Maintenance and Care

Owner Maintenance

block located in the motor

Fuses

compartment.

▼ Fuses

Your vehicle's electrical system is

protected by fuses.

If any lights, accessories, or controls do

not work, inspect the appropriate

circuit protector. If a fuse has blown,

the inside element will be melted.

If the same fuse blows again, avoid

using that system and consult an

Inspect the fuse and replace it if it is

Authorized Mazda Dealer as soon as

blown.

possible.

▼ Fuse Replacement

Replacing the fuses on the vehicle's

left side

If the electrical system does not work,

1. Normal

first inspect the fuses on the vehicle's

2. Blown

left side.

Insert a new fuse of the same

1. Make sure the power switch is

amperage rating, and make sure it

switched off, and other switches

fits tightly. If it does not fit tightly,

are off.

have an expert install it. Consult an

2. Open the fuse panel cover.

Authorized Mazda Dealer.

If you have no spare fuses, borrow

one of the same rating from a

circuit not essential to vehicle

operation, such as the audio or

accessory socket circuit.

Reinstall the cover and make sure

that it is securely installed.

Replacing the fuses under the hood

3. Pull the fuse straight out with the

If the headlights or other electrical

fuse puller provided on the fuse

components do not work and the fuses

in the cabin are normal, inspect the

fuse block under the hood.

6-27

Maintenance and Care

Owner Maintenance

If a fuse is blown, it must be replaced.

1. Normal

Follow these steps:

2. Blown

1. Make sure the power switch is

switched off, and other switches

WARNING

are off.

2. Remove the fuse block cover.

Do not replace the main fuse by

yourself. Have an Authorized

Mazda Dealer perform the

replacement:

Replacing the fuse by yourself is

dangerous because the MAIN fuse

is a high current fuse. Incorrect

replacement could cause an

electrical shock or a short circuit

resulting in a fire.

4. Reinstall the cover and make sure

that it is securely installed.

3. If any fuse but the MAIN fuse is

blown, replace it with a new one of

the same amperage rating.

6-28

Maintenance and Care

Owner Maintenance

FUSE RAT-

No.

PROTECTED COMPONENT

ING

10 A

Motor control system

15 A

Charge control system

F10

10 A

BEV control system

F11

7.5 A

Air conditioner

F12

10 A

BEV control system

F13

―

F14

―

F15

20 A

―

F16

15 A

For protection of various circuits

F17

15 A

Water pump

F18

15 A

Accessory sockets

F19

60 A

Power steering system

F20

15 A

Headlight (LH) 1

F21

15 A

Headlight (RH) 1

F22

15 A

Keyless system

F23

30 A

ABS, Dynamic stability control system

F24

15 A

Headlight (LH) 2

F25

15 A

Headlight (RH) 2

F26

7.5 A

On board diagnostics

F27

25 A

For protection of various circuits

F28

25 A

For protection of various circuits

F29

15 A

Windshield washer

F30

―

F31

15 A

Horn

F32

―

F33

―

F34

20 A

BEV control system

F35

50 A

ABS, Dynamic stability control system

F36

30 A

Parking lock

F37

30 A

Rear window defogger

F38

50 A

For protection of various circuits

F39

―

F40

40 A

Air conditioner

6-30

Maintenance and Care

Appearance Care

clear and color base coat of the

Exterior Care

vehicle's paintwork.

▼ Exterior Care

When insects stick to the paint surface

The paintwork on your Mazda

and decompose, corrosive compounds

represents the latest technical

form. These can erode the clear and

developments in composition and

color base coat of the vehicle's

methods of application.

paintwork if they are not removed.

Environmental hazards, however, can

Tree sap will harden and adhere

harm the paint's protective properties,

permanently to the paint finish. If you

if proper care is not taken.

scratch the sap off while it is hard,

some vehicle paint could come off

Here are some examples of possible

with it.

damage, with tips on how to prevent

Prevention

them.

It is necessary to have your Mazda

Etching Caused by Acid Rain or

washed and waxed to preserve its

Industrial Fallout

finish according to the instructions in

Occurrence

this section. This should be done as

soon as possible.

Industrial pollutants and vehicle

emissions drift into the air and mix

Bird droppings can be removed with a

with rain or dew to form acids. These

soft sponge and water. If you are

acids can settle on a vehicle's finish. As

traveling and these are not available, a

the water evaporates, the acid

moistened tissue may also take care of

becomes concentrated and can

the problem. The cleaned area should

damage the finish.

be waxed according to the instructions

And the longer the acid remains on the

in this section.

surface, the greater the chance is for

Insects and tree sap are best removed

damage.

with a soft sponge and water or a

Prevention

commercially available chemical

cleaner.

It is necessary to wash and wax your

vehicle to preserve its finish according

Another method is to cover the

to the instructions in this section.

affected area with dampened

These steps should be taken

newspaper for 1 to 2 hours. After

immediately after you suspect that acid

removing the newspaper, rinse off the

rain has settled on your vehicle's finish.

loosened debris with water.

Damage Caused by Bird Dropping,

Water Marks

Insects, or Tree Sap

Occurrence

Rain, fog, dew, and even tap water can

Bird droppings contain acids. If these

contain harmful minerals such as salt

are not removed they can eat away the

and lime. If moisture containing these

minerals settles on the vehicle and

6-34

Maintenance and Care

Appearance Care

evaporates, the minerals will

cleaner or polish. Read all warnings

concentrate and harden to form white

and cautions.

rings. The rings can damage your

▼ Maintaining the Finish

vehicle's finish.

