Customer Information and Reporting Safety Defects

Customer Assistance

concern may be reviewed and resolved

North York, Ontario

by an independent third party through

M2J 4Y8

binding arbitration.

http://camvap.ca

Provincial Administrators may be

Your complete satisfaction is the goal

reached locally:

of Mazda Canada Inc. and our dealers.

Province/Territory

CAMVAP Number

Mazda's participation in CAMVAP

makes a valuable contribution to our

British Columbia & Yu-

1 (800) 207-0685

achieving that goal. There is no charge

kon Territories

for using CAMVAP. CAMVAP results

Alberta & Northwest

1 (800) 207-0685

are fast, fair and final as the award is

Territories

binding on both you and Mazda

Saskatchewan

1 (800) 207-0685

Canada Inc.

Manitoba

1 (800) 207-0685

▼ Canadian Motor Vehicle

Ontario

1 (800) 207-0685

Arbitration Plan (CAMVAP)

Atlantic Canada

1 (800) 207-0685

If a specific item of concern arises,

Quebec

1 (800) 207-0685

where a solution cannot be reached

between an owner, Mazda, and/or

▼ Regional Offices

one of its dealers (that all parties

cannot agree upon), the owner may

REGIONAL OFFICES

COVERING AREAS

wish to use the services offered by the

MAZDA CANADA

Canadian Motor Vehicle Arbitration

INC.

Plan (CAMVAP).

WESTERN REGION

ALBERTA,

5011 275 STREET

BRITISH COLUMBIA,

CAMVAP uses the services of Provincial

LANGLEY, BRITISH

MANITOBA,

Administrators to assist consumers in

COLUMBIA

SASKATCHEWAN,

scheduling and preparing for their

V4W 0A8

YUKON

arbitration hearings. However, before

(778) 369-2100

you can proceed with CAMVAP you

1 (800) 663-0908

must follow your Mazda dispute

MAZDA CANADA

resolution process as outlined

ONTARIO,

INC.

previously.

NEW BRUNSWICK,

CENTRAL REGION

NOVA SCOTIA,

55 VOGELL ROAD,

CAMVAP is fully implemented in all

PRINCE EDWARD IS-

RICHMOND HILL,

provinces and territories.

LAND,

ONTARIO, L4B 3K5

Consumers wishing to obtain further

NEWFOUNDLAND

1 (800) 263-4680

information about the Program should

contact the Provincial Administrator at

1 (800) 207-0685, or by contacting

the Canadian Motor Vehicle

Arbitration Plan Office at:

Canadian Motor Vehicle Arbitration

Plan

235 Yorkland Boulevard, suite 300

8-7

Customer Information and Reporting Safety Defects

Customer Assistance

REGIONAL OFFICES

COVERING AREAS

Customer Assistance

MAZDA CANADA

(Puerto Rico)

INC.

QUEBEC REGION

▼ Customer Assistance

6111 ROUTE TRANS-

CANADIENNE

QUEBEC

Your complete and permanent

POINTE CLAIRE, QUE-

satisfaction is our business. That is why

BEC

all Authorized Mazda Dealers have the

H9R 5A5

knowledge and the tools to keep your

(514) 694-6390

Mazda vehicle in top condition.

If you have any questions or

recommendations for improvement

regarding the service of your Mazda

vehicle or servicing by Mazda Dealer

personnel, we recommend that you

take the following steps:

▼ STEP 1

Discuss the matter with an Authorized

Mazda Dealer. This is the quickest and

best way to address the issue. If your

concern has not been resolved by the

CUSTOMER RELATIONS, SALES,

SERVICE, or PARTS MANAGER, then

please contact the GENERAL

MANAGER of the dealership or the

OWNER.

▼ STEP 2

If, after following STEP 1, you feel the

need for further assistance, please

contact your area's Mazda

representative.

Refer to PUERTO RICO/U.S. Virgin

Island on page 8-10.

