When Driving

Rear View Monitor

¾ Do not apply excessive force to the

Rear View Monitor*

camera. The camera position and

angle may deviate.

▼ Rear View Monitor

¾ Do not disassemble, modify, or

The rear view monitor provides visual

remove it as it may no longer be

images of the rear of the vehicle when

waterproof.

reversing.

¾ The camera cover is made of plastic.

Do not apply degreasing agents,

WARNING

organic solvents, wax, or glass

coating agents to the camera cover.

Always drive carefully confirming the

If any are spilled on the cover, wipe

safety of the rear and the surrounding

off with a soft cloth immediately.

conditions by looking directly with

¾ Do not rub the camera cover

your eyes:

forcefully with an abrasive or hard

Reversing the vehicle by only looking at

brush. The camera cover or lens may

the screen is dangerous as it may cause

be scratched which might affect the

an accident or a collision with an

images.

object. The rear view monitor is only a

visual assist device when reversing the

NOTE

vehicle. The images on the screen may

^ If water, snow, or mud is stuck on

be different from the actual conditions.

the camera lens, wipe it off using a

soft cloth. If it cannot be wiped off,

CAUTION

use a mild detergent.

^ If the camera temperature changes

¾ Do not use the rear view monitor

rapidly (Hot to cold, cold to hot), the

under the following conditions:

rear view monitor may not operate

Using the rear view monitor under

correctly.

the following conditions is

^ When replacing the tires, consult an

dangerous and could result in injury

Authorized Mazda Dealer. Replacing

or vehicle damage or both.

the tires could result in deviation of

¾ Icy or snow-covered roads.

the guide lines which appear on the

¾ Tire chains or a temporary spare

display.

tire is installed.

^ If the vehicle's front, side, or rear has

¾ The trunk lid is not fully closed.

been involved in a collision, the

¾ The vehicle is on a road incline.

alignment of the rear view parking

¾ When the display is cold, images

camera (location, installation angle)

may course across the monitor or the

may have deviated. Always consult

screen and may be dimmer than

an Authorized Mazda Dealer to have

usual, which could cause difficulty in

the vehicle inspected.

confirming the surrounding

^ If “No camera signal.” is indicated in

conditions of the vehicle. Always

the display, there could be a

drive carefully confirming the safety

problem with the camera. Have your

of the rear and the surrounding

vehicle inspected at an Authorized

conditions by looking directly with

Mazda Dealer.



(Predicted vehicle path assist lines

your eyes.

display type)

*Some models.

4-183

When Driving

Rear View Monitor

If force is applied to the steering

wheel, the guide lines may not

display. Loosen your grip on the

steering wheel to allow the guide

lines to display.

▼ Rear View Parking Camera

Location

1. Rear view parking camera

4-184

When Driving

Rear View Monitor

▼ Switching to the Rear View Monitor Display

The system switches to the rear view monitor when the power switch is switched

ON and shifting the selector lever to the reverse (R) position.

NOTE

When the selector lever is shifted from reverse (R) position to another selector lever

position, the screen returns to the previous display.

▼ Displayable Range on the Screen

The images on the screen may be different from the actual conditions.

1.

(Screen display)

2.

(Actual view)

3. Bumper

4.

“Check surroundings for safety.” message is displayed

5. Object

NOTE

^ The displayable range varies depending on the vehicle and road conditions.

^ If the camera lens is touched or there is any dirt on it, it could affect the screen

image. Wipe the lens using a soft cloth.

^ The displayable range is limited. Objects under the bumper or around the bumper

ends cannot be displayed.

^ The distance appearing in the displayed image is different from the actual distance

because the rear view parking camera is equipped with a specific lens.

4-185

When Driving

Rear View Monitor



Images displayed on the monitor from the rear view parking camera are reversed

images (mirror images).

^ Some optionally installed vehicle accessories may be picked up by the camera. Do

not install any optional parts that can interfere with the camera view, such as

illuminating parts or parts made of reflective material.

^ It may be difficult to see the display under the following conditions, however, it

does not indicate a malfunction.

^ In darkened areas.