Washing

Prevention

It is necessary to wash and wax your

CAUTION

vehicle to preserve its finish according

to the instructions in this section.

¾ Before lifting the windshield wiper

These steps should be taken

blades off the windshield, always

immediately after you find water marks

follow the procedure for moving the

on your vehicle's finish.

windshield wiper blades. Otherwise,

Paint Chipping

a wiper blade, wiper arm, or the

hood could be damaged.

Occurrence

Refer to the Replacing Windshield

Wiper Blades (page 6-15) section for

Paint chipping occurs when gravel

thrown in the air by another vehicle's

the procedure on how to move the

windshield wiper blades to the

tires hits your vehicle.

service position.

How to avoid paint chipping

¾ When the power switch is switched

ON and the wiper lever is in the

Keeping a safe distance between you

and the vehicle ahead reduces the

AUTO position, the windshield

wipers may operate automatically in

chances of having your paint chipped

by flying gravel.

the following cases:

¾ The area of the windshield above

NOTE

the rain sensor is touched or wiped

^ The paint chipping zone varies with

with a cloth.

the speed of the vehicle. For

¾ The windshield or the rain sensor

example, when traveling at 90 km/h

area in the cabin is hit.

(56 mph), the paint chipping zone is

When the power switch is switched

50 m (164 ft).

^ In low temperatures a vehicle's finish

ON and the wiper lever is in the

AUTO position, do not touch the

hardens. This increases the chance of

paint chipping.

windshield or the windshield wipers

Otherwise, the windshield wipers

^ Chipped paint can lead to rust

forming on your Mazda. Before this

will operate automatically which

could catch your fingers or damage

happens, repair the damage by using

Mazda touch-up paint according to

the windshield wipers.

When removing ice or snow, or

the instructions in this section.

Failure to repair the affected area

cleaning the windshield, always

make sure the wiper lever is in the

could lead to serious rusting and

expensive repairs.

OFF position.

¾ Do not spray water in the motor

compartment. Otherwise, it could

Follow all label and container

lead to an electrical shock resulting

directions when using a chemical

in an accident.

6-35

Maintenance and Care

Appearance Care

¾ When washing and waxing the

NOTE

vehicle, be careful not to apply

^ Mazda is not responsible for

excessive force to any single area of

scratches caused by automatic car

the vehicle roof. Otherwise, you

washes or improper washing.

could dent the vehicle.

^ Scratches are more noticeable on

¾ Make sure that the charge lid is

vehicles with darker paint finishes.

closed and lock the doors.

Otherwise, the charge lid may be

To minimize scratches on the vehicle's

forcefully opened by water pressure

paint finish:

causing damage to the vehicle or

^ Rinse off any dirt or other foreign

charge lid.

matter using lukewarm or cold water

¾ When washing the vehicle, do not

before washing.

spray highly pressurized water

^ Use plenty of lukewarm or cold

against the sensor areas of the front

water and a soft cloth when washing

and rear bumpers, or rub them

the vehicle. Do not use a nylon cloth.

strongly. Otherwise, the sensors may

^ Rub gently when washing or drying

be unable to detect obstructions

the vehicle.

correctly and systems such as the

^ Take your vehicle only to a car wash

parking sensor may not operate

that keeps its brushes well

normally.

maintained.

To help protect the finish from rust and

^ Do not use abrasive cleansers or wax

deterioration, wash your Mazda

that contain abrasives.

thoroughly and frequently, at least

once a month, with lukewarm or cold

CAUTION

water.

¾ Do not use steel wool, abrasive

If the vehicle is washed improperly, the

cleaners, or strong detergents

paint surface could be scratched. Here

containing highly alkaline or caustic

are some examples of how scratching

agents on chrome-plated or

could occur.

anodized aluminum parts. This may

damage the protective coating; also,

Scratches occur on the paint surface

cleaners and detergents may discolor

when:

or deteriorate the paint.

^ The vehicle is washed without first

Pay special attention to removing salt,

rinsing off dirt and other foreign

dirt, mud, and other foreign material

matter.

from the underside of the fenders, and

^ The vehicle is washed with a rough,

make sure the drain holes in the lower

dry, or dirty cloth.

edges of the doors and rocker panels

^ The vehicle is washed at a car wash

are clean.

that uses brushes that are dirty or too

stiff.

Insects, tar, tree sap, bird droppings,

^ Cleansers or wax containing

industrial fallout, and similar deposits

abrasives are used.

can damage the finish if not removed

immediately. When prompt washing

6-36

Maintenance and Care

Appearance Care

with plain water is ineffective, use a

available depending on the type of car

mild soap made for use on vehicles.

wash machine. If the car washer nozzle

is put too close to the vehicle, the

Thoroughly rinse off all soap with

force of the spray could damage or

lukewarm or cold water. Do not allow

deform the molding, affect the

soap to dry on the finish.

sealability of parts, and allow water to

penetrate the interior. Keep a sufficient

After washing the vehicle, dry it with a

space (30 cm (12 in) or more)

clean chamois to prevent water spots

between the nozzle and the vehicle. In

from forming.

addition, do not spend too much time

spraying the same area of the vehicle,

WARNING

and be very careful when spraying

between gaps in doors and around

Dry off brakes that have become wet

windows.

by driving slowly, releasing the

Waxing

accelerator pedal and lightly applying

the brakes several times until the

Your vehicle needs to be waxed when

brake performance returns to normal:

water no longer beads on the finish.

