5.9 Painting work
Paint compatibility should be checked when
repainting. In order to avoid color variations on
painted bodies, MITSUBISHI FUSO recommends that
paints be used only if they have been tested and
approved for the vehicle model in question.
Information on the primers used at the factory and on
MITSUBISHI FUSO color numbers can be obtained
from the relevant department
컄 page 15.
Mask the following areas before painting:
• Sealing surfaces
• Windows
• Contact areas between the wheels
and wheel hubs
• Contact areas for wheel nuts
• Breathers on gearboxes, axles, etc.
• Disc brakes and disc rotors
• Door locks
• Door retainers in the rear door hinges
• Coupling flanges of drive shafts and power take-
offs
• Spring mounting area
• Rubber hoses
• Electric control unit
TCU (Transmission Control Unit)
• Lavel (Caution and name)
• Inner parts of drum brakes <FG>
• Inner surface of brake drums <FG>
• Contact areas between hubs and brake drums
<FG>
H
Environmental note
Paints and lacquers are harmful to health and to the
environment if they are not handled correctly.
Dispose of paints and lacquers in an
environmentally responsible manner.