Please help us by providing the

following information:

1. Your name, address, and telephone

number

2. Year and model of vehicle

3. Vehicle Identification Number (17

digits, noted on your registration or

title or located on the upper

driver's side corner of the dash)

8-8

Customer Information and Reporting Safety Defects

Warranty

Warranties for Your

Outside the United

Mazda

States/Canada

▼ Warranties for Your Mazda

▼ Outside the United States/Canada

^ New Vehicle Limited Warranty

Government regulations in the United

^ Powertrain Limited Warranty

States/Canada require that

^ Safety Restraint System Limited

automobiles meet specific emission

Warranty

regulations and safety standards.

^ Anti-perforation Limited Warranty

Therefore, vehicles built for use in the

^ Federal Emission Control Warranty/

United States/Canada may differ from

California Emission Control Warranty

those sold in other countries.

^ Emission Defect Warranty

The differences may make it difficult or

^ Emission Performance Warranty

even impossible for your vehicle to

^ Emission Control Warranty

receive satisfactory servicing in other

^ Replacement Parts and Accessories

countries. We strongly recommend

Limited Warranty

that you NOT take your Mazda outside

^ Tire Warranty

the United States/Canada.

NOTE

United States

Warranty information varies depending

However, in the event that you are

on the country. Refer to the Warranty

moving to Canada permanently,

Booklet for detailed warranty

Mazda vehicles built for use in the

information.

United States could be eligible for

exportation to Canada with specific

vehicle modifications to comply with

the Canadian Motor Vehicle Safety

Standards (CMVSS).

Canada

However, in the event that you are

moving to the United States

permanently, Mazda vehicles built for

use in Canada could be eligible for

exportation to the United States with

specific vehicle modifications to

comply with the United States Federal

Motor Vehicle Safety Standards

(FMVSS).

NOTE

The above is applicable for a

permanent import/export situation

and not related to travelers on

vacation.

8-13

Customer Information and Reporting Safety Defects

Warranty

You may have the following problems

Registering Your Vehicle

if you do take your vehicle outside of

the United States/Canada:

in A Foreign Country

^ Proper repair facilities, tools, testing

(Except United States and

equipment, and replacement parts

Canada)

may not be available.

Please refer to your Manufacturer's

▼ Registering Your Vehicle in A

Warranty Booklet for more

Foreign Country

information.

Registering your vehicle in a foreign

country may be problematic

depending on whether it meets the

specific emission and safety standards

of the country in which the vehicle will

be driven. Consequently, your vehicle

may require modifications at personal

expense in order to meet the

regulations.

In addition, you should be aware of

the following issues:

Satisfactory vehicle servicing may be

difficult or impossible in another

country.

Parts, servicing techniques, and tools

necessary to maintain and repair your

vehicle may be unavailable.

There might not be an Authorized

Mazda Dealer in the country you plan

to take your vehicle.

The Mazda warranty is valid only in

certain countries.

8-14

Customer Information and Reporting Safety Defects

Warranty

result from the installation of add-on

Add-On Non-Genuine

non-genuine parts or accessories.

Parts and Accessories

▼ Add-On Non-Genuine Parts and

Accessories

Non-genuine parts and accessories for

Mazda vehicles can be found in stores.

These may fit your vehicle, but they are

not approved by Mazda for use with

Mazda vehicles. When you install

non-genuine parts or accessories, they

could affect your vehicle's

performance or safety systems; the

Mazda warranty doesn't cover this.

Before you install any non-genuine

parts or accessories, consult an

Authorized Mazda Dealer.

WARNING

Always consult an Authorized Mazda

Dealer before you install non-genuine

parts or accessories:

Improperly designed parts or

accessories could seriously affect your

vehicle's performance or safety

systems. This could cause you to have

an accident or increase your chances of

injuries in an accident.

Be very careful in choosing and

installing add-on electrical

equipment, such as mobile

telephones, two-way radios, stereo

systems, and car alarm systems:

Incorrectly choosing or installing

improper add-on equipment or

choosing an improper installer is

dangerous. Essential systems could be

damaged, causing air-bag (SRS)

activation, ABS/TCS/DSC inactivation,

or a fire in the vehicle.