^ When the temperature around the lens is high/low.

^ When the camera is wet such as on a rainy day or during periods of high

humidity.

^ When foreign material such as mud is stuck around the camera.

^ When the camera lens reflects sunlight or headlight beams.

^ The surroundings are illuminated by vehicle lights, fluorescent lights, or LED

lights (display may flicker).

^ Extremely small dark or white dots appear on the screen (dots may flicker).

^ Image display may be delayed if the temperature around the camera is low.

▼ Viewing the Display

Predicted vehicle path assist lines display type

The projected path guidance mode displays the predicted path of the vehicle after

you turn the steering wheel.

Use this mode for parking your vehicle in a parking space or garage.

a) Projected vehicle path (yellow)

These lines are displayed as a reference for the projected path of the vehicle.

The lines displaying the projected vehicle path change after you turn the steering

wheel.

b) Extended vehicle width lines (blue)

These lines indicate the vehicle's extended width.

These lines are not displayed when the vehicle's wheels are in the straight-ahead

position.

c) Distance guide lines (red)

4-186

When Driving

Rear View Monitor

These lines indicate the approximate distance to a point measured from the

vehicle's rear (from the end of the bumper).

The blue line indicates the point about 0.5 m (19 in) from the rear bumper.

The red and yellow lines, which change position after you turn the steering wheel,

indicate the points about 0.5 m (19 in) for the red line and 1.0 m (39 in) and 2.0

m (78 in) for the yellow lines from the rear bumper (at the center point of each of

the lines).

A degree of error occurs when the wheels are not in the straight-ahead position.

In the above illustration, the right side of the vehicle is in a position closer to the

actual distance displayed by the distance guide lines (red: about 0.5 m (19 in)

point, yellow: about 1.0 m (39 in), and yellow: about 2.0 m (78 in) point behind

the rear bumper), whereas the left side is in a position farther away.

CAUTION

The indicated position of the guide lines on the display changes depending on the

vehicle conditions (such as the number of occupants/cargo load) and the road

conditions (such as a steep gradient to the rear of the vehicle).

Always check the area to the vehicle's rear and the surrounding area directly with

your eyes while backing up.

Fixed assist lines display type

Guide lines which indicate the width of the vehicle are displayed on the screen as a

reference to the approximate width of the vehicle in comparison to the width of the

parking space you are about to back into.

Use this display view for parking your vehicle in a parking space or garage.

a) Vehicle width guide lines

Guide lines serve as a reference to the approximate width of the vehicle.

b) Distance guide lines

These guide lines indicate the approximate distance to a point measured from the

vehicle's rear (from the end of the bumper).

The red line indicates the point about 0.5 m (19 in) from the rear bumper.

The yellow lines indicate the points about 1.0 m (39 in) and 2.0 m (78 in) from

the rear bumper.

4-187

When Driving

Rear View Monitor

2. Before backing the vehicle into the parking space, turn the steering wheel while

referring to the projected vehicle path display so that the vehicle enters the

center of the parking space.

1.

(Display condition)

2.

(Vehicle condition)

4-189

When Driving

Rear View Monitor

3. After your vehicle begins entering the parking space, continue backing up slowly

so that the distance between the vehicle width lines and the sides of the parking

space on the left and right are roughly equal.

1.

(Display condition)

2.

(Vehicle condition)

4. Continue to adjust the steering wheel until the vehicle width guide lines are

parallel to the left and right sides of the parking space.

5. Once they are parallel, straighten the wheels and back your vehicle slowly into

the parking space. Continue checking the vehicle's surroundings and then stop

4-190

When Driving

Rear View Monitor

the vehicle in the best possible position. (If the parking space has division lines,

check whether the vehicle width guide lines are parallel to them.)

1.

(Display condition)

2.

(Vehicle condition)

6. When the selector lever is shifted from reverse (R) position to another selector

lever position, the screen returns to the previous display.

NOTE

Because there may be a difference between the displayed image, such as indicated

below, and the actual conditions when parking, always verify the safety at the rear of

the vehicle and the surrounding area directly with your eyes.