Driving with wet brakes is dangerous.

Always wash and dry the vehicle before

Increased stopping distance or the

waxing it. In addition to the vehicle

vehicle pulling to one side when

body, wax the metal trim to maintain

braking could result in a serious

its luster.

accident. Light braking will indicate

whether the brakes have been

1. Use wax which contains no

affected.

abrasives.

Wax containing abrasives will

When using an automatic car wash

remove paints and could damage

^ Retract the door mirrors.

bright metal parts.

^ The automatic car wash brushes

2. Use a good grade of natural wax for

could reduce the paint luster or

metallic, mica, and solid colors.

hasten paint deterioration.

3. When waxing, coat evenly with the

sponge supplied or a soft cloth.

NOTE

4. Wipe off the wax with a soft cloth.

Release the parking brake and use

NOTE

neutral hold mode (automatic car

A spot remover to remove oil, tar, and

wash mode) when it is necessary to

similar materials will usually also take

change the shift position to the N

off the wax. Rewax these areas even if

position for an automatic car wash.

the rest of the vehicle does not need it.

For details on neutral hold mode

(automatic car wash mode) (page

▼ Repairing Damage to the Finish

4-28).

Deep scratches or chips on the finish

When using a high water pressure car

should be repaired promptly. Exposed

wash

metal quickly rusts and can lead to

major repairs.

High water temperature and high

water pressure car washers are

6-37

Maintenance and Care

Appearance Care

floor pan, even though these parts may

CAUTION

be coated with anti-corrosive material.

If your Mazda is damaged and needs

metal parts repaired or replaced, make

Thoroughly flush the underbody and

sure the body shop applies

wheel housings with lukewarm or cold

anti-corrosion materials to all parts,

water at the end of each winter. Try

both repaired and new. This will

also to do this every month.

prevent them from rusting.

Pay special attention to these areas

▼ Bright-Metal Maintenance

because they easily hide mud and dirt.

It will do more harm than good to wet

^ Use tar remover to remove road tar

down the road grime without

and insects. Never do this with a

removing it.

knife or similar tool.

^ To prevent corrosion on bright-metal

The lower edges of doors, rocker

surfaces, apply wax or chrome

panels, and frame members have drain

preservative and rub it to a high

holes that should not be clogged.

luster.

Water trapped there will cause rusting.

^ During cold weather or in coastal

areas, cover bright-metal parts with a

WARNING

coating of wax or preservative

heavier than usual. It would also help

to coat them with noncorrosive

Dry off brakes that have become wet

petroleum jelly or some other

by driving slowly, releasing the

protective compound.

accelerator pedal and lightly applying

the brakes several times until the

brake performance returns to normal:

CAUTION

Driving with wet brakes is dangerous.

Increased stopping distance or the

Do not use steel wool, abrasive

vehicle pulling to one side when

cleaners, or strong detergents

braking could result in a serious

containing highly alkaline or caustic

accident. Light braking will indicate

agents on chrome-plated or anodized

whether the brakes have been

aluminum parts. This may result in

affected.

damage to the protective coating and

cause discoloration or paint

▼ Camera and Lens Maintenance

deterioration.

▼ Underbody Maintenance

CAUTION

Road chemicals and salt used for ice

¾ The camera cover is made of hard

and snow removal and solvents used

plastic, therefore do not apply oil

for dust control may collect on the

film remover, organic solvents, wax,

underbody. If not removed, they will

or coating agents. If any such agent is

speed up rusting and deterioration of

applied, wipe it using a soft cloth

such underbody parts as frame and

immediately.

6-38

Maintenance and Care

Appearance Care

¾ Do not rub the camera cover or lens

strongly alkaline detergents.

forcefully, or clean them with an

Otherwise, these chemical agents

abrasive or hard brush.

can discolor or damage the surfaces

resulting in a significant loss in

NOTE

functionality. If plastic parts become

If there are water droplets, snow, or

inadvertently exposed to any of these

mud on the camera lens, wipe it off

chemical agents, flush with water

using a soft cloth. If the camera lens is

immediately.

especially dirty, wash it off with mild

^ If plastic parts such as the bumpers

detergent.

become inadvertently exposed to

chemical agents or fluids such as

▼ Aluminum Wheel Maintenance

coolant, or lead-acid battery fluid, it

could cause discoloration, staining,

A protective coating is provided over

or paint peeling. Wipe off any such

the aluminum wheels. Special care is

chemical agents or fluids using a soft

needed to protect this coating.

cloth immediately.

^ High water temperature and high

CAUTION

water pressure car washers are

Do not use any detergent other than

available depending on the type of

mild detergent. Before using any

high pressure car washer device. If

detergent, verify the ingredients.

the car washer nozzle is put too

Otherwise, the product could discolor

close to the vehicle or aimed at one

or stain the aluminum wheels.

area for an extended period of time,

it could deform plastic parts or

NOTE

damage the paint.

