ON-VEHICLE SERVICE TSB Revision AUTOMATIC TRANSAXLE 23A-344 (4) Loosen the locking nut of the key interlock cable. arrow until the cable stops. Tighten the locking nut. (6) Install the floor console. 3. After adjusting, check the operation once more. If the operation is still incorrect, replace the key interlock cable. .) SHIFT LOCK MECHANISM CHECK M1232001000064 1. Carry out the following inspections. 2. When the above operations are defective, adjust the shift lock cable as follows: (1) Remove the floor console. (Refer to GROUP 54A - Floor console .) (2) Shift selector lever to "P." cable comes above the red marking of the lock cam. (5) Install the floor console. 3. After adjusting, check the operation once more. If the operation is still incorrect, replace the shift lock cable. (Refer AC0001627AB RED MARKING LOCKING SHIFT LOCK CABLE LOCK CAM INSPECTION INSPECTION CONTENTS CHECK DETAILS (NORMAL CONDITION) 1 Brake pedal: Ignition key Push in the selector lever push button. Shifting from "P" 2 Brake pedal: Push in the selector lever push button. Shifting from "P" 3 Brake pedal: Push in the selector lever push button. Shifting from "R" AC001628AB RED MARKING LOCKING LOCK CAM SHIFT LOCK CABLE |
