A/T-ECU
AUTOMATIC TRANSMISSION
23A-143
A/T-ECU
REMOVAL AND INSTALLATION
M1231130200222
AC509596
3
1
AB
12 ± 2 N·m
5.0 ± 1.0 N·m
5
4
2
<LHD>
<RHD>
Removal steps
•
Driver’s side under cover (Refer to
GROUP 52A, Instrument Panel
Assembly ).
1.
A/T-ECU connector connection
2.
A/T-ECU and A/T-ECU bracket
assembly
3.
Harness connection
4.
A/T-ECU bracket
5.
A/T-ECU
4WD INDICATOR-ECU
REMOVAL AND INSTALLATION
M1231119100015
Refer to GROUP 22A .
Removal steps (Continued)
