REAR SEAT CUSHION TRIM COVER

INTERIOR

52A-48

4. Pull draw string and attach to the centre wire as shown.

5. Reattach all outer points.

6. Work the trim into all the grooves and adjust if necessary to

remove creases as shown.

19DB038A

TRIM COVER AND DRAW
STRING ATTACHED TO
THESE WIRES

19DB039A

CUSHION PAD

SEAT TRIM

19DB040A

REAR SEAT BACK TRIM COVER

INTERIOR

52A-49

REAR SEAT BACK TRIM COVER

REMOVAL AND  FITMENT

REAR SEAT BACK TRIM REMOVAL

.

1. Remove rear seat back from the vehicle, and remove arm

rest and arm rest pivot bushes from rear seat back.

2. Release the draw string.

3. Release all outer attachment points. Release all the centre

clips.

19DB041A

19DB042A

Release all clips around
arm rest hole

Release trim from
all outer attachments

REAR SEAT BACK TRIM COVER

INTERIOR

52A-50

4. Peel cover away from the foam pad.

NOTE: Place a finger on the Blue Velcro strip when peeling
the cover to prevent the strip being pulled out of the foam
pad.

Blue Velcro Strip

19DB034A

Seat Trim Cover

REAR SEAT BACK TRIM COVER

INTERIOR

52A-51

REAR SEAT BACK TRIM FITMENT

.

1. Fit the trim over the lower wire brackets.

2. Locate the new trim onto the pad by aligning the Velcro strip

with the grooves. Use an intersection in order to align both
directions. Whenever possible work from the centre of the
trim toward the outside.

3. When all the grooves are aligned pull the cover over the

pad.

19DB043A

LOWER WIRE BRACKET

Intersection

Cushion

Seat
Trim

velcro

Blue strips
in grooves

19DB044A

Cushion
Pad

Seat Trim
Cover

19DB045A
