Mitsubishi L200. Manual - part 580





FRONT SEAT ASSEMBLY

INTERIOR

52A-26

<BENCH SEAT>

AC509460AC

5

11

4

3

10

9

N

N

7

1

6

2

8

Disassembly steps

1.

Front seat cushion assembly

2.

Hog ling

3.

Front seat cushion cover

4.

Front seat cushion pad

5.

Inner seat cushion frame

6.

Front seatback assembly

<<

A

>>

7.

Headrestraint guide

8.

Front seatback cover

9.

Hog ling

10. Front seatback pad
11. Front seatback frame

DISASSEMBLY SERVICE POINT

<<A>> HEADRESTRAINT GUIDE REMOVAL

AC205342

Remove the headrest guides while pushing the on
both sides inward.

INSPECTION

M1522001400608

POWER SEAT SWITCH CONTINUITY
CHECK

AC507447AB

Connect the (+) terminal of the battery to the power
seat connector terminal No.2 and the (

−) terminal to

terminal No.1, and check that the power seat works
normally.

FRONT SEAT ASSEMBLY

INTERIOR

52A-27

HEATED SEAT RELAY CONTINUITY
CHECK

AC510001

4

3

2

1

AB

Seat heater relay

Junction block

Battery voltage Tester

connection

Specified
condition

Not applied

− 4

Open circuit

• Connect

terminal 2 to
the positive
battery
terminal

• Connect

terminal 1 to
the negative
battery
terminal

Continuity (Less
than 2

Ω)

HEATED SEAT SWITCH CONTINUITY
CHECK

5

2

4

1

6

3

AC501130

Inspect the heated seat switch for continuity.

Switch
position

Tester
connection

Specified
condition

Note

HI

− 2

Continuity
(Less than

Ω)

2(+)

− 6(−)

Indicator

− 4

Illumination

OFF

− 4

Illumination

LOW

− 5

2(+)

− 6(−)

Indicator

− 4

Illumination

SEAT CUSHION HEATER CHECK

AC509808

Connector 2

Connector 2-1

AB

Measure the resistance between the terminals.

Standard value (At room temperature 20

°C):

Connector, terminal No.

Specified condition

Connector 2, terminal 3

−

Connector 2

− 1, terminal 1

3.79

− 4.53 Ω

Connector 2, terminal 1

−

Connector 2

− 1, terminal 1

3.98

− 4.76 Ω

Connector 2, terminal 3

−

Connector 2, terminal 1

0.22

− 0.26 Ω

SEATBACK HEATER CHECK

AC509810AB

Measure the resistance between the terminals.

Standard value (At room temperature 20

°C):

Tester connection

Specified condition

− 2

5.01

− 6.00 Ω

REAR SEAT ASSEMBLY <CLUB CAB, DOUBLE CAB>

INTERIOR

52A-28

REAR SEAT ASSEMBLY <CLUB CAB, DOUBLE CAB>

REMOVAL AND INSTALLATION

M1522001801007

<CLUB CAB>

ACA01331

1

2

1

2

5

2

2

3

1

4

22 ± 4 N·m

22 ± 4 N·m

22 ± 4 N·m

22 ± 4 N·m

AC

22 ± 4 N·m

Removal steps

1.

Rear seat hinge cover outer

2.

Rear seat hinge cover inner

3.

Rear seat cushion assembly

4.

Rear seatback assembly

>>

A

<<

5.

Headrestraint

Removal steps (Continued)

REAR SEAT ASSEMBLY <CLUB CAB, DOUBLE CAB>

INTERIOR

52A-29

<DOUBLE CAB>

AC509494AB

1

1

3

2

44 ± 10 N·m

30 ± 5 N·m

20 ± 4 N·m

30 ± 5 N·m

1

1.

Headrestraint
Removal steps

2.

Rear seat back assembly

3.

Rear seat cushion assembly

INSTALLATION SERVICE POINT

ACA01403

1

2

2

AB

>>A<< HEADRESTRAINT INSTALLATION (CLUB
CAB)
Tighten the bolts in the order shown in the figure.