Mazda assumes no responsibility for

death, injury, or expenses that may

8-15

Customer Information and Reporting Safety Defects

Cell Phones

Cell Phones Warning

▼ Cell Phones Warning

WARNING

Please comply with the legal

regulations concerning the use of

communication equipment in vehicles

in your country:

Use of any electrical devices such as

cell phones, computers, portable

radios, vehicle navigation or other

devices by the driver while the vehicle

is moving is dangerous. Dialing a

number on a cell phone while driving

also ties-up the driver's hands. Use of

these devices will cause the driver to

be distracted and could lead to a

serious accident. If a passenger is

unable to use the device, pull off the

right-of-way to a safe area before use.

If use of a cell phone is necessary

despite this warning, use a hands-free

system to at least leave the hands free

to drive the vehicle. Never use a cell

phone or other electrical devices while

the vehicle is moving and, instead,

concentrate on the full-time job of

driving.

8-16

Customer Information and Reporting Safety Defects

Uniform Tire Quality Grading System (UTQGS)

Uniform Tire Quality

WARNING

Grading System (UTQGS)

The traction grade assigned to this tire

is based on braking (straight ahead)

▼ Uniform Tire Quality Grading

traction tests and does not include

System (UTQGS)

acceleration cornering (turning),

hydroplaning, or peak traction

This information relates to the tire

characteristics.

grading system developed by the U.S.

National Highway Traffic Safety

▼ Temperature-A, B, C

Administration for grading tires by

tread wear, traction, and temperature

The temperature grades A (the

performance.

highest), B, and C, represent the tire's

resistance to the generation of heat

▼ Tread Wear

and its ability to dissipate heat when

tested under controlled conditions on

The tread wear grade is a comparative

a specified indoor laboratory test

rating based on the wear rate of the

wheel.

tire when tested under controlled

Sustained high temperature can cause

conditions on a specified government

the material of the tire to degenerate

test course.

and reduce tire life, and excessive

For example, a tire graded 150 would

temperatures can lead to sudden tire

wear one-and-a-half times as well on

failure.

the government course as a tire graded

100.

Grade C corresponds to a level of

performance which all passenger

The relative performance of tires

vehicle tires must meet under the

depends upon the actual conditions of

Federal Motor Vehicle Safety Standard

their use, however, and may depart

No. 109. Grades B and A represent

significantly from the norm because of

higher levels of performance on the

variations in driving habits, service

laboratory test wheel than the

practices and differences in road

minimum required by law.

characteristics and climate.

▼ Traction-AA, A, B, C

The traction grades, from highest to

lowest, are AA, A, B, and C. These

grades represent the tire's ability to

stop on wet pavement as measured

under controlled conditions on

specified government test surfaces of

asphalt and concrete. A tire marked C

may have poor traction performance.

8-19

Customer Information and Reporting Safety Defects

Uniform Tire Quality Grading System (UTQGS)

TREADWEAR 200 TRACTION AA

WARNING

TEMPERATURE A

UTQGS MARK (example)

Keep your vehicle's tires properly

inflated and not overloaded:

Driving with improperly inflated or

overloaded tires is dangerous.

Excessive speed, underinflation, or

excessive loading, either separately or

in combination, can cause heat

buildup and possible tire failure. The

temperature grade for this tire is

established for a tire that is properly

inflated and not overloaded.

These grades will be added to the

sidewalls of passenger vehicle tires

over the next several years according to

a schedule established by the NHTSA

and the tire manufacturers.

The grade of tires available as standard

or optional equipment on Mazda

vehicles may vary with respect to

grade.

ALL PASSENGER VEHICLE TIRES MUST

CONFORM TO THESE GRADES AND

TO ALL OTHER FEDERAL TIRE-SAFETY

REQUIREMENTS.

▼ UNIFORM TIRE QUALITY

GRADING

Quality grades can be found where

applicable on the tire sidewall

between tread shoulder and maximum

section width.

For example:

8-20

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

14.Max. permissible inflation pressure

Tire Labeling

P215/65R15 95H is an example of a

▼ Tire Labeling

tire size and load index rating. Here is

Federal law requires tire manufacturers

an explanation of the various

to place standardized information on

components of that tire size and load

the sidewall of all tires. This

index rating. Note that the tire size and

information identifies and describes

load index rating may be different from

the fundamental characteristics of the

the example.

tire and also provides a tire

P

identification number for safety

standard certification and in case of a

Indicates a tire that may be installed on

recall.

cars, SUVs, minivans and light trucks as

designated by the Tire and Rim

▼ Information on Passenger Vehicle

Association (T&RA).

