INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-18

INSTRUMENT PANEL <RHD> (CONTINUED)

AC509451

Connector
symbol

-201
thru
-220

C

C-201

C-202

C-203

C-204

C-205

C-206

C-207

C-208

C-209

C-210

C-211

C-212

C-213

C-214

C-215

C-217

<J/B (Front view) >

C-218

C-220

C-219

<J/B (Rear view) >

AC

C-216

C-201 (4)

Blower relay

C-202 (4)

Accessory socket relay

C-203 (4)

Heated seat relay

C-204 (10)

Instrument panel wiring harness and
J/B combination

C-205 (4)

No connection

C-206 (4)

Roof wiring harness and J/B
combination

C-207 (6)

Instrument panel wiring harness and
J/B combination

C-208 (14)

Instrument panel wiring harness and
J/B combination

C-209 (8)

Instrument panel wiring harness and
J/B combination

C-210 (13)

Front wiring harness and J/B
combination

C-211 (10)

Front wiring harness and J/B
combination

C-212 (4)

Floor wiring harness and J/B
combination

C-213 (1)

Front wiring harness and J/B
combination

C-214 (4)

No connection

C-215 (4)

Rear fog lamp relay

C-216 (4)

No connection

C-217 (4)

Rear window defogger relay

C-218 (20)

ETACS-ECU

C-219 (24-GR) ETACS-ECU
C-220 (24)

ETACS-ECU

INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-19

INSTRUMENT PANEL <RHD> (CONTINUED)

ACB01367AB

C-302

C-301

C-307

Y

C-306

C-305

Instrument panel
wiring harness

Steering sub
wiring harness

Clock
spring

<Steering column>

Steering
switch earth

Connector
symbol

-301
thru
-312

C

C-310

C-308

C-303

C-304

C-309

C-311

Connector colour
code
B : Black
BR : Brown
G : Green
GR : Grey
L : Blue
None : Milk white
O : Orange
R : Red
V : Violet
Y : Yellow

C-312

C-301 (7)

Key reminder switch

C-302 (10)

Column switch

C-303 (2)

Driver’s air bag module (squib)

C-304 (1)

Horn switch

C-305 (4-Y)

Clock spring

C-306 (6-B)

Clock spring

C-307 (6)

Ignition switch

C-308 (5)

Steering wheel sensor <ASTC>

C-309 (4-L)

Cruise control switch

C-310 (5-B)

Clock spring and steering sub wiring
harness combination

C-311 (5-R)

Steering wheel audio remote control
switch

C-312 (4)

Steering wheel voice control switch

FLOOR AND ROOF

CONFIGURATION DIAGRAMS

80-20

FLOOR AND ROOF

FLOOR AND ROOF <SINGLE CAB>

M1801000904761

AC903682

Connector
symbol

D

Roof
wiring harness

D-23

D-10

D-01

D-25

Floor wiring
harness

D-07

D-19

Frame wiring
harness

D-06

D-04

D-02

D-15

D-13

Rear window
defogger earth

<LHD>

Roof
wiring harness

D-23

D-10

D-26

Floor wiring
harness

D-07

D-19

Frame wiring
harness

AB

D-06

D-04

D-02

D-15

D-13

Rear window
defogger earth

D-01

<RHD>

15

16

12

17

15

16

12

17

D-01

(3)

Door switch (front: RH)

D-02

(4)

Clock

D-04

(2)

Accessory socket

D-06

(2)

Rear room lamp

D-07

(1-B)

Rear window defogger (+)

D-10

(1-B)

Rear window defogger (-)

D-13

(3)

Door switch (front: LH)

D-15

(2-B)

Seat belt pre-tensioner (LH)

D-19

(1-B)

Parking brake switch <Lever type>

D-23

(2-B)

Seat belt pre-tensioner (RH)

D-25

(2)

Seat belt switch (LH)

D-26

(2)

Seat belt switch (RH)

FLOOR AND ROOF <CLUB CAB>

M1801000905645

ACB01368

Connector
symbol

D

D-17

Floor wiring
harness

D-29

D-19

Frame wiring
harness

D-37

D-39

D-25

<LHD>

D-21

D-07

D-35

D-20

D-36

D-23

D-01

D-10

Roof
wiring harness

15

16

12

17

D-17

Floor wiring
harness

D-19

Frame wiring
harness

AB

<RHD>

D-35

D-39

D-10

D-06

D-40

D-02

D-38

D-13

D-34

D-15

D-13

D-34

D-15

D-06

D-07

D-41

D-28

D-02

D-01

D-29

D-03

D-04

Rear window
defogger earth

12

15

16

17

Rear window
defogger earth

D-23

D-40

D-37

D-04

D-20

D-36

D-38

D-21

D-26

D-03 D-28 D-41

D-01

(3)

