Mitsubishi Lancer Evolution 8. Manual - part 163





13A-38

MPI – TROUBLESHOOTING

Checking Procedure 3

Is it possible to start the engine?

Check to see if engine warning light is broken
(ref. Chapter 54A – Combi. Meter)

Checking procedure 22: Check engine ECU power
supply, engine control relay, ignition switch-IG1 system
(ref. P.13A-65)

Replace engine warning light

Check connector C-106

C-106 Combi. meter connector
measurement
• Undo connector, then take

measurement on harness side

• Ignition switch ON
• Voltage across 9 – earth
OK: Battery voltage

Check connector C-49

C-49 Engine ECU measurement
• Undo connector, then take
measurement on harness side
• Ignition switch ON
• Voltage across22 – earth
OK: Battery voltage

Check connectors C-212, C-210

Check and repair harness between combi. meter and ignition
switch.
• Check for damage to power supply cable

Check connector C-22

Check harness between combi. meter and engine ECU.
• Check for damage to power supply cable

Confirm fault symptoms

Replace engine ECU

Intermittent malfunction (ref. Chapter 00 – Intermittent
Malfunctions)

Check connectors C-212, C-210

Check and repair harness
between combi. meter and
ignition switch.
• Check to see if power supply

cable is broken, or has short
circuit

Check connectors C-22

Check and repair harness
between combi. meter and
ignition switch.
• Check to see if power supply

cable is broken, or has short
circuit

The engine warning light does not come on  immediately after
turning ignition switch ON.

Probable causes

To check whether the engine warning light bulb is broken or not, the
engine ECU checks the engine warning light for a duration of 5 seconds
immediately after the ignition switch is turned to the ON position.

• Engine warning lamp bulb is broken
• Ignition switch malfunction
• Engine control relay malfunction
• Engine ECU malfunction

YES

NO

OK

OK

OK

OK

OK

OK

OK

OK

OK

NG

NG

NG

NG

NG

NG

OK

NG

NG

NG

NG

NG

NG

OK

OK

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

MPI – TROUBLESHOOTING

13A-39

Checking Procedure 4

MUT-II/III Diagnosis Code
• Has diagnosis code been

output?

Check connector C-49

C-49 Engine ECU measurement
• Undo connector, then take

measurement on harness side

• Ignition switch ON
• Voltage across 22 - earth
OK: Battery voltage

Check connector C-22

Check and repair harness
between combi. meter and
Engine ECU
• Check to see if output cable for

short circuit

Diagnosis Code List
(ref. P.13A-5)

Confirm fault symptoms

Replace engine ECU

Intermittent malfunction (ref.
Chapter 00 – Intermittent
Malfunctions)

Engine warning light stays lit (does not go off)

Probable causes

When the engine ECU records the generation of the diagnosis code, it
turns the engine warning light on.

• Engine ECU malfunction

YES

NG

NG

NG

NG

OK

OK

OK

NO

OK

Repair

Repair

MPI – TROUBLESHOOTING

13A-40

Checking Procedure 5

Check connector C-201

Check battery
(ref. Chapter 54 – Battery)

MUT-II/III Service Data
• No.18: cranking signal
• Ignition switch: ST

OK: ON

• Ignition switch: ON

OK: OFF

To next page

Replace battery

Check connector B-14X

B-14X Starter interlock relay
connector measurement
• Undo connector, then take
measurement on harness side
• Ignition switch: ST
• Voltage across 2 – earth
• Voltage across 3 – earth

OK: Battery voltage

Check starter interlock relay
(ref. Chapter 16 – Vehicle
Servicing)

Check connector C-127

C-127 Clutch switch connector
measurement
• Undo connector, then take

measurement on harness side

(1) Voltage across 2 - earth

(Ignition switch: ST)
OK: Battery voltage

(2) Resistance across 2 – earth

OK: 2

or less

Check clutch switch
(ref. Chapter 21 – Clutch Pedal)

Check connectors C-23, B-21,
B-05

To next page

Check ignition switch
(ref. Chapter 54 – Ignition Switch)

Replace ignition
switch

Check connector C-21

Check and repair harness
between ignition switch and
starter interlock relay
• Check to see if power supply

cable is broken, or has a short

Starter interlock relay

Check connector C-126, C-22

Check and repair harness
between starter interlock relay
and clutch switch
• Check to see if power supply

cable is broken or has a short

Check connectors C-126, C-107

Check and repair harness
between clutch switch and body
earth
• Check to see if earth wire is

broken or damaged

Replace clutch switch

Starting not possible (starter does not turn over)

Probable causes

The probable causes are noted right.

• Battery malfunction
• Ignition switch malfunction
• Starter malfunction

NG

NG

NG

NG

NG

NG

NG

NG

(1) NG

(2) NG

NG

OK

OK

NG

Repair

OK

OK

OK

OK

OK

OK

OK

OK

OK

NG

NG

OK

OK

OK

Repair

Repair

Repair

Repair

Repair

MPI – TROUBLESHOOTING

13A-41

From previous page

Check connector B-05

B-05 Starter connector
measurement
• Undo connector, then take

measurement on harness side

• Ignition switch: ST
• Voltage across 1 – earth
OK: Battery voltage

Check terminal: B-04

B-04 Starter terminal
measurement
• Voltage across 1 – earth
OK: Battery voltage

Check connectors B-14X, C-21,
C-201

Check harness between ignition
switch and starter interlock relay
• Check for damage to power

supply cable

Check connector B-21

Check harness starter interlock
relay and starter
• Check for damage to output

wire

Check connector C-22, C-126,
C-127, C-107

Check harness between starter
interlock relay and clutch switch
• Check for damage to power

supply cable

Check harness between battery
and starter
• Check for damage to power

supply cable

Replace starter

From previous page

Check harness between starter
interlock relay and starter
interlock relay intermediate
connector
• Check to see if output wire is

broken or has a short

Check harness between starter
interlock relay intermediate connector
and starter
• Check output wire for short circuit

Check connector B-21

Check and repair harness
between starter interlock relay
intermediate connector and
starter
• Check to see if output wire is

broken

Check and repair harness
between battery and starter
• Check to see if power supply

cable is broken or has a short

Check connector C-42

Check and repair harness between
starter interlock relay intermediate
connector and Engine ECU
• Check output wire for short circuit

OK

NG

OK

OK

OK

OK

NG

OK

OK

OK

OK

OK

OK

OK

OK

OK

OK

OK

OK

NG

NG

NG

NG

NG

NG

NG

NG

NG

NG

NG

NG

NG

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair

Repair
