Customer Information and Reporting Safety Defects

Uniform Tire Quality Grading System (UTQGS)

▼ UNIFORM TIRE QUALITY

WARNING

GRADING

Keep your vehicle's tires properly

Quality grades can be found where

inflated and not overloaded:

applicable on the tire sidewall

Driving with improperly inflated or

between tread shoulder and maximum

overloaded tires is dangerous.

section width.

Excessive speed, underinflation, or

For example:

excessive loading, either separately or

TREADWEAR 200 TRACTION AA

in combination, can cause heat

TEMPERATURE A

buildup and possible tire failure. The

UTQGS MARK (example)

temperature grade for this tire is

established for a tire that is properly

inflated and not overloaded.

These grades will be added to the

sidewalls of passenger vehicle tires

over the next several years according to

a schedule established by the NHTSA

and the tire manufacturers.

The grade of tires available as standard

or optional equipment on Mazda

vehicles may vary with respect to

grade.

ALL PASSENGER VEHICLE TIRES MUST

CONFORM TO THESE GRADES AND

TO ALL OTHER FEDERAL TIRE-SAFETY

REQUIREMENTS.

8-22

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

14.Max. permissible inflation pressure

Tire Labeling

P215/65R15 95H is an example of a

▼ Tire Labeling

tire size and load index rating. Here is

Federal law requires tire manufacturers

an explanation of the various

to place standardized information on

components of that tire size and load

the sidewall of all tires. This

index rating. Note that the tire size and

information identifies and describes

load index rating may be different from

the fundamental characteristics of the

the example.

tire and also provides a tire

identification number for safety

standard certification and in case of a

Indicates a tire that may be installed on

recall.

cars, SUVs, minivans and light trucks as

designated by the Tire and Rim

▼ Information on Passenger Vehicle

Association (T&RA).

Tires

NOTE

Please refer to the sample below.

If your tire size does not begin with a

letter this may mean it is designated by

either ETRTO (European Tire and Rim

Technical Organization) or JATMA

(Japan Tire Manufacturing

Association).

215

“215” is the nominal width of the tire

in millimeters. This three-digit number

gives the width in millimeters of the

tire from sidewall edge to sidewall

edge. In general, the larger the

1. SAFETY WARNING

number, the wider the tire.

2. Passenger car tire

3. Nominal width of tire in millimeters

4. Ratio of height to width (aspect

“65” is the aspect ratio. This two-digit

ratio)

number indicates the tire's ratio of

5. Radial

height to width.

6. Run-flat tire

7. Rim diameter code

8. TIN: U.S. DOT tire identification

“R” is the tire construction symbol. R

number

indicates “Radial ply construction”.

9. Load index & speed symbol

10.Severe snow conditions

11.Tire ply composition and materials

“15” is the wheel rim diameter in

used

inches.

12.Max. load rating

13.Tread wear, traction and

temperature grades

8-23

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

U.S. DOT Tire Identification Number

(TIN)

“95” is the Load Index. This two-or

three-digit number indicates how

This begins with the letters “DOT”

much weight each tire can support.

which indicates the tire meets all

federal standards. The next two

numbers or letters are the plant code

“H” is the speed rating. The speed

where it was manufactured, and the

rating denotes the maximum speed for

last four numbers represent the week

which the use of the tire is rated.

and year the tire was manufactured.

For example, the numbers 457 means

Letter Rating

Speed Rating

the 45st week of 1997. After 2000 the

99 mph

numbers go to four digits. For

example, the number 2102 means the

106 mph

21th week of 2002. The other

112 mph

numbers are marketing codes used at

118 mph

the manufacturer's discretion. This

information is used to contact

124 mph

consumers if a tire defect requires a

130 mph

recall.

149 mph

Tire Ply Composition and Materials

168^* mph

Used

186^* mph

The number of plies indicates the

number of layers of rubber-coated

^* For tires with a maximum speed capability over

fabric in the tire. In general, the greater

149 mph, tire manufacturers sometimes use the

the number of plies, the more weight a

letters ZR. For tires with a maximum speed

tire can support. Tire manufacturers

capability over 186 mph, tire manufacturers

also must indicate the tire materials,

always use the letters ZR.

which include steel, nylon, polyester,

M+S or M/S: Mud and Snow

and other.