Tires

NOTE

Please refer to the sample below.

If your tire size does not begin with a

letter this may mean it is designated by

either ETRTO (European Tire and Rim

Technical Organization) or JATMA

(Japan Tire Manufacturing

Association).

215

“215” is the nominal width of the tire

in millimeters. This three-digit number

gives the width in millimeters of the

tire from sidewall edge to sidewall

edge. In general, the larger the

1. SAFETY WARNING

number, the wider the tire.

2. Passenger car tire

3. Nominal width of tire in millimeters

65

4. Ratio of height to width (aspect

“65” is the aspect ratio. This two-digit

ratio)

number indicates the tire's ratio of

5. Radial

height to width.

6. Run-flat tire

7. Rim diameter code

R

8. TIN: U.S. DOT tire identification

“R” is the tire construction symbol. R

number

indicates “Radial ply construction”.

9. Load index & speed symbol

10.Severe snow conditions

15

11.Tire ply composition and materials

“15” is the wheel rim diameter in

used

inches.

12.Max. load rating

13.Tread wear, traction and

temperature grades

8-21

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

95

the 45st week of 1997. After 2000 the

numbers go to four digits. For

“95” is the Load Index. This two-or

example, the number 2102 means the

three-digit number indicates how

21th week of 2002. The other

much weight each tire can support.

numbers are marketing codes used at

H

the manufacturer's discretion. This

information is used to contact

“H” is the speed rating. The speed

consumers if a tire defect requires a

rating denotes the maximum speed for

recall.

which the use of the tire is rated.

Tire Ply Composition and Materials

Letter Rating

Speed Rating

Used

Q

99 mph

The number of plies indicates the

R

106 mph

number of layers of rubber-coated

S

112 mph

fabric in the tire. In general, the greater

the number of plies, the more weight a

T

118 mph

tire can support. Tire manufacturers

U

124 mph

also must indicate the tire materials,

H

130 mph

which include steel, nylon, polyester,

and other.

V

149 mph

W

168^* mph

Maximum Load Rating

Y

186^* mph

This number indicates the maximum

load in kilograms and pounds that can

^* For tires with a maximum speed capability over

be carried by the tire.

149 mph, tire manufacturers sometimes use the

Maximum Permissible Inflation

letters ZR. For tires with a maximum speed

Pressure

capability over 186 mph, tire manufacturers

always use the letters ZR.

This number is the greatest amount of

air pressure that should ever be put in

M+S or M/S: Mud and Snow

the tire under normal driving

AT: All Terrain.

conditions.

AS: All Season. The “M+S” or “M/S”

Tread Wear, Traction and Temperature

indicates that the tire has some

Grades

functional use in mud and snow.

Tread wear: The tread wear grade is a

U.S. DOT Tire Identification Number

comparative rating based on the wear

(TIN)

rate of the tire when tested under

This begins with the letters “DOT”

controlled conditions on a specified

which indicates the tire meets all

government test course. For example,

federal standards. The next two

a tire graded 150 would wear one and

numbers or letters are the plant code

one-half (1 1/2) times as well on the

where it was manufactured, and the

government course as a tire graded

last four numbers represent the week

100.

and year the tire was manufactured.

Traction: The traction grades, from

For example, the numbers 457 means

highest to lowest are AA, A, B, and C.

8-22

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

The grades represent the tire's ability

▼ Information on Temporary Tires

to stop on wet pavement as measured

Please refer to the sample below.

under controlled conditions on

specified government test surfaces of

asphalt and concrete. A tire marked C

may have poor traction performance.

Temperature: The temperature grades

are A (the highest), B and C,

representing the tire's resistance to the

generation of heat and its ability to

dissipate heat when tested under

controlled conditions on a specified

indoor laboratory test wheel.

Snow Tires

1. Temporary tires

In some heavy snow areas, local

2. Nominal width of tire in millimeters

governments may require true snow

3. Ratio of height to width (aspect

tires, those with very deeply cut tread.

ratio)

These tires should only be used in pairs

4. Diagonal

or placed on all four wheels. Make

5. Rim diameter code

sure you purchase snow tires that are

6. Load index & speed symbol

the same size and construction type as

the other tires on your vehicle.

