TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-23

No. Standard measurement point

Hole shape Size mm (in)

42

Front pillar positioning notch (upper)

−

−

43

Front pillar positioning notch (lower)

−

−

44

Roof side rail positioning notch (front)

−

−

45

Side sill positioning notch (front)

−

−

46

Center pillar positioning notch (upper)

−

−

47

Center pillar positioning notch (lower)

−

−

48

Roof side rail positioning notch (rear)

−

−

49

Side sill positioning notch (rear)

−

−

50

Quarter panel positioning notch (upper)

−

−

51

Quarter panel positioning notch (lower)

−

−

59

Body center point of rear shelf panel

−

−

68

Center of parking brake lever mounting hole (Body center point)

Round

11 (0.43)

69

Body center point of rear floor extension

−

−

70

Center of rear shock absorber mounting hole

Round

14 (0.55)

71

Center of rear end trim mounting hole

Round

8.5 (0.335)

AB601025

42

AC

AB700598

43

AB

AB601027

44, 46

44

46

AC

AB601028

45

AC

AB601030

47

AC

AB601031

48

AC

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-24

AB700485

49

AB

AB601033

50

AC

AB700858

51

AB

AB601056AC

59

AB601063

68

AC

AB700463

69

AB

AB700464

70

AB

AB700465AB

71

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-25

AB600984

AE

72

73

1,392

(54.8)

 130

(5.1)

1,392

(54.8)

1,397

(55.0)

 140

(5.5)

1,401

(55.2)

mm (in)

75

74

No. Standard measurement point

Hole shape Size mm (in)

72

Center of deck crossmember mounting hole (left-upper)

Round

13 (0.51)

73

Center of deck crossmember mounting hole (left-lower)

Round

13 (0.51)

74

Center of deck crossmember mounting hole (right-upper)

Round

9 (0.35)

75

Center of deck crossmember mounting hole (right-lower)

Round

9 (0.35)

AB601067

72, 73

72

73

AC

AB601066

74, 75

74

75

AC
