AUTOMATIC TRANSAXLE DIAGNOSIS
TSB Revision
AUTOMATIC TRANSAXLE
23A-31
3. Connect the special tools (2,942 kPa (427 psi) oil pressure
gauge [MD998330] and adapters [MD998332, MD998900])
to each pressure discharge port.
NOTE:
.
•
2ND: Second brake pressure port
•
UD: Underdrive clutch pressure port
•
LR: Low-reverse brake pressure port
•
DA: Torque converter apply pressure port
•
DR: Torque converter release pressure port
•
RV: Reverse clutch pressure port
•
OD: Overdrive clutch pressure port
4. Measure the hydraulic pressure at each port under the
conditions given in the standard hydraulic pressure table,
and check that the measured values are within the standard
value ranges.
5. If a value is outside the standard range, correct the problem
while referring to the hydraulic pressure test diagnosis table.
STANDARD HYDRAULIC PRESSURE TEST
AC001827
AC001825
AC001828
MEASUREMENT CONDITION
STANDARD HYDRAULIC PRESSURE kPa (psi)
SELECTOR
LEVER
POSITION
SHIFT
POSITION
ENGINE
SPEED (r/min)
UNDERDRIVE
CLUTCH
PRESSURE
[UD]
REVERSE
CLUTCH
PRESSURE
[RV]
OVERDRIVE
CLUTCH
PRESSURE
[OD]
LOW-
REVERSE
BRAKE
PRESSURE
[LR]
SECOND
BRAKE
PRESSURE
[2ND]
TORQUE
CONVERTER
PRESSURE
[DR]
P
−
2,500
−
−
−
220
−
360
(32
−
52)
−
250
−
390
(37
−
57)
R
Reverse
2,500
−
1,270
−
1,770 (185
−
256)
−
1,270
−
1,770
(185
−
256)
−
500
−
700
(73
−
101)
N
−
2,500
−
−
−
220
−
360
(32
−
52)
−
250
−
390
(37
−
57)
