COMBINATION METER CHASSIS ELECTRICAL 54A-83 STEP 2. Check the diagnosis code of the engine- Q: Is the diagnosis code set? YES : Diagnose the engine-ECU (Refer to GROUP 13A − Troubleshooting . On completion, go to Step 4. NO : Go to Step 3. STEP 3. M.U.T.-III data list • Turn the ignition switch to the "ON" position. • Remove the each inserted seatbelt. OK: Normal conditions are displayed for all Q: Is the check result normal? YES <All the signals are received normally.> : Go to Step 4. NO <The seat belt switch signal is not received.> : Refer to inspection procedure C-6 "The seat
<L.H. drive vehicles> or <R.H. drive vehicles>." NO <The ignition switch (IG1) signal is not Refer to inspection procedure C-3 "The ignition switch (IG1) signal is not ." STEP 4. Check the combination meter Q: Does the combination meter work? YES : Go to Step 5. NO : Refer to symptom procedure 1 "Power STEP 5. Connector check: C-113 combination Q: Is the check result normal? YES : Go to Step 6. NO : Repair the defective connector. Item Item name Normal condition 30 Ignition switch(IG1) ON 50 Driver’s Being turned ON 51 Passenger AC903856 Harness side BH Connector: C-113 <LHD> AC903868 Harness side BY Connector: C-113 <RHD> AC509934 Connector: C-219 <LHD> AD C-219 (GR) Harness side Junction block AC509943 Connector: C-219 <RHD> AB C-219 (GR) Harness side Junction block |