^ Do not use wax containing

^ Do not use a wire brush or any

compounds (polish). Otherwise, it

abrasive cleaner, polishing

could result in paint damage.

compound, or solvent on aluminum

^ In addition, do not use an electrical

wheels. They may damage the

or air tool to apply wax. Otherwise,

coating.

the frictional heat generated could

^ Always use a sponge or soft cloth to

result in deformation of plastic parts

clean the wheels.

or paint damage.

Rinse the wheels thoroughly with

lukewarm or cold water. Also, be

sure to clean the wheels after driving

on dusty or salted roads to help

prevent corrosion.

^ Avoid washing your vehicle in an

automatic car wash that uses

high-speed or hard brushes.

▼ Plastic Part Maintenance

^ When cleaning the plastic lenses of

the lights, do not use gasoline,

kerosene, rectified spirit, paint,

thinner, highly acidic detergents, or

6-39

Maintenance and Care

Appearance Care

sure there is no remaining moisture

Interior Care

on them.

▼ Interior Care

WARNING

If a seat belt appears frayed or has

abrasions, have it replaced by an

Do not spray water into the vehicle

Authorized Mazda Dealer:

cabin:

If a seat belt is used under such a

Spraying water into the vehicle cabin is

condition, it cannot function at its full

dangerous as electrical devices such as

capacity which could result in serious

the audio and switches could get wet

injury or death.

resulting in a malfunction or vehicle

fire.

Use a mild detergent to remove

soiling from a seat belt:

NOTE

If organic solvents are used for cleaning

the seat belts or they become stained

^ Do not wipe the interior using

or bleached, there is the possibility of

alcohol, chlorine bleach, or organic

them becoming weakened and as a

solvents such as thinner, benzene,

result, they may not function at their

and gasoline. Otherwise, it may

full capacity which could cause serious

cause discoloration or stains.

injury or death.

^ Rubbing hard with a stiff brush or

cloth may cause damage.

NOTE

If the vehicle interior becomes soiled

Clean seat belts diligently if they get

by any of the following, wipe it off

dirty. Leaving them uncleaned will

immediately using a soft cloth.

make it difficult to clean them later,

Leaving it uncleaned could cause

and it may affect the smooth retracting

discoloration, stains, cracks, or peeling

of the seat belt.

of the coating, and it will make it hard

to wipe off later.

▼ Vinyl Upholstery Maintenance

^ Beverage or fragrance

Remove dust and dirt from the vinyl

^ Grease or oil

upholstery using a brush or vacuum.

^ Soiling

Remove soiling from vinyl upholstery

using a leather and vinyl upholstery

▼ Seat Belt Maintenance

cleaner.

1. Clean the soiled area by lightly

▼ Upholstery and Synthetic Leather

dabbing it with a soft cloth soaked

Maintenance

in a mild detergent (approx. 5%)

diluted with water.

Fabric

2. Wipe off the remaining detergent

1. Clean the soiled area by lightly

using a cloth soaked in clean water

dabbing it with a soft cloth soaked

and wrung out well.

in a mild detergent (approx. 5%)

3. Before retracting seat belts which

diluted with water.

have been pulled out for cleaning,

dry them off thoroughly and make

6-40

Maintenance and Care

Appearance Care

2. Wipe off the remaining detergent

^ Sand or dirt

using a cloth soaked in clean water

^ Grease or oil, such as hand cream

and wrung out well.

^ Alcohol, such as in cosmetic or

hair dressing items

Synthetic leather

^ If the leather upholstery gets wet,

Remove dust and sand using a

promptly remove moisture with a dry

vacuum cleaner.

cloth. Remaining moisture on the

Wipe the soiled area with a soft

surface may cause deterioration such

cloth soaked in a mild detergent

as hardening and shrinkage.

(approx. 5%) diluted with water.

^ Exposure to direct sunlight for long

Wipe off the remaining detergent

periods may cause deterioration and

using a cloth soaked in clean water

shrinkage. When parking the car

and wrung out well.

under direct sunlight for long

periods, shade the interior using

▼ Leather Upholstery Maintenance*

sunshades.

^ Do not leave vinyl products on the

Remove dust and sand using a

leather upholstery for long periods.

vacuum cleaner.

They may affect the leather quality

Wipe off the soiled area with a soft

and coloring. If the cabin

cloth and a suitable, special cleaner

temperature becomes hot, the vinyl

or a soft cloth soaked in a mild

may deteriorate and adhere to the

detergent (about 5%) diluted with

genuine leather.

water.

Wipe off the remaining detergent

▼ Plastic Part Maintenance

using a cloth soaked in clean water

and wrung out well.

Remove moisture with a dry, soft

CAUTION

cloth and allow the leather to

Do not use polishing agents.

further dry in a well-ventilated,

Depending on the product ingredients,

shaded area. If the leather gets wet

they could cause discoloration, stains,

such as from rain, remove the

cracks or peeling of the coating.

moisture and dry it as soon as

possible.