^ In the image of the parking space (or garage) displayed on the screen, the back

end and distance guide lines may appear aligned in the monitor, but they may not

actually be aligned on the ground.

4-191

When Driving

Rear View Monitor



When parking in a space with a division line on only one side of the parking space,

the division line and the vehicle width guide line appear aligned in the monitor,

but they may not actually be aligned on the ground.

Fixed assist lines display type

NOTE

Images displayed on the monitor from the rear view parking camera are reversed

images (mirror images).

1. Shift the selector lever to reverse (R) position to switch the display to the rear

view monitor display.

2. Confirming the surrounding conditions, reverse the vehicle.

4-192

When Driving

Rear View Monitor

3. After your vehicle begins entering the parking space, continue backing up slowly

so that the distance between the vehicle width lines and the sides of the parking

space on the left and right are roughly equal.

1.

(Display condition)

2.

(Vehicle condition)

4. Continue to adjust the steering wheel until the vehicle width guide lines are

parallel to the left and right sides of the parking space.

5. Once they are parallel, straighten the wheels and back your vehicle slowly into

the parking space. Continue checking the vehicle's surroundings and then stop

4-193

When Driving

Rear View Monitor

the vehicle in the best possible position. (If the parking space has division lines,

check whether the vehicle width guide lines are parallel to them.)

1.

(Display condition)

2.

(Vehicle condition)

6. When the selector lever is shifted from reverse (R) position to another selector

lever position, the screen returns to the previous display.

NOTE

Because there may be a difference between the displayed image, such as indicated

below, and the actual conditions when parking, always verify the safety at the rear of

the vehicle and the surrounding area directly with your eyes.

^ In the image of the parking space (or garage) displayed on the screen, the back

end and distance guide lines may appear aligned in the monitor, but they may not

actually be aligned on the ground.

4-194

When Driving

Rear View Monitor



When parking in a space with a division line on only one side of the parking space,

the division line and the vehicle width guide line appear aligned in the monitor,

but they may not actually be aligned on the ground.

▼ Variance Between Actual Road Conditions and Displayed Image

Some variance occurs between the actual road and the displayed road. Such

variance in distance perspective could lead to an accident. Note the following

conditions that may cause a variance in distance perspective.

When the vehicle is tilted due to the weight of passengers and load

When the vehicle rear is lowered, the object displayed on the screen appears farther

than the actual distance.

1. Object

2. Variance

3. Object on screen

When there is a steep grade behind the vehicle

When there is a steep upgrade (downgrade) behind the vehicle, the object displayed

on the screen appears farther (downgrade: closer) than the actual distance.

1. Appears farther than actual distance

2. Appears closer than actual distance

3. Distance between the vehicle and object displayed on the screen.

4-195

When Driving

Rear View Monitor

4. Actual distance between the vehicle and object.

5. Object at actual position

6. Object on screen

Three-dimensional object on vehicle rear

Because the distance guide lines are displayed based on a flat surface, the distance

to the three-dimensional object displayed on the screen is different from the actual

distance.

1.

(Screen display)

2.

(Actual condition)

3. Sensed distance on screen A>B>C

4. Actual distance B>C=A

(Predicted vehicle path assist lines display type)

When reversing near a three-dimensional object

When reversing near an overhanging object, the vehicle may hit the object even if

the anticipated course line does not contact the object on the screen. The position

of the object displayed on the screen is different from the actual position because

the anticipated course lines on the screen are displayed based on a horizontal road

4-196

When Driving

Rear View Monitor

surface. When backing up near an overhanging object, confirm the rear and

surrounding conditions directly with your eyes.

1.

(Screen display)

2.

(Actual view)

4-197

When Driving

Parking Sensor System

Parking Sensor System*

▼ Parking Sensor System

The parking sensors use ultrasonic sensors which detect obstructions around the

vehicle when the vehicle is driven at low speeds, such as during garage or parallel

parking, and a buzzer sound and detection indicator notify the driver of the

approximate distance from the vehicle to the surrounding obstruction.

