INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-8

DISASSEMBLY AND REASSEMBLY

M1521001900484

CAUTION

Refer to GROUP 52B, Driver’s, Front Passenger’s
Air bag Module(s) and Clock Spring

P.52B-145



before removing the passenger’s side air bag
module.

AC401816

4

5

3

7

8

1

6

7

5

8

1

9

10

11

12

AB

b

b

b

b

b

b

b

l

b

b

b

b

b

b

b

13

2

b

i

h

Disassembly steps

1.

Side air outlet bezel

2.

Under reinforcement

3.

Air bag module (passenger’s side)

4.

Ventilator air distribution duct

5.

Side defroster duct

6.

Defroster nozzle

7.

Upper side bracket

8.

Side air outlet

9.

Connector holder

10. Centre reinforcement
11. Glove box striker
12. End cover
13. Instrument panel

Disassembly steps (Continued)

Main

Index

Group

TOC

SYSTEM UP TRAY

INTERIOR

52A-9

SYSTEM UP TRAY

REMOVAL AND INSTALLATION

M1521009000021

AC206304



AC401818

1

2

3

3

4

AB

Removal steps

1.

Floor console cover

2.

Cup holder

3.

Floor console panel

4.

Floor console

Removal steps (Continued)

Main

Index

Group

TOC

FLOOR CONSOLE ASSEMBLY

INTERIOR

52A-10

FLOOR CONSOLE ASSEMBLY

REMOVAL AND INSTALLATION <M/T>

M1521002200585

AC600651AC

1

2

2

3

4

5

6

A

A

B

B

 Claw

 Claw

NOTE
         : Claw positions

Section A – A

Section B – B

1.

Ashtray
Removal steps

2.

Console panel

3.

Floor console centre panel

4.

Floor console assembly

5.

Floor console front bracket

6.

Floor console centre bracket

Removal steps (Continued)

Main

Index

Group

TOC

TRIMS

INTERIOR

52A-11

TRIMS

INTERIOR TRIM

REMOVAL AND INSTALLATION

M1521001100585

AC206368

AC401821

17

16

18

20

22

9

6

8

21

19

5

7

3

4

2

1

44 ± 10 N·m

44 ± 10 N·m

AB

10

11

12 13

14

15

22 ± 4 N·m

1.

Front scuff plate

2.

Cowl side trim

3.

Door opening trim

4.

Front pillar trim

5.

Rear scuff plate

6.

Rear door opening trim

7.

Centre pillar trim lower

8.

Front seat belt connection

9.

Centre pillar trim upper

10. Washer assembled bolt
11. Child restraint fitting

12. Cover
13. Spacer
14. Plain washer
15. Fiber washer
16. Rear end trim
17. Quarter trim cap
18. Quarter trim hook
19. Quarter trim lower
20. Rear seat belt connection
21. Rear seat belt clip
22. Quarter trim upper