▼ Instrument Panel Top (Soft pad)

Maintenance

NOTE

Extremely soft material is used for the

^ Because genuine leather is a natural

soft pad surface. If the soft pad surface

material, its surface is not uniform

is rubbed harshly with a dry cloth, it

and it may have natural scars,

could result in the surface being

scratches, and wrinkles.

damaged and leaving white scratch

^ To maintain the quality for as long as

marks.

possible, periodical maintenance,

1. Wipe the soiled area with a soft

about twice a year, is recommended.

cloth soaked in a mild detergent

^ If the leather upholstery comes into

(approx. 5%) diluted with water.

contact with any of the following,

2. Wipe off the remaining detergent

clean it immediately.

using a cloth soaked in clean water

Leaving it uncleaned could cause

and wrung out well.

premature wear, mold, or stains.

*Some models.

6-41

Maintenance and Care

Appearance Care

▼ Active Driving Display

When cleaning the interior side of the

Maintenance

window glass, gently wipe it with a soft

cloth soaked in clean water and

The dust-proof sheet has a coating.

thoroughly wrung out.

When cleaning, do not use a hard or

If there is oil film on the windshield,

rough-surface cloth, or cleaning

headlight beams from on-coming

detergent. In addition, if a chemical

vehicles may reflect irregularly

solvent gets on the active driving

especially on a rainy night, and your

display, wipe it off immediately. The

front vision might be obstructed.

dust-proof sheet could be damaged

If an antenna or filament is printed on

and the surface coating could be

the window glass, gently wipe along

scratched. Use a fine, soft cloth such as

the antenna or filament to clean that

those used for cleaning eyeglasses.

area.

NOTE

Use of compressed air when cleaning

CAUTION

the dust-proof sheet is recommended.

If some areas require further cleaning,

▼ Panel and Cork Area Maintenance

a glass cleaning agent can be used.

However, be careful of the following

If a panel or cork area becomes soiled,

points.

gently wipe it off with a soft cloth

soaked in clean water and thoroughly

¾ Follow the instructions on the glass

wrung out.

cleaner container.

If some areas require further cleaning,

¾ Do not use a glass cleaning agent on

use the following procedure:

a window antenna and filaments,

1. Wipe the soiled area with a soft

and on a rearview mirror equipped

cloth soaked in a mild detergent

with the automatic glare prevention

(approx. 5 %) diluted with water.

function.

2. Wipe off the remaining detergent

Using a glass cleaning agent may

using a cloth soaked in clean water

damage the window antenna or

and wrung out well.

filaments, and the automatic glare

prevention function may not operate

NOTE

normally.

^ Be particularly careful when cleaning

▼ Cleaning the Floor Mats

shiny surface panels and metallic

parts such as plating as they can be

Rubber floor mats should be cleaned

scratched easily.

with mild soap and water only.

 (Cork area)

Do not apply items with adhesive

WARNING

properties to the cork area.

Otherwise, the cork could be

Do not use rubber cleaners, such as

damaged.

tire cleaner or tire shine, when

cleaning rubber floor mats:

▼ Glass and Mirror Maintenance

Cleaning the rubber floor mats with

Use Mazda genuine glass cleaner to

rubber cleaning products makes the

remove oil film from the glass or

floor mats slippery.

mirror.

6-42

If Trouble Arises

Helpful information on what to do if a problem arises with the

vehicle.

Parking in an Emergency

7-2

Tiedown Hooks*

7-19

Parking in an Emergency

7-2

Warning/Indicator Lights and

Flat Tire

7-3

Warning Sounds

7-21

Tool Storage

7-3

If a Warning Light Turns On or

Emergency Flat Tire Repair

Flashes

7-21

Kit

7-4

Message Indicated on Multi-

Changing a Flat Tire

7-10

information Display

7-33

Warning Sound is

Troubleshooting for Charging

Activated

7-37

............................................ 7-11

What to do when charging is not

When Liftgate Cannot be

possible

7-11

Opened

7-42

When Liftgate Cannot be

Opened

7-42

Depleted Lead-acid Battery

7-12

Jump-Starting

7-12

Active Driving Display Does Not

Operate

7-43

Fully Discharged High Voltage

If the Active Driving Display Does

Battery

7-16

Not Operate

7-43

Fully Discharged High Voltage

Battery

7-16

Windshield Wipers Operate at High

Emergency Starting

7-17

Speed

7-44

Push-Starting

7-17

Windshield Wipers Operate at

High Speed

7-44

Emergency Towing

7-18

Towing Description

7-18

*Some models.

7-1

If Trouble Arises

Parking in an Emergency

▼ Parking in an Emergency

The hazard warning lights should

always be used when you stop on or

near a roadway in an emergency.

The hazard warning lights warn other

drivers that your vehicle is a traffic

hazard and that they must take

extreme caution when near it.

Depress the hazard warning flasher

and all the turn signals will flash. The

hazard warning indicator lights in the

instrument cluster flash simultaneously.

NOTE

^ The turn signals do not work when

the hazard warning lights are on.

^ Check local regulations about the

use of hazard warning lights while

the vehicle is being towed to verify

that it is not in violation of the law.

7-2

If Trouble Arises

Flat Tire

▼ Jack

Tool Storage

▼ Tool Storage

NOTE

A jack is not equipped in the vehicle as

NOTE

standard equipment. When replacing

Your vehicle may or may not be

the tire, use a jack. Consult an

equipped with a spare tire. For details,

Authorized Mazda Dealer for details.

consult an Authorized Mazda Dealer.