1. Front ultrasonic sensor*

2. Front corner ultrasonic sensor*

3. Rear ultrasonic sensor

4. Rear corner ultrasonic sensor

5. Rear side ultrasonic sensor*

WARNING

Do not rely completely on the parking sensor system and be sure to confirm the

safety around your vehicle visually when driving:

This system can assist the driver in operating the vehicle in the forward and

backward directions while parking. The detection ranges of the sensors are limited,

therefore, driving the vehicle while relying only on the system may cause an

accident. Always confirm the safety around your vehicle visually when driving.

CAUTION

¾ Do not install any accessories within the detection ranges of the sensors. It may

affect the system operation.

¾ Depending on the type of obstruction and the surrounding conditions, the

detection range of a sensor may narrow, or the sensors may not be able to detect

obstructions.

¾ When washing the vehicle, do not spray highly pressurized water against the

sensor area, or rub it strongly. Otherwise, it may not be able to detect obstructions

correctly and the system may not operate normally.

4-198 *Some models.

When Driving

Parking Sensor System



The system may have a malfunction if a message indicating a system malfunction is

displayed. Have your vehicle inspected by an Authorized Mazda Dealer.

^ A message may be displayed even when the ambient temperature is extremely

cold, or mud, ice, or snow adheres to the sensor area. Remove any foreign matter

from the sensor area.

▼ Sensor Detection Range

The sensors detect obstructions within the following range.

1. Front ultrasonic sensor detection range

2. Rear corner/Rear side ultrasonic sensor detection range

3. Rear ultrasonic sensor detection range

4. Front corner ultrasonic sensor detection range

A: About 55.0 cm (About 21.6 in)

B: About 150 cm (About 59.0 in)

C: About 100 cm (About 39.3 in)

Viewing distance display

Distance between vehicle and obstruc-

Display

tion

Without 360° view monitor

Rear ultrasonic sen-

Front ultrasonic

sor/Rear corner ul-

Without front ul-

With front ultra-

With 360° view

sensor^*/Front cor-

trasonic sensor

sonic sensor and

trasonic sensor/

monitor

ner ultrasonic sen-

Rear side ultrasonic

and front corner

front corner ultra-

sor^*

ultrasonic sensor

sonic sensor

sensor^*

Green

Front ultrasonic sen-

Rear ultrasonic sen-

sor:

sor:

Approx. 100―60.0

Approx. 150―60.0

cm (39.3―23.6 in)

cm (59.0―23.6 in)

4-200 *Some models.

When Driving

Parking Sensor System

Distance between vehicle and obstruc-

Display

tion

Without 360° view monitor

Rear ultrasonic sen-

Front ultrasonic

Without front ul-

With front ultra-

sor/Rear corner ul-

With 360° view

sensor^*/Front cor-

trasonic sensor

sonic sensor and

trasonic sensor/

monitor

ner ultrasonic sen-

and front corner

front corner ultra-

Rear side ultrasonic

sor^*

ultrasonic sensor

sonic sensor

sensor^*

Yellow

Rear ultrasonic sen-

Front ultrasonic sen-

sor:

sor:

Approx. 60.0―45.0

Approx. 60.0―45.0

cm (23.6―17.7 in)

cm (23.6―17.7 in)

Rear corner ultra-

Front corner ultra-

sonic sensor/Rear

sonic sensor:

side ultrasonic sen-

Approx. 55.0―38.0

sor:

cm (21.6―14.9 in)

Approx. 55.0―38.0

cm (21.6―14.9 in)

Amber

Rear ultrasonic sen-

Front ultrasonic sen-

sor:

sor:

Approx. 45.0―35.0

Approx. 45.0―35.0

cm (17.7―13.7 in)

cm (17.7―13.7 in)

Rear corner ultra-

Front corner ultra-

sonic sensor/Rear

sonic sensor:

side ultrasonic sen-

Approx. 38.0―25

sor:

cm (14.9―9.8 in)

Approx. 38.0―25

cm (14.9―9.8 in)

Red

Rear ultrasonic sen-

Front ultrasonic sen-

sor:

sor:

Within approx. 35.0

Within approx. 35.0

cm (13.7 in)

cm (13.7 in)

Rear corner ultra-

Front corner ultra-

sonic sensor/Rear

sonic sensor:

side ultrasonic sen-

Within approx. 25

sor:

cm (9.8 in)

Within approx. 25

cm (9.8 in)

▼ Parking Sensor OFF Switch

sensor OFF switch indicator light turns

on.

