINE COOLANT
 TEMPERATURE SENSOR
·FUEL TANK DIFFERENTIAL
 PRESSURE SENSOR
·HEATED OXYGEN SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
 TEMPERATURE SENSOR
·KNOCK SENSOR
·MANIFOLD ABSOLUTE
 PRESSURE SENSOR
·MASS AIRFLOW
 SENSOR
·THROTTLE POSITION
 SENSOR

COIL
DRIVER
