40

3 Planning of bodies

3.10 Maintenance and repairs

i

MITSUBISHI FUSO body/equipment mounting directives for FE, FG  Issue date: 06. 07. 2012

!

 Only print out complete sections from the current version

3.10.4 Work before handing over the modified

vehicle

The manufacturer must confirm the work and
modifications carried out by making an entry in the
vehicle or job file.

Checking the overall vehicle

Check the vehicle for perfect condition. All damage
must be repaired.

Checking the batteries:

Test the battery charge before handing over the
vehicle.

Checking the tires

Before handing over the vehicle, check that the tires
are inflated to the specified pressure and check the
tires for damage. Damaged tires must be replaced.

Checking wheel alignment

When equipment, attachments and bodies have been
mounted, it is recommended to have the toe setting
checked by a qualified specialist workshop. NAFTA
recommends a MITSUBISHI FUSO Service Center for
this work.

It is absolutely essential that all safety-relevant work
and all work on safety-relevant systems be performed
by a qualified specialist workshop.

i

Further details are available from any
MITSUBISHI FUSO Service Center.

41

3 Planning of bodies

3.11 Special equipment

i

MITSUBISHI FUSO body/equipment mounting directives for FE, FG  Issue date: 06. 07. 2012

!

 Only print out complete sections from the current version

3.11 Special equipment

MITSUBISHI FUSO recommends using equipment
available as option codes to adapt the vehicle to the
body optimally.

All code-specific special equipment is available from
your MITSUBISHI FUSO authorized dealer or from
body manufacturer advisors

컄 page 15.

Optional equipment (e.g. , auxiliary tanks, toolboxes,
etc.) or retrofitted equipment increases the unladen
weight of the vehicle.

When chassis are fitted with bodies or accessory
equipment, the frame height can change considerably
in both the laden and unladen state.

The actual vehicle weight and axle loads must be
determined by weighing before mounting.

Not all optional equipment can be installed in any
vehicle without problems. This applies, in particular,
for retrofitted equipment because the installation
space may already be occupied by other components
or the special equipment may require other
components.

If the current value falls outside the specified range
when body building and modification work are
performed for electrical parts, a fault is detected,
causing a warning lamp to go on and remain on or a
function not to operate.
• If an electrical part is to be added or a lamp is to be

replaced with an LED lamp, the current value of the
electrical part should be ensured to fall within a
specified range. This is, however, does not
guarantee that the electrical part to be mounted
will be fully operational when its current value falls
within the specified range.

• For the specified current value, ask your

MITSUBISHI FUSO Service Center or body
manufacturer advisors

컄 page 15.

• Some electrical parts to be mounted require that

the SAM control unit parameters be changed. For
the electrical parts to be mounted, see "5.1.1
Signal detection and actuation module-related
parts"

컄 page 53.

Ask your MITSUBISHI FUSO Service Center.

• When adding or replacing a lighting unit, be sure to

mount one that complies with the applicable laws
and regulations, and observe the regulations
governing visibility.

a

Risk of accident and injury

The use of parts, assemblies or conversion parts
and accessories which have not been approved
may jeopardize the safety of the vehicle.

Before installing any attachments, special-purpose
bodies, equipment or carrying out any
modifications to the basic vehicle and/or its
assemblies, you must read the relevant sections of
the vehicle Owner's Manual, as well as the
operating and assembly instructions issued by the
manufacturer of the accessories and items of
optional equipment.

You could otherwise fail to recognize dangers,
which could result in injury to yourself or others.

B

42

4.1 Vehicle overhang and technical wheelbases

MITSUBISHI FUSO body/equipment mounting directives for FE, FG  Issue date: 06. 07. 2012

!

 Only print out complete sections from the current version

i

4.1 Vehicle overhang and technical wheelbases

• When calculating the length of the vehicle

overhang, always take into account the permissible
axle loads and the minimum front axle load.

• Comply with the minimum front axle load

컄 page 45.

• Take the weight of special equipment into

consideration when making calculations.

4 Technical threshold values for planning

a

Risk of accident

The body must be designed in such a way that
placement of excessive load weight at the rear is
prevented. It is important to comply with the points
listed below, otherwise the necessary steering and
braking forces for safe vehicle operation cannot be
transferred to the road.

43

4 Technical threshold values for planning

4.1 Vehicle overhang and technical wheelbases

MITSUBISHI FUSO body/equipment mounting directives for FE, FG  Issue date: 06. 07. 2012

!

 Only print out complete sections from the current version

i

4.1.1

Maximum vehicle overhangs

Van body: Body that fully encloses payload and does
permit payload to protrude at the rear of vehicle

Example: Van body, lorry, etc.

i

All federal, state, and local regulations codes, and
registration requirements must be complied with.