When the parking sensor OFF switch is

pressed with the power switch

switched ON, the parking sensor

system is stopped and the parking

*Some models.

4-201

When Driving

Parking Sensor System

If the switch is pressed again, the

Without 360°view monitor

parking sensor becomes operational

and the indicator light turns off.

1. Front ultrasonic sensor gauge*

2. Right front corner ultrasonic sensor

1. Indicator light

gauge*

NOTE

3. Right rear corner ultrasonic sensor

gauge/Right rear side ultrasonic

^ The detection indicator and buzzer

sensor gauge*

of the front ultrasonic sensors/front

4. Rear ultrasonic sensor gauge

corner ultrasonic sensors do not

5. Left rear corner ultrasonic sensor

operate when the selector lever is in

gauge/Left rear side ultrasonic

the P position.

sensor gauge*

^ The detection indicator and buzzer

6. Left front corner ultrasonic sensor

sound do not activate when the

parking brake is applied.

gauge*

With 360°view monitor

▼ Obstruction Detection Indication

The position of a sensor which has

detected an obstruction is indicated.

The gauge illuminates in different areas

depending on the distance to an

obstruction detected by the sensor.

As the vehicle approaches closer to an

obstruction, the zone in the gauge

closer to the vehicle illuminates.

1. Front ultrasonic sensor gauge

2. Right front corner ultrasonic sensor

gauge

3. Right rear corner ultrasonic sensor

gauge/Right rear side ultrasonic

sensor gauge*

4. Rear ultrasonic sensor gauge

4-202 *Some models.

When Driving

Parking Sensor System

5. Left rear corner ultrasonic sensor

With 360°view monitor

gauge/Left rear side ultrasonic

sensor gauge*

6. Left front corner ultrasonic sensor

gauge

NOTE

The detection indicator can be

switched between display and

non-display and the buzzer volume

can be changed.

Refer to the Settings section in the

Mazda Connect Owner's Manual.

(Vehicles with 360° View Monitor)

Check the reason for the indication

When the detection indicator is set to

displaying on the center display or

“Display”, even with the 360° view

multi-information display.

monitor not displayed, if a front sensor

Refer to If a Warning Light Turns On or

or a front corner sensor detects an

Flashes on page 7-21.

obstruction, the 360° view monitor

switches automatically to display.

When an obstruction is no longer

detected, the display switches to the

display before the obstruction was

detected. However, while the 360°

view monitor is displayed, it continues

to display no matter if an obstruction is

detected or not.

System problem notification

The indication displays if the system

has a malfunction.

Without 360°view monitor

*Some models.

4-203

When Driving

Parking Sensor System

▼ Parking Sensor Warning Beep

Informs the driver of the approximate distance from the vehicle to the obstruction

using warning beeps depending on the distance. If multiple obstructions are

detected at the same time, warning beeps are activated according to the distance to

the nearest obstruction. The warning beeps are activated as follows while the system

is operating. However, the warning beeps are not activated while the seat belt

reminder is operating.

Front ultrasonic sensor*, Rear ultrasonic sensor

Distance De-

Distance between vehicle and obstruction

Beeper sound^*1

tection area

Front ultrasonic sensor

Rear ultrasonic sensor

Approx. 100―60.0 cm

Approx. 150―60.0 cm

(39.3―23.6 in)

(59.0―23.6 in)

Farthest dis-

Slow intermittent

tance

sound

Approx. 60.0―45.0 cm

Approx. 60.0―45.0 cm

(23.6―17.7 in)

(23.6―17.7 in)

Medium intermit-

Far distance

tent sound

Approx. 45.0―35.0 cm

Approx. 45.0―35.0 cm

(17.7―13.7 in)

(17.7―13.7 in)

Middle dis-

Fast intermittent

tance

sound

Within approx. 35.0 cm (13.7

Within approx. 35.0 cm (13.7

in)

in)

Continuous

Close distance

sound

^*1

The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction.