T115/70D16 90M is an example of a

SAFETY WARNING

tire size and load index rating. Here is

an explanation of the various

The following safety warning appears

components of that tire size and load

on the tire's sidewall.

index rating. Note that the tire size and

SERIOUS INJURY MAY RESULT FROM:

load index rating may be different from

^ EXPLOSION OF TIRE/RIM ASSEMBLY

the example.

DUE TO IMPROPER

T

MOUNTING-MATCH TIRE

DIAMETER TO RIM DIAMETER;

Indicates a tire that may be installed on

NEVER EXCEED 40 psi (275 kPa) TO

cars, SUVs, minivans and light trucks as

SEAT BEADS-ONLY SPECIALLY

designated by the Tire and Rim

TRAINED PERSONS SHOULD

Association (T&RA).

MOUNT TIRES.

115

^ TIRE FAILURE DUE TO

UNDER-INFLATION/

“115” is the nominal width of the tire

OVERLOADING/DAMAGE-FOLLOW

in millimeters. This three-digit number

OWNER'S MANUAL AND PLACARD

gives the width in millimeters of the

IN VEHICLE-FREQUENTLY CHECK

tire from sidewall edge to sidewall

INFLATION PRESSURE AND INSPECT

edge. In general, the larger the

FOR DAMAGE.

number, the wider the tire.

8-23

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

70

Location of the Tire Label

“70” is the aspect ratio. This two-digit

(Placard)

number indicates the tire's ratio of

height to width.

▼ Location of the Tire Label (Placard)

D

You will find the tire label containing

“D” is the tire construction symbol. D

tire inflation pressure by tire size and

indicates “diagonal ply construction”.

other important information on the

driver's side B-pillar or on the edge of

16

the rear door on the driver's side.

“16” is the wheel rim diameter in

SAMPLE

inches.

90

“90” is the Load Index. This two-or

three-digit number indicates how

much weight each tire can support.

M

“M” is the speed rating. The speed

rating denotes the maximum speed for

▼ Recommended Tire Inflation

Pressure

which the use of the tire is rated.

On the tire label you will find the

Letter Rating

Speed Rating

recommended tire inflation pressure in

M

81 mph

both kPa and psi for the tires installed

as original equipment on the vehicle. It

is very important that the inflation

pressure of the tires on your vehicle is

maintained at the recommended

pressure. You should check the tire

pressure regularly to insure that the

proper inflation pressure is maintained.

Refer to Tires on page 9-5.

NOTE

Tire pressures listed on the vehicle

placard or tire information label

indicate the recommended cold tire

inflation pressure, measured when the

tires are cold, after the vehicle has

been parked for at least 3 hours. As

you drive, the temperature in the tire

warms up, increasing the tire pressure.

8-24

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

road when it's mounted on the

Tire Maintenance

vehicle.

▼ Tire Maintenance

Seating capacity means the total

allowable number of vehicle

Improper or inadequate vehicle

occupants. Seating capacity is

maintenance can cause tires to wear

described on the tire label.

abnormally. Here are some important

maintenance points:

Production options weight is the

▼ Tire Inflation Pressure

combination weight of installed regular

production options weighing over 2.3

Inspect all tire pressure monthly

kilograms in excess of the standard

(including the spare) when the tires are

items which they replace, and not

cold. Maintain recommended

previously considered in the curb

pressures for the best ride, top

weight or accessory weight, including

handling, and minimum tire wear. Use

heavy duty brakes, ride levelers, roof

the pressures specified on the vehicle

rack, heavy duty battery, and special

tire information placard or tire label for

trim.

optimum service.

▼ Tire Rotation

Rim is the metal support (wheel) for a

tire or a tire and tube assembly upon

To equalize tread wear, rotate the tires

which the tire beads are seated.

every 16,000 km (10,000 miles) at the

latest or sooner if irregular wear

develops. Mazda recommends to

rotate every 8,000 km (5,000 miles) to

help increase tire life and distribute

wear more evenly.