Designated jack-up position

Tools are stored in the locations

illustrated in the diagram.

Type A

1. Jacking position

1. Emergency flat tire repair kit

2. Tiedown eyelet

3. Jack lever

Type B

1. Emergency flat tire repair kit

2. Tiedown eyelet

3. Jack lever

7-3

If Trouble Arises

Flat Tire

▼

About the Emergency Flat Tire

Emergency Flat Tire

Repair Kit

The emergency flat tire repair kit

▼ Emergency Flat Tire Repair Kit

includes the following items.

The emergency flat tire repair kit

included with your Mazda is for a

temporary repair of a slightly damaged

flat tire resulting from running over

nails or similar sharp objects on the

road surface.

Perform the emergency flat tire repair

without removing the nail or similar

sharp object which punctured the tire.

NOTE

Your vehicle is not equipped with a

spare tire. In the event of a flat tire, use

the emergency flat tire repair kit to

repair the tire temporarily. When doing

the repair, refer to the instructions

included in the emergency flat tire

repair kit. If an emergency repair was

performed on a flat tire using the

Sealant bottle

emergency flat tire repair kit, have an

Compressor

Authorized Mazda Dealer, repair or

Speed restriction sticker

replace the tire as soon as possible.

Repaired tire sticker

Instructions

WARNING

Do not allow children to touch the

tire sealant:

¾ Ingestion of tire sealant is dangerous.

In the event tire sealant is

accidentally swallowed, drink large

amounts of water immediately and

seek medical assistance.

¾ Tire sealant that comes into contact

with the eyes and skin is dangerous.

If tire sealant enters the eyes or

contacts the skin, flush immediately

with large amounts of water and

seek medical assistance.

7-4

If Trouble Arises

Flat Tire

NOTE

Unload passengers and luggage,

and remove the emergency flat tire

^ The tire sealant cannot be reused.

repair kit.

Purchase new tire sealant at an

Authorized Mazda Dealer.

^ The emergency flat tire repair kit

cannot be used in the following

cases.

Consult an Authorized Mazda

Dealer.

^ The period of effective use for the

tire sealant has expired. (The

period of effectiveness is indicated

on the bottle label.)

Shake the sealant bottle to mix the

^ The tear or puncture exceeds

contents. Then extend the injection

about 4 mm (0.16 in).

hose.

^ The damage has occurred to an

area of the tire other than the

tread.

^ The vehicle has been driven with

nearly no air remaining in the tire.

^ The tire has come off the wheel

rim.

^ Damage to the wheel rim has

occurred.

^ The tire has 2 or more punctures.

▼ Using the Emergency Flat Tire

Repair Kit

Park on a level surface off the

1. Injection hose

right-of-way and set the parking

brake.

CAUTION

Shift the selector lever to the P

Do not shake the bottle excessively.

position and switch the power

Otherwise, the sealant could spray

switch to OFF.

out of the injection hose, and if the

Turn on the hazard warning flasher.

sealant contacts clothing or other

objects, you may not be able to

remove it.

NOTE

The sealant hardens easily and

injecting it will be difficult under

cold weather conditions (0 °C

(32 °F) or below). Warm the

sealant inside the vehicle to

facilitate injection.

7-5

If Trouble Arises

Flat Tire

6. Pull out the air compressor hose

injection hose to the tire valve, turn

and the air compressor plug from

the sleeve to the right, and tighten

the air compressor.

it.

1. Compressor hose

7. Install the air compressor hose

which was pulled out of the air

1. Valve

compressor to the injection valve of

2. Valve cap

the bottle.

3. Injection hose

9. Install the bottle to the air

compressor and press it in until the

left and right tabs are engaged

securely.

1. Compressor hose

2. Valve

3. Injection hose

CAUTION

1. Tabs

10.Insert the air compressor plug into

Make sure that the air compressor

the accessory socket inside the

switch is off before inserting the air

vehicle and switch the power

compressor hose to the injection

switch to ACC.

valve of the bottle. If the air

compressor hose is not installed to

the injection valve of the bottle

securely, the sealant may leak.

8. Remove the valve cap from the

valve of the flat tire, install the

7-6

If Trouble Arises

Flat Tire

Refer to Accessory Sockets on page

NOTE

5-39.

The inflation pressure may increase

to about 300 kPa (3.1 kgf/cm2, 3

bar, 43.5 psi) temporarily to inject

the sealant through the valve.

Normally, the inflation pressure

decreases gradually and it reaches

the actual inflation pressure after

about 30 seconds.

WARNING

Never use the air compressor

above 300 kPa (3.1 kgf/cm2, 3

bar, 43.5 psi):

Using the air compressor at an

inflation pressure above 300 kPa

(3.1 kgf/cm2, 3 bar, 43.5 psi)

continuously is dangerous. If the air

compressor overheats, hot air will

be exhausted and you could get

burned.

NOTE

Compressor plug

Compressor

^ Check the tire inflation pressure

label rear door on the driver's

CAUTION

side for the correct tire inflation

pressure.

