4-1

BODY – MAIN BODY

SECTION 4

BODY

CONTENTS

Main Body................................................4-1

Body Panels .....................................................4-1

Paintwork.................................................4-1

Body colour chart ............................................4-1

Main Body

Body Panels

Vehicle weight has been reduced by using aluminium for the roof panels and the side door beams, in addition to the bonnet
panel and front wing panels, as previously.

: Parts made from aluminium

Paintwork

Body colour chart

Colour name
(Former name)

Colour
symbol

Colour
code

Colour (paint)
number

Coating ingredient

Maintenance
symbol

Name of paint
manufacturer

Cool Silver Metallic

CL

A31

CMA10031

Aluminium

M

Kansai Paint

Medium Purplish Grey Mica

ES

A39

CMA10039

Aluminium +
interference mica

2P

Nippon Paint

Solid White (Scotia White)

2E

W83

AC10983

––

S

Kansai Paint

Solid Red (Palma Red)

JW

P85

AC11185

––

S

Kansai Paint

Note :
• The maintenance code is only for the top coat. S = Solid; M = Metallic; 2P = 2-coat pearl
• The name of the paint manufacturer is the name of the manufacturer of the paint used at the time of production.



5-1

EXTERIOR  – MARKINGS

SECTION 5

EXTERIOR

CONTENTS

Markings ..................................................5-3

Markings

An Evolution MR logo has been added.

Evolution MR logo

7-1

EQUIPMENT  – COMBINATION METER

SECTION 7

EQUIPMENT

CONTENTS

Combination meter .................................7-1

Combination meter

The combination meter has been changed as illustrated below.

(Lancer Evolution VIII MR)

(Lancer Evolution VIII)

Marking changed

8-1

REFERENCE MATERIAL – MAIN SPECIFICATIONS

SECTION 8

REFERENCE MATERIAL

CONTENTS

Main specifications.................................8-1
Detailed specifications...........................8-4

Main equipment ......................................8-6
Cold climate specifications ...................8-8

Main Specifications

These Main Specifications are based on submitted data, and may therefore differ from the actual equipment.
The

★

symbol indicates specifications which have changed from the previous model.

Vehicle name and model

Mitsubishi GH-CT9A

Chassis name and type

Mitsubishi CT9A

Manufacturer

Mitsubishi Motor Corporation

Category

Normal

Use

Passenger

Body shape

Saloon

Engine type

4G63

Capacity cc

1997

GH-CT9A

GH-CT9A

Item

SNDFZ

SJDFZ

SJGFZ

Classification No.È

079, 080, 085, 086,

091, 092, 097, 098

083, 084, 089,

090, 095, 096,

099~102

105, 106, 109,

110, 113, 114,

117, 118

119

Vehicle length mm

4490

Vehicle width mm

1770

Vehicle height mm

1450

Wheelbase mm

2625

Front

1500

1515

¨

¨

Dimensions

Track mm

Rear

1500

1515

¨

¨

Weight

See weight chart

Left

50˚

Performance Max.

angle of

stability

Right

50˚

Wheel alignment Front 2 drive – Rear 2 drive

Front

Other

Tyre

size

Rear

205/65R15 94H

235/45ZR17

¨

¨

Note :
See Weight Chart for relationships between classification numbers and equipment.