4-204 *Some models.

When Driving

Parking Sensor System

Front corner ultrasonic sensor*, Rear corner/Rear side* ultrasonic sensor

Distance between vehicle and obstruction

Distance Detection

Front corner ultrasonic sensor/Rear corner,

Beeper sound^*1

area

Rear side ultrasonic sensor

Approx. 55.0―38.0 cm (21.6―14.9 in)

Medium intermittent

Far distance

sound

Approx. 38.0―25 cm (14.9―9.8 in)

Middle distance

Fast intermittent sound

Within approx. 25 cm (9.8 in)

Close distance

Continuous sound

^*1

The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction.

NOTE

^ If an obstruction in the same area excluding the close area is detected

continuously for 6 seconds or longer, only the warning beeps stop activating.

(Detection is indicated) If the detection area changes to the close side, the

warning beeps resumes. (If the detection area changes to the far side, the warning

beeps remain off)

^ The sound volume (each of front and rear) can be changed.

Refer to the Settings section in the Mazda Connect Owner's Manual.

▼ When Warning Indicator/Beep is Activated

The system notifies the driver of an abnormality by activating the beep sound and

the indicator light.

*Some models.

4-205

When Driving

Parking Sensor System

Indicator/Beep

How to check

A message indicating a sys-

There may be a problem with the system. Have your vehicle inspected

tem malfunction or sensor

by an Authorized Mazda Dealer as soon as possible.

malfunction is displayed.

A message indicating that the

Remove any foreign matter from the sensor area. If the system does not

sensor is dirty is displayed.

recover, have the vehicle inspected by an Authorized Mazda Dealer.

A certain obstruction detec-

Foreign matter may have gotten on the sensor area corresponding to

tion indication is continuous-

the detection indicator. If the system does not recover, have the vehicle

ly displayed.

inspected by an Authorized Mazda Dealer.

4-206

Interior Features

Climate Control System

^ Clear all obstructions such as leaves,

For Your Ride Comfort

snow and ice from the hood and the

air inlet in the cowl grille to improve

▼ For Your Ride Comfort

the system efficiency.

^ If the vehicle has been parked in

NOTE

direct sunlight during hot weather,

If the airflow of the climate control

open the windows to let warm air

system significantly decreases, the air

escape, then run the climate control

filter may be clogged. Replace the air

system.

filter.

^ The climate control system measures

^ Use the climate control system to

defog the windows and dehumidify

inside and outside temperatures,

humidity and sunlight using the

the air.

^ Run the air conditioner about 10

sunlight/temperature sensor. It sets

temperatures inside the cabin

minutes at least once a month to

keep internal parts lubricated.

accordingly.

^ Have the air conditioner checked

before the weather gets hot. Lack of

CAUTION

refrigerant may make the air

Do not obstruct both sensors,

conditioner less efficient.

otherwise the climate control system

The refrigerant specifications are

will not operate properly.

indicated on a label attached to the

inside of the motor compartment. If

Sunlight sensor

the wrong type of refrigerant is used,

it could result in a serious

malfunction of the air conditioner.

Consult a professional, government

certified repairer for the inspection

or repair because a special device is

required for the air conditioner

maintenance.

For details, consult an Authorized

Mazda Dealer.

1. Sunlight sensor

Interior temperature sensor

1. Label

1. Interior temperature sensor

5-2

Interior Features

Climate Control System

Climate Control System Operation Area

▼ List of Climate Control System Switches/Icons

Climate control system information is displayed on the display.