When inserting the air compressor

^ Do not operate the air

plug into or removing it from the

compressor for a continuous 10

accessory socket, make sure that

minutes or longer because using

the air compressor switch is off.

it for long periods could cause a

When turning the air compressor

malfunction.

on/off, use the air compressor

^ If the tire inflation pressure does

switch.

not increase, repair of the tire is

11.The sealant is injected into the tire

not possible. If the tire does not

when the air compressor is

reach the specified tire inflation

switched on. After the sealant is

pressure within 10 minutes, it

injected completely, wait until the

may have received extensive

tire inflation pressure increases to

damage. In this case, the repair

the specified tire inflation pressure.

using the emergency flat tire

repair kit was not successful.

Contact an Authorized Mazda

Dealer.

7-7

If Trouble Arises

Flat Tire

12.Adhere the speed restriction sticker

the sleeve of the injection hose to

to an area where it can be viewed

the left, and pull it out of the tire

easily by the driver.

valve.

15.Remove the air compressor hose

from the injection valve of the

bottle. After that, install the

injection hose to the injection valve

of the bottle to prevent leakage of

any remaining sealant.

13.Adhere the repaired tire sticker to

the wheel of the flat tire.

CAUTION

The remaining sealant in the hose

may spray out when the hose is

removed. Remove the hose

carefully because you may not be

able to remove the sealant

contacting clothing or other

WARNING

objects.

16.Install the tire valve cap.

Do not adhere the speed

17.Put the emergency flat tire repair kit

restriction sticker to the padded

into the trunk.

area on the steering wheel:

18.Start driving immediately to spread

Adhering the speed restriction

the sealant in the tire.

sticker to the padded area on the

steering wheel is dangerous

CAUTION

because the air bag may not

operate (deploy) normally resulting

Carefully drive the vehicle at a

in serious injury. In addition, do not

speed of 80 km/h (50 mph) or less.

adhere the sticker to areas where

If the vehicle is driven at a speed of

warning lights or the speedometer

80 km/h (50 mph) or more, the

cannot be viewed.

vehicle may vibrate.

14.When the tire inflates to the

specified tire inflation pressure, turn

the air compressor switch off, turn

7-8

If Trouble Arises

Flat Tire

NOTE

to the nearest Authorized Mazda

If the tire is not properly inflated,

Dealer immediately and have the

the tire pressure monitoring system

flat tire replaced. Replacement with

warning light will illuminate (page

a new tire is recommended. If the

4-180).

tire is to be repaired or reused,

19.After driving the vehicle for about

consult an Authorized Mazda

10 minutes or 5 km (3 miles),

Dealer.

connect the air compressor to the

NOTE

tire using Step 8 of the procedure,

and check the tire inflation pressure

^ If an emergency flat tire repair has

using the tire pressure gauge on the

been performed using the

air compressor. If the tire inflation

emergency flat tire repair kit,

pressure is lower than the specified

Mazda recommends that the tire

tire inflation pressure, turn the air

be replaced with a new one as

compressor on and wait until it

soon as possible. If the tire is to

reaches the specified tire inflation

be repaired or reused, consult an

pressure.

Authorized Mazda Dealer.

^ The wheel can be reused if the

WARNING

sealant adhering to it is removed.

However, replace the valve with a

If the tire inflation pressure has

new one.

decreased below 130 kPa (1.3

▼ Inspecting the Emergency Flat Tire

kgf/cm2 or bar, 18.9 psi), stop

Repair Kit

driving and contact an Authorized

Mazda Dealer:

Inspect the emergency flat tire repair

The repair using the emergency flat

kit at regular intervals.

tire repair kit was not successful.

^ Check the tire sealant period of

effective use.

If you see a decrease in the tire

^ Check the operation of the tire

inflation pressure, even if Steps 8

compressor.

to 19 of the procedure are

performed repeatedly, stop

NOTE

driving:

The tire sealant has a period of

Contact an Authorized Mazda

effective use. Check the period of

Dealer.

effective use indicated on the bottle

label and do not use it if it has expired.

CAUTION

Have the tire sealant replaced at an

Authorized Mazda Dealer before the

Before checking the tire inflation

period of effective use has expired.

pressure using the tire pressure

gauge, turn the air compressor

switch off.

20.The emergency flat tire repair is

completed successfully if the tire

inflation pressure does not

decrease. Carefully drive the vehicle

7-9

If Trouble Arises

Flat Tire

To install the antitheft lug nut

Changing a Flat Tire

1. Place the special key on top of the

▼ Locking Lug Nuts

nut, and be sure to hold the key

square to it. If you hold the key at

If your Mazda is equipped with the

an angle, you may damage both key

optional antitheft wheel lug nuts, a

and nut. Do not use a power

special key must be used to unlock the

impact wrench.

locking lug nut for each wheel. The key

2. Place the lug wrench on top of the

is stored in the glove compartment,

special key, apply pressure, and

center console storage, storage box, or

turn it clockwise.

trunk. Register the key and lug nuts

with the lock manufacturer by filling

Nut tightening torque

out the registration card and mailing it

108―147 (12―14,

in using the accompanying envelope. If

N·m (kgf·m, ft·lbf)

80―108)

the key is lost, consult an Authorized

Mazda Dealer or use the lock

manufacturer’s order form to order a

new key.

Antitheft wheel lug nuts cannot be

installed on a steel wheel spare tire.

When installing a temporary spare tire,

use one of the original lug nuts in place

of the locking lug nut. The original lug

nuts are stored inside your Mazda.

