Mitsubishi Grandis. Manual - part 355

COMBINATION METER

CHASSIS ELECTRICAL

54A-39

Step 4. Check the wiring harness between fuel
tank pump and gauge unit assembly connector
D-15 (terminal 1) and earth.

NOTE:

Also check intermediate connector D-28, C-16 for
loose, corroded, or damaged terminals, or terminals
pushed back in the connector. If intermediate
connector D-28, C-16 are damaged, repair or
replace the connector.

Q: Is the wiring harness between fuel tank pump and

gauge unit assembly connector D-15 (terminal 1)
and earth in good condition?

YES :

Go to Step 11.

NO :

Repair the harness, and then go to Step 11.

AC310207

AG

Connector: D-15

D-15 (GR)

Harness side

AC310615

AE

Connector: C-16 <LHD>

AC310631 AD

Connector: C-16 <RHD>

AC310633AE

Connector: D-28 <LHD>

AC310205

AE

Connector: D-28 <RHD>

COMBINATION METER

CHASSIS ELECTRICAL

54A-40

Step 5. Connector check: Combination meter
connector C-02 and fuel gauge unit connector
D-07.

Q: Is combination meter connector C-02 and fuel

gauge unit connector D-07 in good condition?

YES :

Go to Step 6.

NO :

Repair the connector, and then go to Step
10.

AC310613

AX

Connector: C-02 <LHD>

Harness side

40

20

28

8

34

14

37

17

38

39

1918

35

36

1615

31

11

33

13

32

12

30

10

29

9

23

3

27

7

26

6

24

4

25

5

21

1

22

2

AC310631AU

Connector: C-02 <RHD>

Harness side

40

20

28

8

34

14

37

17

38

39

1918

35

36

1615

31

11

33

13

32

12

30

10

29

9

23

3

27

7

26

6

24

4

25

5

21

1

22

2

AC310633AF

Connector: D-07 <LHD>

Harness side

AC310205

AF

Harness side

Connector: D-07 <RHD>

COMBINATION METER

CHASSIS ELECTRICAL

54A-41

Step 6. Check the wiring harness between
combination meter connector C-02 (terminal 31)
and fuel gauge unit connector D-07 (terminal 1).

COMBINATION METER

CHASSIS ELECTRICAL

54A-42

NOTE:

Also check intermediate connectors C-16, D-28 for
loose, corroded, or damaged terminals, or terminals
pushed back in the connector. If intermediate
connector C-16, D-28 are damaged, repair or
replace the connector.

Q: Is the wiring harness between combination meter

connector C-02 (terminal 31) and fuel gauge unit
connector D-07 (terminal 1) in good condition?

YES :

Go to Step 7.

NO :

Repair the harness, and then go to Step 10.

AC310613

AX

Connector: C-02 <LHD>

Harness side

40

20

28

8

34

14

37

17

38

39

1918

35

36

1615

31

11

33

13

32

12

30

10

29

9

23

3

27

7

26

6

24

4

25

5

21

1

22

2

AC310631AU

Connector: C-02 <RHD>

Harness side

40

20

28

8

34

14

37

17

38

39

1918

35

36

1615

31

11

33

13

32

12

30

10

29

9

23

3

27

7

26

6

24

4

25

5

21

1

22

2

AC310634AC

Connectors: D-07, D-28 <LHD>

Harness side

D-07

D-28

D-07

D-28

AC310206

AD

Connectors: D-07, D-28 <RHD>

Harness side

D-07

D-28

D-07

D-28

AC310615

AE

Connector: C-16 <LHD>

AC310631 AD

Connector: C-16 <RHD>