AT: All Terrain.

Maximum Load Rating

AS: All Season. The “M+S” or “M/S”

This number indicates the maximum

indicates that the tire has some

load in kilograms and pounds that can

functional use in mud and snow.

be carried by the tire.

Maximum Permissible Inflation

Pressure

This number is the greatest amount of

air pressure that should ever be put in

the tire under normal driving

conditions.

8-24

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Tread Wear, Traction and Temperature

^ EXPLOSION OF TIRE/RIM ASSEMBLY

Grades

DUE TO IMPROPER

MOUNTING-MATCH TIRE

Tread wear: The tread wear grade is a

DIAMETER TO RIM DIAMETER;

comparative rating based on the wear

NEVER EXCEED 40 psi (275 kPa) TO

rate of the tire when tested under

SEAT BEADS-ONLY SPECIALLY

controlled conditions on a specified

TRAINED PERSONS SHOULD

government test course. For example,

MOUNT TIRES.

a tire graded 150 would wear one and

^ TIRE FAILURE DUE TO

one-half (1 1/2) times as well on the

UNDER-INFLATION/

government course as a tire graded

OVERLOADING/DAMAGE-FOLLOW

100.

OWNER'S MANUAL AND PLACARD

Traction: The traction grades, from

IN VEHICLE-FREQUENTLY CHECK

highest to lowest are AA, A, B, and C.

INFLATION PRESSURE AND INSPECT

The grades represent the tire's ability

FOR DAMAGE.

to stop on wet pavement as measured

under controlled conditions on

▼ Information on Temporary Tires

specified government test surfaces of

Please refer to the sample below.

asphalt and concrete. A tire marked C

may have poor traction performance.

Temperature: The temperature grades

are A (the highest), B and C,

representing the tire's resistance to the

generation of heat and its ability to

dissipate heat when tested under

controlled conditions on a specified

indoor laboratory test wheel.

Snow Tires

In some heavy snow areas, local

governments may require true snow

Temporary tires

tires, those with very deeply cut tread.

Nominal width of tire in millimeters

These tires should only be used in pairs

Ratio of height to width (aspect

or placed on all four wheels. Make

ratio)

sure you purchase snow tires that are

Diagonal

the same size and construction type as

Rim diameter code

the other tires on your vehicle.

Load index & speed symbol

SAFETY WARNING

The following safety warning appears

on the tire's sidewall.

SERIOUS INJURY MAY RESULT FROM:

8-25

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

T115/70D16 90M is an example of a

Letter Rating

Speed Rating

tire size and load index rating. Here is

81 mph

an explanation of the various

components of that tire size and load

index rating. Note that the tire size and

load index rating may be different from

the example.

Indicates a tire that may be installed on

cars, SUVs, minivans and light trucks as

designated by the Tire and Rim

Association (T&RA).

115

“115” is the nominal width of the tire

in millimeters. This three-digit number

gives the width in millimeters of the

tire from sidewall edge to sidewall

edge. In general, the larger the

number, the wider the tire.

“70” is the aspect ratio. This two-digit

number indicates the tire's ratio of

height to width.

“D” is the tire construction symbol. D

indicates “diagonal ply construction”.

“16” is the wheel rim diameter in

inches.

“90” is the Load Index. This two-or

three-digit number indicates how

much weight each tire can support.

“M” is the speed rating. The speed

rating denotes the maximum speed for

which the use of the tire is rated.

8-26

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Location of the Tire Label

WARNING

(Placard)

Always check the tire inflation

pressures on a regular basis according

▼ Location of the Tire Label (Placard)

to the recommended tire inflation

You will find the tire label containing

pressure on the tire label and in

tire inflation pressure by tire size and

conjunction with the information in

other important information on the

this owner's manual:

driver's side B-pillar or on the edge of

Driving your vehicle with

the driver's door frame.

under-inflated tires is dangerous.

