GARNISHES AND MOLDINGS
EXTERIOR
51-10
2. Scrape off the double-sided tape with a resin spatula as
much as possible.
3. Peel off the protection tape.
4. Use a shop towel moistened with 3M
™ AAD Part number
8906 or equivalent to wipe the body.
.
<Remove double-sided tape remaining on SIDE PROTECTOR
MOLDING/ROOF DRIP MOLDING and adhere double-sided
tape (when re-using SIDE PROTECTOR MOLDING/ROOF
DRIP MOLDING)>
1. Scrape off the double-sided tape on the side protector
molding with a resin spatula as much as possible.
2. Use a shop towel moistened with 3M
™ AAD Part number
8906 or equivalent to wipe the side protector molding
surface.
3. Remove only a small portion of the residual adhesive.
4. Apply primer to adherence area of the side protector
molding, then adhere the double-sided tape as specified on
the side protector molding (Refer to double-sided tape
adherence location ).
INSTALLATION SERVICE POINT
.
>>A<< SIDE PROTECTOR MOLDING/ROOF DRIP
MOLDING INSTALLATION.
1. Tear off the double-sided tape backing paper.
NOTE: If you attach the adhesive tape to the edge of the
backing paper, it will be easy to tear off.
2. Install the side protector molding/roof drip molding.
NOTE: If the double-sided tape is difficult to affix in cold tem-
perature, etc., warm the bonding surfaces of the body and
side protector molding to about 40
− 60°C (104 − 140°F)
before affixing the tape.
3. Firmly press in the side protector molding.
AC000421
DOUBLE-SIDED TAPE
AB
AC000422
AC000657
