SPECIAL TOOLS

ENGINE MECHANICAL <4G1>

11C-4

SPECIAL TOOLS

M1112000601175

Tool

Number

Name

Use

B992080

A

B

MB992080
A: MB992081
B: MB992082

Belt tension meter set
A: Belt tension meter
B: Microphone assembly

Drive belt tension check

MB991910

MB991826

MB991955

MB991911

MB991824

MB991827

MB991825

A

B

C

D

E

F

DO NOT USE

MB991955
A: MB991824
B: MB991827
C: MB991910
D: MB991911
E: MB991825
F: MB991826

M.U.T.-III sub assembly
A: Vehicle communication

interface (V. C. I.)

B: M.U.T.-III USB cable
C: M.U.T.-III main harness

A (Vehicles with CAN
communication system)

D: M.U.T.-III main harness

B (Vehicles without
CAN communication
system)

E: M.U.T.-III adapter

harness

F: M.U.T.-III trigger

harness

CAUTION

For vehicles with CAN
communication, use
M.U.T.-III main harness A to
send simulated vehicle
speed. If you connect
M.U.T.-III main harness B
instead, the CAN
communication does not
function correctly.

• Drive belt tension check

• Checking the ignition timing

• Checking the idle speed

B991668

MB991668

Belt tension meter set

Drive belt tension check (used
together with M.U.T.-III)

Main

Index

Group

TOC

AC204024

SPECIAL TOOLS

ENGINE MECHANICAL <4G1>

11C-5

MD998772

Valve spring compressor

Compressing intake and
exhaust valve spring

MB991671

Valve stem seal installer

Valve stem seal installation

MD998762

MD998762

Circular packing installer

For pressing in cylinder head
camshaft end seal

MD998713

Camshaft oil seal installer Camshaft oil seal

D998727

MD998727

Oil pan FIPG cutter

Engine oil pan removal

D998781

MD998781

Flywheel stopper

Supporting the drive plate

MD998011

Crankshaft rear oil seal
installer

Crankshaft rear oil seal
installation

Tool

Number

Name

Use

Main

Index

Group

TOC

MB991962

SPECIAL TOOLS

ENGINE MECHANICAL <4G1>

11C-6

MB991962

Crankshaft front oil seal
guide

Crankshaft front oil seal
installation

MD998306

Camshaft oil seal installer

MB991653

Cylinder head bolt wrench Removal and installation of

cylinder head bolt

MD998769

Crankshaft sprocket
spacer

Removal and installation of
valve timing belt

D998738

MD998738

Adjust bolt

Supporting the timing belt
tensioner arm and timing belt
tensioner adjuster

D998767

MD998767

Tensioner wrench

Valve timing belt tension
adjustment

Tool

Number

Name

Use

Main

Index

Group

TOC

B991953

SPECIAL TOOLS

ENGINE MECHANICAL <4G1>

11C-7

MB991953

Oxygen sensor wrench

Oxygen sensor removal and
installation

B991527

MB991527

Engine hanger

Supporting the engine
assembly during removal and
installation of the transmission
assembly
NOTE: Special tool MB991454
is a part of engine hanger
attachment set MB991453.

B991454

MB991454

Engine hanger balancer

Tool

Number

Name

Use

Main

Index

Group

TOC