Door switch (front: RH)

D-02

(4)

Clock

D-03

(2)

Front room lamp

D-04

(2)

Accessory socket

D-06

(2-GR)

Rear room lamp

D-07

(1-B)

Rear window defogger (+)

D-10

(1-B)

Rear window defogger (-)

D-13

(3)

Door switch (front: LH)

D-15

(2-B)

Seat belt pre-tensioner (LH)

D-17

(3)

Heated seat (LH)

D-19

(1-B)

Parking brake switch

D-20

(2)

Power seat assembly (Driver’s side)

FLOOR AND ROOF

CONFIGURATION DIAGRAMS

80-21

FLOOR AND ROOF <DOUBLE CAB>

M1801000905656

ACB01369

Connector
symbol

D

D-40

D-09

D-37

D-26

D-17

Floor wiring
harness

D-28

D-19

Frame wiring
harness

D-06

D-02

D-04

D-34

D-14

<LHD>

D-21

D-30

D-07

D-35

D-20

D-39

D-31

D-38

D-01

D-13

D-11

D-12

D-03

D-05

D-29

D-08

D-10

Roof
wiring harness

D-09

D-23

D-26

D-25

Floor wiring
harness

D-28

D-04

Frame wiring
harness

AB

D-05

D-02

D-03

D-34

D-14

<RHD>

D-36

D-40

D-07

D-35

D-39

D-38

D-24

D-01

D-13

D-11

D-12

D-06

D-41

D-08

D-10

Roof
wiring
harness

D-21

14

15

16

12

17

13

18

14

15

16

12

17

13

18

D-32

D-23

D-24

D-36

D-25

D-15

D-33

D-37

D-31

D-30

D-20

D-17

D-19

D-15

D-33

D-29

D-32

D-41

D-01

(3)

Door switch (front: RH)

D-02

(4)

Clock

D-03

(2)

Front room lamp

D-04

(2)

Accessory socket

D-05

(3)

Door switch (rear: RH)

D-06

(2-GR)

Rear room lamp <without sunroof>

D-07

(1-B)

Rear window defogger (+) <without
rear panel power window>

D-08

(2)

Rear window defogger <with rear
panel power window>

D-09

(6-B)

Rear panel power window motor

D-10

(1-B)

Rear window defogger (-) <without
rear panel power window>

D-11

(18)

Rear panel power window-ECU

D-12

(3)

Door switch (rear: LH)

D-13

(3)

Door switch (front: LH)

D-14

(12)

Floor wiring harness and rear door
wiring harness (LH) combination

D-15

(2-B)

Seat belt pre-tensioner (LH)

D-17

(3)

Heated seat (LH)

D-19

(1-B)

Parking brake switch

D-20

(2)

Power seat assembly (Driver’s side)

D-21

(3)

Heated seat (RH)

D-23

(2-B)

Seat belt pre-tensioner (RH)

D-24

(12)

Floor wiring harness and rear door
wiring harness (RH) combination

D-25

(2)

Seat belt switch (LH)

D-26

(2)

Seat belt switch (RH)

D-28

(10)

Sunroof motor assembly

D-29

(6-B)

Sunroof switch

D-30

(18)

Audio amplifier

D-31

(18)

Audio amplifier

D-32

(2-B)

Curtain air bag module (squib) (RH)

D-33

(2-B)

Curtain air bag module (squib) (LH)

D-34

(2-Y)

Side impact sensor (LH)

D-35

(2-Y)

Side-airbag module (squib) (LH)

D-36

(2-Y)

Side-airbag module (squib) (RH)

D-37

(2-Y)

Side impact sensor (RH)

D-38

(4)

Lighting control sensor <Vehicles with
auto lamp>

D-39

(6)

Floor wiring harness and AUX adapter
wiring harness combination

D-40

(6)

Audio adapter and audio and video
adapter

D-41

(3)

Microphone unit

D-21

(3)

Heated seat (RH)

D-23

(2-B)

Seat belt pre-tensioner (RH)

D-25

(2)

Seat belt switch (LH)

D-26

(2)

Seat belt switch (RH)

D-28

(10)

Sunroof motor assembly

D-29

(6-B)

Sunroof switch

D-34

(2-Y)

Side impact sensor (LH)

D-35

(2-Y)

Side-airbag module (squib) (LH)

D-36

(2-Y)

Side-airbag module (squib) (RH)

D-37

(2-Y)

Side impact sensor (RH)

D-38

(4)

Lighting control sensor <Vehicles with
auto lamp>

D-39

(6)

Floor wiring harness and AUX adapter
wiring harness combination

D-40

(6)

Audio adapter and audio and video
adapter

D-41

(3)

Microphone unit
