Mitsubishi L200. Manual - part 553

MUD GUARD

EXTERIOR

51-28

MUD GUARD

REMOVAL AND INSTALLATION

M1511011200430

AC509793

AC501968

AB

Front mud guard

<Vehicles without overfender>

<Vehicles with overfender>

Rear mud guard

Claw

Section A – A

Rear
overfender

Rear
mud guard

A

A

SIDE STEP

EXTERIOR

51-29

SIDE STEP

REMOVAL AND INSTALLATION

M1511011500378

AC501160

AC501166

A

A

A

A

A

A

A

A

1

1

1

2

3

2

3

4

2

4

1

AC

<Double cab>

<Club cab>

Section A – A

Bolt

Nut

Screw

1

3

4

Removal steps
1. Step stay
2. Side step garnish

3. Side step cover
4. Side step plate

Removal steps (Continued)

ACA00451

A

A

3

2

3

AB

Section A – A

1

5

5

1

4

6

8

2

11 ± 2 N·m

11 ± 2 N·m

11 ± 2 N·m

5

5

7

7

4

N

N

N

N

N

N

A

A

A

A

8

8

2

6

N

N

5

N

<Double cab wide fender>

AC808295

AB

2

Double-sided tape affixed location

Double-sided tape:
Generic products, 8.0 mm width and 1.6 mm thickness

Removal steps
1. Side step pipe
2. Side step cover A

<<

A

>> >>

A

<< 3. Rivets A

4. Side step cap

<<

A

>> >>

A

<< 5. Rivets B

6. Side step plate
7. Side step cover B
8. Pad

SIDE STEP

EXTERIOR

51-30

Removal steps (Continued)

SIDE STEP

EXTERIOR

51-31

DISASSEMBLY SERVICE POINT

<<A>> RIVETS A/RIVETS B REMOVAL

AC100411AB

Rivet

Drill

Bumper face

Use a drill (

φ 4.0 mm) to make a hole in the rivet A

and rivet B to break it, and remove the rivet.

REASSEMBLY SERVICE POINT

>>A<< RIVETS A/RIVETS B INSTALLATION

AC203149
AC205918

AC801423

AB

1

2

3

4

Portion C

Rivet

Flange

Rivet

Rivet tool

Side step pipe

Rivet A

Rivet B

Unit: mm

Ø8.0

Ø8.0

Ø4.0

Ø4.1

Rivet tool

Use a rivet tool shown in the illustration to connect
the parts with rivets by the following procedures.
1. Insert rivet A into the side step pipe and side step

cap and rivet B into the side step pipe and side
step plate.

2. Place the rivet tool over portion C of rivet.
3. While pushing the flange surface of the rivet onto

parts to be fixed with the rivet tool, press the
handle of the tool.

4. Thin part of portion C of the rivet will cut off and

the rivet is fixed in position.