1. Forward

Do not include (TEMPORARY USE

ONLY) spare tire in rotation.

Inspect the tires for uneven wear and

damage. Abnormal wear is usually

caused by one or a combination of the

following:

^ Incorrect tire pressure

8-26

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)



Improper wheel alignment

NOTE

^ Out-of-balance wheel

Tires degrade over time, even when

^ Severe braking

they are not being used on the road. It

is recommended that tires generally be

After rotation, inflate all tire pressures

replaced when they are 6 years or

to specification on page 9-5 and

older. Heat caused by hot climates or

inspect the lug nuts for tightness.

frequent high loading conditions can

accelerate the aging process. You

CAUTION

should replace the spare tire when you

Rotate unidirectional tires and radial

replace the other road tires due to the

tires that have an asymmetrical tread

aging of the spare tire. The period in

pattern or studs only from front to rear,

which the tire was manufactured (both

not from side to side. Tire performance

week and year) is indicated by a 4-digit

will be weakened if rotated from side

number.

to side.

Refer to Tire Labeling on page 8-21.

▼ Replacing a Tire

▼ Safety Practices

The way you drive has a great deal to

WARNING

do with your tire mileage and safety.

So cultivate good driving habits for

Always use tires that are in good

your own benefit.

condition:

^ Observe posted speed limits and

Driving with worn tires is dangerous.

drive at speeds that are safe for the

Reduced braking, steering, and

existing weather conditions

traction could result in an accident.

^ Avoid fast starts, stops and turns

^ Avoid potholes and objects on the

If a tire wears evenly, a wear indicator

road

will appear as a solid band across the

^ Do not run over curbs or hit the tire

tread.

Replace the tire when this happens.

against the curb when parking

CAUTION

If you feel a sudden vibration or ride

disturbance while driving or you

suspect your tire or vehicle has been

damaged, immediately reduce your

speed. Drive with caution until you can

safely pull off the road. Stop and

inspect the tire for damage. If the tire

1. New tread

is under-inflated or damaged, deflate

2. Worn tread

it, remove the tire and rim and replace

3. Tread wear indicator

it with your spare tire. If you cannot

detect a cause, have the vehicle towed

You should replace the tire before the

to the nearest vehicle or tire dealer to

band crosses the entire tread.

have the vehicle inspected.

8-27

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Overloading makes a vehicle harder to

Vehicle Loading

drive and control. It also increases the

distance required for stopping. In cases

▼ Vehicle Loading

of serious overloading, brakes can fail

completely, particularly on steep

WARNING

grades. The load a tire will carry safely

is a combination of the size of the tire,

Do not tow a trailer with this vehicle:

its load range, and corresponding

Towing a trailer with this vehicle is

inflation pressure.

dangerous because it has not been

Never overload the vehicle and always

designed to tow a trailer and doing so

observe the vehicle's weight ratings

will affect the drive system which could

from the vehicle's Safety Certification

result in vehicle damage.

and Tire and Load Information labels.

This section will guide you in the

Base Curb Weight is the weight of the

proper loading of your vehicle, to keep

vehicle including all standard

your loaded vehicle weight within its

equipment. It does not include

design rating capability. Properly

passengers, cargo, or optional

loading your vehicle will provide

equipment.

maximum return of vehicle design

performance. Before loading your

Vehicle Curb Weight is the weight of

vehicle, familiarize yourself with the

your new vehicle when you picked it

following terms for determining your

up from your dealer plus any

vehicle's weight ratings, from the

aftermarket equipment.

vehicle's Safety Certification Label and

Tire and Load Information Label:

PAYLOAD

WARNING

Overloaded Vehicle:

Payload is the combination weight of

Overloading a vehicle is dangerous.

cargo and passengers that the vehicle

The results of overloading can have

is designed to carry. The maximum

serious consequences in terms of

payload for your vehicle can be found

passenger safety. Too much weight on

on the Tire and Load Information label

a vehicle's suspension system can

on the rear door on the driver's side or

cause spring or shock absorber failure,

door pillar. Look for “THE

brake failure, handling or steering

COMBINATION WEIGHT OF

problems, irregular tire wear, tire

OCCUPANTS AND CARGO SHOULD

failure or other damage.