1. Antitheft lug nut

2. Special key

To remove an antitheft lug nut

1. Obtain the special key for the

antitheft lug nut.

2. Place the special key on top of the

antitheft lug nut, and be sure to

hold the key square to it. If you

hold the key at an angle, you may

damage both key and nut. Do not

use a power impact wrench.

3. Place the lug wrench on top of the

key and apply pressure. Turn the

wrench counterclockwise.

7-10

If Trouble Arises

Troubleshooting for Charging

Normal charging is not possible.

What to do when

charging is not possible

Cause

Action

▼ What to do when charging is not

Check if a ground-fault circuit in-

possible

terrupter has operated or if a

The outlet

power outage occurred. If the

If trouble arises while charging such as

has no pow-

power source has a timer func-

not being able to charge the high

er.

tion, electrical power may not be

voltage battery, refer to the following

supplied to the outlet until the

table. If the problem cannot be solved

time set to supply power.

even after checking the following table,

there may be a problem with the

The charge

vehicle or charger. Contact an

plug is not

Check if the charge plug is prop-

Authorized Mazda Dealer.

properly

erly plugged into the outlet.

plugged into

Charging is not possible.

the outlet.

The charge

connector is

Check if the charge connector is

Cause

Action

not properly

properly connected.

The selector

connected.

lever is in a

Shift the selector lever to the P

Cancel the charging timer using

position

position.

Charging

EV Settings in Mazda Connect,

other than P.

timer is set.

or the charging timer cancella-

The high

tion function.

voltage bat-

Charging is not performed when

tery is al-

the high voltage battery is al-

Troubleshooting for functions using a

ready fully

ready fully charged.

Smartphone or computer

charged.

If you are having trouble with the

The high

Check the high voltage battery

remote function service, such as when

voltage bat-

temperature gauge in the instru-

the remote function does not work,

tery temper-

ment cluster. If the high voltage

refer to the Connected Service owner’s

ature is ex-

battery temperature gauge is in

manual.

tremely high

the red or blue range, charging

or low.

may not be possible.

If the instrument cluster does not

The

turn on even if the power switch

Lead-acid

is switched ON, the Lead-acid

battery is

battery may be depleted. Charge

depleted.

or replace the Lead-acid battery.

7-11

If Trouble Arises

Depleted Lead-acid Battery

Jump-Starting

▼ Jump-Starting

The lead-acid battery might be depleted if the following conditions occur.

^ The EV system does not start.

^ The selector lever cannot be shifted to a position other than P.

^ The horn sound is weak or it does not sound.

^ The brightness of the lights is extremely low.

Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If

you feel unsure about jump-starting, we strongly recommend that you have a

competent service technician do the work.

Using commercially available booster cables, connect the lead-acid battery of the

booster vehicle’s battery to the lead-acid battery of your vehicle and start the EV

system.

WARNING

Follow These Precautions Carefully:

To ensure safe and correct handling of the lead-acid battery, read the following

precautions carefully before using the lead-acid battery or inspecting it.

Keep flames and sparks away from open lead-acid battery cells and do not

allow metal tools to contact the positive (+) or negative (-) terminal of the

lead-acid battery when working near a lead-acid battery. Do not allow the

positive (+) terminal to contact the vehicle body:

Flames and sparks near open lead-acid battery cells are dangerous. Hydrogen gas,

produced during normal lead-acid battery operation, could ignite and cause the

lead-acid battery to explode. An exploding lead-acid battery can cause serious burns

and injuries. Keep all flames including cigarettes and sparks away from open

lead-acid battery cells.

7-12

If Trouble Arises

Depleted Lead-acid Battery

Keep all flames and sparks away from open lead-acid battery cells because

hydrogen gas is produced from open lead-acid battery cells while charging the

lead-acid battery or adding lead-acid battery fluid:

Flames and sparks near open lead-acid battery cells are dangerous. Hydrogen gas,

produced during normal lead-acid battery operation, could ignite and cause the

lead-acid battery to explode. An exploding lead-acid battery can cause serious burns

and injuries. Keep all flames including cigarettes and sparks away from open

lead-acid battery cells.

Do not jump-start a frozen lead-acid battery or one with a low fluid level:

Jump-starting a frozen lead-acid battery or one with a low fluid level is dangerous. It

may rupture or explode, causing serious injury.

Connect the negative cable to a good ground point away from the lead-acid

battery:

Connecting the end of the second jumper cable to the negative (-) terminal of the

depleted lead-acid battery is dangerous.

A spark could cause the gas around the lead-acid battery to explode and injure

someone.

Route the jumper cables away from parts that will be moving:

Connecting a jumper cable near or to moving part (cooling fans) is dangerous. The

cable could get caught when the EV system starts and cause serious injury.

CAUTION

¾ Connect the booster cables with extreme care.

¾ Do not jump-start the vehicle with the charging cable connected to your vehicle.

Otherwise, the vehicle could be damaged.

¾ Do not use your vehicle as a booster vehicle.

NOTE

^ If your lead-acid battery is depleted, make sure that the booster vehicle's battery is

a lead-acid battery.

1. Move the booster vehicle so that its lead-acid battery is as close as possible to

your vehicle's lead-acid battery.

2. Make sure that the power switch is switched OFF.

7-13

Mazda MX-30 (2022 year). Manual in english - page 14
