CIRCUIT DIAGRAMS - J/C

3-9

H3J00J03BB

DVD-MMCS
Fully
automatic air
conditioning

Remote control
door mirror

J/B

(General-

purpose

fuses)

General-
purpose
spare
connectors

DVD-MMCS
Spare
connector
for audio
<vehicle not
fitted with
DVD-
MMCS>

DVD-
MMCS
Clock
<vehicle not
fitted with
DVD-
MMCS>

J/B

(General-

purpose

fuses)

Fog light
Spare
connector
for fog
light

Fog light

Fog light
Spare
connector
for fog light

SRS airbag
Seat belt
pretensioners

DVD-MMCS
Engine
immobiliser
system
Engine control
system

Diagnostic
connector

Interior light,
Luggage
compartment
light, ignition
lock light,
door open
warning light

Central door
locking <vehicle
fitted with
keyless entry>
Interior light,
Luggage
compartment
light, ignition key
cylinder
illumination light,
door open
warning light

DVD-
MMCS
Gauge
Warning
light

Gauge
Warning light

J/C (4)

C-110

11

13

CIRCUIT DIAGRAMS - J/C

3-10

Diagnostic
connector

Security
alarm

Security alarm
Horn

Fully
automatic air
conditioning

Horn

Interior light,
luggage
compartment,
ignition lock
light, door open
warning light

Engine control
system

Engine
control
system
Ignition

Gauge

Engine control
system
Gauge
Ignition

Engine immobiliser
system
Engine control system
Fully automatic air
conditioning
Cooling

Engine
control
system Engine

immobiliser
system
Engine
control
system Engine immobiliser system

Fully automatic air conditioning
Cooling

J/C (continued)

Remote
control door
mirror
Electric
window
Fog light
Headlight
Rear
wiper/washer

Indicator light,
hazard warning
light
Tail light, front
side light,
licence plate
light, lighting
monitor buzzer

Ignition key
reminder
warning
buzzer
Windscreen
wiper/washer
Sunroof
Security
alarm
Central door
locking

CIRCUIT DIAGRAMS - CENTRALISED JUNCTIONS

3-11

CENTRALISED JUNCTIONS

M3030000300240

Fusible links (relay box inside engine compartment fuse box directly fitted on battery)

Relay box inside engine compartment

Fuse box directly fitted on the battery

AC203977AB

Vehicle front

Vehicle front

No. Used circuit

Type

Housing colour Rated capacity (A)

1

General-purpose fuse Nos. 15, 18, 19, 20

Screwed

Yellow

60

2

Fully automatic air conditioning, cooling

Connector

Red

50

3

ABS

Connector

Yellow

60

4

Circuit via ignition switch

Connector

Green

40

5

Special-purpose fuse No. 21, electric window

Connector

Green

40

6

Battery/fusible link Nos. 1, 2, 3, 4, 5, special-purpose
fuse Nos. 1, 2, 3, 4, 5, 6, 7, 8, 10, 24, front ECU

Screwed

-

100

7

ACD

Screwed

-

60

CIRCUIT DIAGRAMS - CENTRALISED JUNCTIONS

3-12

Special-purpose fuses (relay box inside engine compartment, fuse box directly fitted in J/B)

Power distribution
circuit

Fuse
No.

Rated
capacity
(A)

Identification
colour

Application

1

15

Blue

Fog light relay, fog light, fog light indicator

light, spare connector for fog light

2

10

Red

Horn relay, horn

3

20

Yellow

Engine ECU, engine control system relay,

idling speed control servo, radiator (for

injector), purge control solenoid valve,

cam position sensor, crank angle sensor,

Oxygen sensor, airflow sensor, radiator

fan control relay, secondary air control

solenoid valve, waste gate solenoid valve,

fuel pressure solenoid valve, ignition coil

1, Ignition coil 2

4

10

Red

A/C compressor

5

15

Blue

ABS-ECU, rear combination light, high

mount stop light, 4WD-ECU

6

30

Green

Condenser fan motor

7

7.5

Brown

Alternator

8

10

Red

ETACS-ECU

9

-

-

-

Battery/alternator

(fusible link No. 6)

10

15

Blue

Fuel pump relay 3, fuel pump register,

fuel pump & fuel gauge unit (main)

11

10

Red

Headlight (HI: RH)

Front ECU (Headlight

relay: HI)

12

10

Red

Headlight (HI: LH) high beam indicator

light

10

Red

Headlight ASSY (LO: RH) <excluding

discharge type headlight>

13

20

Yellow

Headlight ASSY (LO: RH) <discharge

type headlight>

10

Red

Headlight ASSY (LO: LH) <excluding

discharge type headlight>

Front ECU (Headlight

relay: LO)

14

20

Yellow

Headlight ASSY (LO: LH) <discharge type

headlight>, headlight levelling system

Front ECU (tail light
relay)

15

16

7.5

7.5

Brown

Brown

Headlight ASSY (position: RH), rear
combination light, A/C-ECU, heater control
unit, audio unit, clock, cigarette lighter
light, ashtray illumination light, combination
meter, hazard switch, fog light switch, ACD
mode switch, Intercooler water spray
switch, headlight levelling system, general-
purpose spare connectors, spare
connector for audio

Headlight ASSY (position: LH), rear
combination light, licence plate light
