SERVICE SPECIFICATIONS AUTOMATIC TRANSMISSION (FF) 23A-3 SERVICE SPECIFICATIONS M1231000300412 LUBRICANTS M1231000400475 Item Standard value A/T fluid temperature sensor resistance k Ω At 0 °C 16.7 − 20.5 At 20 °C 7.3 − 8.9 At 40 °C 3.4 − 4.2 At 60 °C 1.9 − 2.2 At 80 °C 1.0 − 1.2 At 100 °C 0.57 − 0.69 Damper clutch control (DCC) solenoid valve coil resistance (at 20 °C) Ω 2.7 − 3.4 Low & reverse (LR) solenoid valve coil resistance (at 20 °C) Ω 2.7 − 3.4 Second (2ND) solenoid valve coil resistance (at 20 °C) Ω 2.7 − 3.4 Underdrive (UD) solenoid valve coil resistance (at 20 °C) Ω 2.7 − 3.4 Overdrive (OD) solenoid valve coil resistance (at 20 °C) Ω 2.7 − 3.4 Stall speed r/min 2,300 − 2,800 Line pressure MPa 1,01 − 1,05 Item Specified lubricants Capacity L A/T fluid DIA QUEEN ATF SP III 7.7 |