Auto operation screen

ᶃ AUTO switch

page 5-4

ᶄ Seat warmer icon*

page 2-21

ᶅ Steering warmer icon*

page 2-23

ᶆ Seat warmer setting icon*

page 2-21

Steering warmer setting icon*

page 2-23

ᶇ Climate control power switch

page 5-5

ᶈ Rear window defogger switch

page 5-5

ᶉ Fan control icon

page 5-5

ᶊ Fan control switch

page 5-5

ᶋ Display setting icon

page 5-5

ᶌ ECO icon

page 5-6

ᶍ Auto and manual operation screen switching icon

page 5-6

ᶎ A/C icon

page 5-6

ᶏ Air intake selector icon

page 5-6

ᶐ Temperature control switch

page 5-5

ᶑ Temperature control icon

page 5-5

ᶒ Windshield defroster switch

page 5-6

*Some models.

5-3

Interior Features

Climate Control System

Manual operation screen

ᶃ Mode selector icon

page 5-6

NOTE

Free/open source software information

This product includes free/open sources. Information about the licensing and source

code is available at the following URL.

https://www.alpine.com/m/e/oss/download/

▼ Touch Panel Basic Operation

operation screen to the auto operation

screen.

CAUTION

▼ AUTO Switch

Do not press the screen strongly or

By pressing the AUTO switch the

press it with a sharp-pointed object.

following functions will be

Otherwise, the screen could be

automatically controlled in accordance

damaged.

with the selected set temperature:

Touch panel operation

^ Airflow temperature

^ Amount of airflow

You can do three types of icon

^ Selection of airflow mode

operations on the touch panel using

^ Outside/Recirculated air selection

your finger including, touch, touch and

^ Air conditioner (cooling, defrosting

hold, and swipe operations.

functions) operation

Switching between auto and manual



*Seat warmer level selection*1

operation screens



*Heated steering wheel operation*1

Touch the seat indication in the center

^*1

Auto mode operates when auto mode is

of the screen to switch from the auto

enabled in the Mazda Connect settings.

operation screen to the manual

Refer to the Settings section in the Mazda

operation screen. Press the AUTO

Connect Owner's Manual.

switch to switch from the manual

5-4

*Some models.

Interior Features

Climate Control System

NOTE

^ To reduce power consumption by

the climate control system, warm

AUTO switch indicator light

airflow may not be supplied when

^ ON

the ambient temperature is 25 °C

The indicator light turns on during

(77 °F) or more.

auto operation.

▼ Fan Control Switch/Icon

^ OFF

When any switch or icon is operated

The airflow amount can be adjusted to

during auto operation, including the

7 levels.

,

,

,

,

,

,

, the

The airflow amount can be adjusted by

fan control switch, or the defroster

pressing the fan control switch, or by

switch, the indicator light turns off.

touching the

or

At this time, the functions other than

In addition, when the fan control

the one operated operate

switch,

, or

is pressed and held,

automatically.

the airflow amount can be adjusted

▼ Temperature Control Switch/Icon

quickly.

The temperature setting can be

NOTE

adjusted between 15 °C (60 °F) and

^ When the

or

is swiped

29 °C (84 °F) by pressing the

upward, the airflow amount can be

temperature setting switch, or touching

increased at 3 levels. When swiped

the

(red) or

(blue).

downward, the airflow amount can

The temperature setting can be quickly

be decreased at 3 levels.

adjusted by pressing and holding the

temperature setting switch, or touching

▼ Climate Control Power Switch

(System On/Off)

and holding the

(red) or

(blue).

The climate control system turns on

and off each time the climate control

NOTE

power switch is pressed.

^ When you set the temperature to the

lower or upper limit, “LO” or “HI” is

▼ Rear Window Defogger Switch

displayed.

Press the rear window defogger switch

^ The temperature units for the

to defrost the rear window.

temperature setting display can be

When the defroster is operated, the

changed in conjunction with the

outside mirror defogger* and the

temperature units for the outside

windshield wiper de-icer* operate in

temperature display.

conjunction.

^ When swiping the

(red) or

(blue) up/down, the temperature

▼ Display Setting Icon

can be adjusted up or down in

Touch the to display the display

increments of 3 °C (6 °F).

setting screen.

You can adjust the brightness (41

levels), select the screen from

*Some models.

5-5

Interior Features

Climate Control System

Auto/Day/Night, and adjust the

▼ Air Intake Selector Icon

operation volume (mute or 3 levels).