NEVER EXCEED XXX kg or XXX lbs” for

your maximum payload. The payload

listed on the tire label is the maximum

payload for the vehicle as built by the

assembly plant. If any aftermarket or

dealer installed equipment has been

installed on the vehicle, the weight of

the equipment must be subtracted

8-28

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

from the payload listed on the tire

If the weight of the occupant increases,

label in order to be accurate.

the cargo weight limit decreases by

that much.

SAMPLE

GAW (Gross Axle Weight) is the total

weight placed on each axle (front and

rear) - including vehicle curb weight

and all payload.

GAWR (Gross Axle Weight Rating) is

the maximum allowable weight that

can be carried by a single axle (front or

rear). These numbers are shown on

CARGO

the Safety Compliance Certification

Label located on the rear door on the

driver's side or door pillar. The total

load on each axle must never exceed

Cargo Weight includes all weight

its GAWR.

added to the Base Curb Weight,

including cargo and optional

GVW

equipment.

The cargo weight limit decreases

depending on the number of vehicle

GVW (Gross Vehicle Weight) is the

occupants. The cargo weight limit can

Vehicle Curb Weight + cargo +

be calculated by subtracting the total

passengers.

weight of the vehicle occupants from

the “combination weight of occupants

GVWR (Gross Vehicle Weight Rating)

and cargo should never exceed” value

is the maximum allowable weight of

on the tire label.

the fully loaded vehicle (including all

options, equipment, passengers and

Examples: Based on a single occupant

cargo). The GVWR is shown on the

weight of 68 kg (150 lbs), and a value

Safety Compliance Certification Label

of 385 kg (849 lbs) for the

located on the rear door on the

“combination weight of occupants and

driver's side or door pillar. The GVW

cargo should never exceed”:

must never exceed the GVWR.

The cargo weight limit with one

occupant is 385 kg (849 lbs) － 68 kg

SAMPLE

(150 lbs) = 317 kg (699 lbs)

The cargo weight limit with two

occupants is 385 kg (849 lbs) － (68 ×

2) kg ( (150 × 2) lbs) = 249 kg (549

lbs)

8-29

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Do not use replacement tires with

WARNING

lower load carrying capacities than the

originals because they may lower the

Never Exceed Axle Weight Rating

vehicle's GVWR and GAWR

Limits:

limitations. Replacement tires with a

Exceeding the Safety Certification

higher limit than the originals do not

Label axle weight rating limits is

increase the GVWR and GAWR

dangerous and could result in death or

limitations.

serious injury as a result of substandard

Never exceed the GVWR or the GAWR

vehicle handling, performance, motor,

specified on the certification label.

EV transaxle and/or structural damage,

serious damage to the vehicle, or loss

of control.

Always keep the vehicle within the axle

weight rating limits.

GCW

GCW (Gross Combination Weight) is

the weight of the loaded vehicle

(GVW).

GCWR (Gross Combination Weight

Rating) is the maximum allowable

weight of the vehicle - including all

cargo and passengers - that the vehicle

can handle without risking damage.

The GCW must never exceed the

GCWR.

WARNING

Never Exceed GVWR or GAWR

Specifications:

Exceeding the GVWR or the GAWR

specified on the certification label is

dangerous. Exceeding any vehicle

rating limitation could result in a

serious accident, injury, or damage to

the vehicle.

8-30

Specifications

Identification Numbers

▼ Chassis Number

Vehicle Information

Open the cover shown in the figure to

Labels

check the chassis number.

▼ Vehicle Identification Number

The vehicle identification number

legally identifies your vehicle. The

number is on a plate attached to the

cowl panel located on the left corner

of the dashboard. This plate can easily

be seen through the windshield.

▼ Vehicle Emission Control

Information Label

▼ Motor Vehicle Safety Standard

Label

▼ Tire Pressure Label

9-2

Specifications

Specifications

Specifications

▼ Charge System

Item

Servicing data

Input power

110 - 240 V AC (single phase)

Rated frequency

60 Hz

Maximum rated electrical current

32 A (normal charge)

Maximum power consumption

7.68 kVA (normal charge)

Maximum charging current

100 A (quick charge)

Electrical leakage detection current

for control box including genuine

5 mA

charge cable

Normal charge: AC Level 1, AC level 2

EV charge mode/Connection type

Quick charge: CCS1 (Combo1)

Installation requirements

Applicable laws and regulations, and standards must be followed

(information on protection against

for protection measures against over-current and over-voltage.

short-circuit current and equipment

Always make sure to install appropriate over-current protection

protection)

devices to the wiring of houses and buildings.

