Mitsubishi L200. Manual - part 549





REAR BUMPER ASSEMBLY

EXTERIOR

51-12

VEHICLES FOR MOROCCO (OPTIONAL)

ACB01698

2

1

38 ± 12 N·m

37 ± 14 N·m

3

38 ± 12 N·m

2

37 ± 14 N·m

AB

Removal steps

Licence plate lamp(Refer to .

1. Rear step bumper assembly
2. Rear bumper side bracket
3. Rear bumper plate

DISASSEMBLY AND REASSEMBLY

M1511002101063

VEHICLES FOR EUROPE AND RUS-
SIA(OPTIONAL)

ACB01724 AB

2

1

1

3

Removal steps
1. Rear corner bumper
2. Rear bumper face support

reinforcement

3. Rear bumper step plate

RADIATOR GRILLE

EXTERIOR

51-13

VEHICLES FOR MOROCCO (OPTIONAL)

ACB01723 AB

5

5

8

6

6

7

1

1

4

4

2

2

7

3

Disassembly steps

Licence plate lamp(Refer to .

1. Rear bumper step plate
2. Rear bumper weatherstrip
3. Rear bumper mud guard

4. Rear bumper protector
5. Rear side bumper
6. Rear step bumper reinforcement
7. Rear step bumper stay assembly
8. Rear centre bumper

RADIATOR GRILLE

ADHESIVE

M1511000501292

Application

Specified adhesive

Front three-diamond mark

Double-sided tape: Generic products, 1.2 mm thickness

Disassembly steps (Continued)

RADIATOR GRILLE

EXTERIOR

51-14

REMOVAL AND INSTALLATION

M1511002901263

AC808687

Double-sided tape (when mark reused)

3

1

AD

Section A – A

Front bumper

2

1

Claw

A

A

2

Adhesive tape: Double-sided tape
Generic products, 1.2 mm thickness

<Type 1>

<Type 2>

2

1

3

4

5

5.0 ± 1.0 N·m

5.0 ± 1.0 N·m

5.0 ± 1.0 N·m

5.0 ± 1.0 N·m

 :Claw positions

NOTE

View B

B

B

Removal steps

1. Radiator grille
2. Front three-diamond mark
3. Bracket

4. Radiator grille outer
5. Radiator grille inner

Removal steps (Continued)

AC902498

2

AB

1

E

<Type 3>

D

D

D

D

E

C

C

4

3

3

Front bumper

Section C – C

Section D – D

Section E – E

Front bumper

1

Clip

Claw

4

2

4

 :Clip positions (To radiator grille)

 :Clip position (To front bumper)

 :Claw positions (To front bumper)

Removal steps <Type 3>

1. Radiator grille assembly

<<

A

>>

2. Radiator grille weatherstrip mounting

clip

3. Radiator grille
4. Radiator grille weatherstrip

RADIATOR GRILLE

EXTERIOR

51-15

Removal steps <Type 3>