Outside or recirculated air positions

Touch the to close the screen.

can be selected. Touch the

to

NOTE

select outside/recirculated air

For safety reasons, the setting screen is

positions.

not displayed while driving the vehicle.

WARNING

▼ ECO Icon

ECO mode switches on/off each time

Do not recirculate the air in the cabin

the icon is touched.

during cold or rainy weather:

The operation frequency of the air

Recirculating the air in the cabin during

conditioner in ECO mode is less than

cold and rainy weather is dangerous as

in normal mode, making driving more

it will cause the windows to fog up.

economical.

Your vision will be hampered, which

could lead to a serious accident.

▼ Auto and Manual Operation

Screen Switching Icon

Recirculated air position (Indicator

light next to the

turns on)

Touch the seat indication in the center

of the screen to switch to the manual

Outside air is shut off. Use this position

operation screen.

when going through tunnels, driving in

congested traffic (high engine exhaust

The

,

,

,

, and

can be

operated.

areas) or when quick cooling is

desired.

▼ A/C Icon

Outside air position (Indicator light

Touch the A/C while the AUTO switch

next to the

turns off)

is turned on will turn off the air

conditioner (cooling, defrosting

Outside air is allowed to enter the

functions).

cabin. Use this mode for ventilation or

The on/off of the air conditioner

windshield defrosting.

switches each time the A/C is

▼ Windshield Defroster Switch

touched.

While the air conditioner is operating,

Press the switch to defrost the

the indicator light next to the A/C

windshield and front door windows.

turns on.

NOTE

NOTE

The defroster can also be used by

^ The air conditioner operates when

touching the

the A/C is touched while the air

▼ Mode Selector Icon

conditioner is turned off.

^ The air conditioner may not function

When the

,

,

,

, or

is

when the outside temperature

touched, the airflow mode can be

approaches 0 °C (32 °F).

selected according to the purpose of

use.

5-6

Interior Features

Climate Control System

NOTE

Basic Climate Control

^ When on the auto operation screen,

System Operation

touch the seat indication in the

center of the screen to display the

▼ Air Conditioner Basic Operation

,

,

,

, and

icons.

Operate the air conditioner (cooling,

^ When swiping the

,

,

,

,

defrosting functions) with the EV

or

to the left, the icon two icons

system started. The air conditioner can

to the left can be selected. When

be used while charging when the

swiping to the right, the icon two

power switch is switched ON. In

icons to the right can be selected.

addition, Cabin preconditioning can

also be used when the power switch is

switched OFF.

NOTE

When the charging is completed with

the power switch switched ON, the air

conditioner (cooling, heating,

defrosting functions) stops

automatically.

1.

Press the AUTO switch. Selection of

the airflow mode, air intake

selector and amount of airflow will

be automatically controlled.

2.

Operate the temperature setting

switch/

(red) or

(blue) to

set the desired temperature.

NOTE

^ The recommended set

temperature is 22 °C (72 °F).

^ Setting the temperature to

maximum hot or cold will not

provide the desired temperature

at a faster rate.

^ The power consumption of the

air conditioner changes

depending on the set

temperature and the ambient

temperature. If the set

temperature is too low or high,

the remaining distance to full

discharge shortens.

3.

To turn off the system, press the

climate control power switch.

5-7

Interior Features

Climate Control System

▼ Adjusting the Vents

1. Knob

Directing airflow

Center Vents

To adjust the direction of airflow, move

the adjustment knob.

Air vent open/close

NOTE

^ When using the air conditioner

under humid ambient temperature

conditions, the system may blow fog

from the vents. This is not a sign of

trouble but a result of humid air

being suddenly cooled.

^ The air vents can be fully opened and

closed by operating the knob.

1. Knob

Side Vents

2. Close

3. Open

Air vent open/close

Airflow direction adjustment

1. Knob

2. Open

1. Knob

3. Close

▼ Selecting the Airflow Mode

Airflow direction adjustment

Dashboard Vents

5-8

Content      ..     9      10      11      12     ..