IP44: When charge connector is connected to charge inlet

IP level

IP67: Charge cable

Onboard charger: -30 °C (-22 °F) ― 65 °C (149 °F) (coolant

temperature). Performance degrades at 60 °C (140 °F) or higher

Operating temperature

Charge cable: -30 °C (-22 °F) ― 50 °C (122 °F) (ambient tem-

perature)

Onboard charger: -40 °C (-40 °F) ― 65 °C (149 °F) (coolant

temperature), -40 °C (-40 °F) ― 85 °C (185 °F) (ambient tem-

Storage temperature

perature)

Charge cable: Vehicle guaranteed temperature

Onboard charger:　EN/IEC 61851-1, EN/IEC 61851-21,

EN/IEC 61851-23, UL 2202

Applicable standards

Charge cable: NFPA 70, NFPA 79, SAE-J 1772, UL 62, UL 817, UL

2231-1, UL 2231-2, UL 2251, UL 2594, CSA C22.2 No.280-16

Do not use an adapter on the charge plug and the charge con-

Adapters

nector.

Do not use an extension cable.

▼ High Voltage Battery

Item

Specification

Type

Lithium-ion battery

9-3

Specifications

Specifications

Item

Specification

Operation guaranteed temperature: -30 °C (-22 °F) ― 60 °C

(140 °F)

Temperature range

Storage guaranteed temperature: -40 °C (-40 °F) ― 70 °C

(158 °F)

▼ Lead-acid Battery

Item

Specification

Lead-acid battery^*1

12V-42Ah/20HR

*1

Check the battery installed on the vehicle and use a battery with an equal or

higher performance. However, the performance of the battery may vary even

among the same battery types, consult an Authorized Mazda Dealer for

replacement.

▼ Lubricant Quality

Lubricant

Classification

Coolant

FL-22 type

EV Transaxle fluid

Mazda Original Oil ATF-FZ

Brake fluid

SAE J1703 or FMVSS116 DOT-3

▼ Capacities

(Approximate Quantities)

Item

Capacity

Coolant

4.3 L (4.5 US qt, 3.8 Imp qt)

EV Transaxle fluid

1.55 L (1.64 US qt, 1.36 Imp qt)

Check oil and fluid levels with dipsticks or reservoir gauges.

▼ Dimensions

Item

Vehicle specification

Overall length

4,393 mm (173.0 in)

Overall width

1,797 mm (70.7 in)

Overall height

1,574 mm (62.0 in)

Front tread

1,563 mm (61.5 in)

Rear tread

1,563 mm (61.5 in)

Wheelbase

2,653 mm (104.4 in)

9-4

Specifications

Specifications

▼ Weights

Item

Weight

GVWR (Gross Vehicle Weight Rating)

2,087 kg (4,601 lbs)

Front

1,047 kg (2,308 lbs)

GAWR (Gross Axle Weight Rating)

Rear

1,042 kg (2,297 lbs)

▼ Light Bulbs

Exterior light/Interior light

All the light bulbs are the LED type.

The LED bulb cannot be replaced. We recommend an Authorized Mazda Dealer

when the replacement is necessary.

▼ Tires

NOTE

The tires have been optimally matched with the chassis of your vehicle.

When replacing tires, Mazda recommends that you replace tires of the same type

originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.

Check the tire pressure label for tire size and inflation pressure.

^ Refer to Tire Pressure Label on page 9-2.

Standard tire

Inflation pressure

Tire size

Front

Rear

215/55R18 95H M+S

250 kPa (36 psi)

250 kPa (36 psi)

Lug nut tightening torque

When installing a tire, tighten the lug nut to the following torque.

108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)

▼ Fuses

Refer to Fuses on page 6-27.

9-5

Content      ..     14      15      16