Under-inflation is the most common

SAMPLE

cause of failures in any kind of tire and

may result in severe cracking, tread

separation or “blowout”, with

unexpected loss of vehicle control and

increased risk of injury. Under-inflation

increases sidewall flexing and rolling

resistance, resulting in heat buildup

and internal damage to the tire. It

results in unnecessary tire stress,

▼ Recommended Tire Inflation

irregular wear, loss of control and

Pressure

accidents. A tire can lose up to half of

its air pressure and not appear to be

On the tire label you will find the

flat!

recommended tire inflation pressure in

It is impossible to determine whether

both kPa and psi for the tires installed

or not tires are properly inflated just by

as original equipment on the vehicle. It

looking at them.

is very important that the inflation

pressure of the tires on your vehicle is

▼ Checking Tire Pressure

maintained at the recommended

1. When you check the air pressure,

pressure. You should check the tire

make sure the tires are cold

pressure regularly to insure that the

―meaning they are not hot from

proper inflation pressure is maintained.

driving even a mile.

Refer to Tires on page 9-10.

2. Remove the cap from the valve on

NOTE

one tire.

Tire pressures listed on the vehicle

3. Firmly press a tire gauge onto the

placard or tire information label

valve.

indicate the recommended cold tire

4. Add air to achieve recommended

inflation pressure, measured when the

air pressure.

tires are cold, after the vehicle has

5. If you overfill the tire, release air by

been parked for at least 3 hours. As

pushing on the metal stem in the

you drive, the temperature in the tire

center of the valve. Then recheck

warms up, increasing the tire pressure.

the pressure with your tire gauge.

6. Replace the valve cap.

8-27

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

7. Repeat with each tire, including the

road when it's mounted on the

spare.

vehicle.

NOTE

Seating capacity means the total

Some spare tires require higher

allowable number of vehicle

inflation pressure.

occupants. Seating capacity is

8. Visually inspect the tires to make

described on the tire label.

sure there are no nails or other

objects embedded that could poke

Production options weight is the

a hole in the tire and cause an air

combination weight of installed regular

leak.

production options weighing over 2.3

9. Check the sidewalls to make sure

kilograms in excess of the standard

there are no gouges, cuts, bulges,

items which they replace, and not

cracks or other irregularities.

previously considered in the curb

▼ Glossary of Terms

weight or accessory weight, including

heavy duty brakes, ride levelers, roof

Tire Placard: A label indicating the OE

rack, heavy duty battery, and special

tire sizes, recommended inflation

trim.

pressure, and the maximum weight the

vehicle can carry.

Rim is the metal support (wheel) for a

Tire Identification Number (TIN): A

tire or a tire and tube assembly upon

number on the sidewall of each tire

which the tire beads are seated.

providing information about the tire

brand and manufacturing plant, tire

size, and date of manufacture.

Inflation Pressure: A measure of the

amount of air in a tire.

kPa: Kilopascal, the metric unit for air

pressure.

psi: Pounds per square inch, the

English unit for air pressure.

B-pillar: The structural member at the

side of the vehicle behind the front

door.

Original Equipment (OE): Describes

components originally equipped on

the vehicle.

Vehicle Load Limit: The maximum

value of the combination weight of

occupants and cargo.

Bead Area of the Tire: Area of the tire

next to the rim.

Sidewall Area of the Tire: Area

between the bead area and the tread.

Tread Area of the Tire: Area on the

perimeter of the tire that contacts the

8-28

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

^ Improper wheel alignment

Tire Maintenance

^ Out-of-balance wheel

^ Severe braking

▼ Tire Maintenance

After rotation, inflate all tire pressures

Improper or inadequate vehicle

to specification on page 9-10 and

maintenance can cause tires to wear

inspect the lug nuts for tightness.

abnormally. Here are some important

maintenance points:

CAUTION

▼ Tire Inflation Pressure

Rotate unidirectional tires and radial

Inspect all tire pressure monthly

tires that have an asymmetrical tread

(including the spare) when the tires are

pattern or studs only from front to rear,

cold. Maintain recommended

not from side to side. Tire performance

pressures for the best ride, top

will be weakened if rotated from side

handling, and minimum tire wear. Use

to side.

the pressures specified on the vehicle

tire information placard or tire label for

▼ Replacing a Tire

optimum service.

WARNING

▼ Tire Rotation

To equalize tread wear, rotate the tires

Always use tires that are in good

every 16,000 km (10,000 miles) at the

condition:

latest or sooner if irregular wear

Driving with worn tires is dangerous.

develops. Mazda recommends to

Reduced braking, steering, and

rotate every 8,000 km (5,000 miles) to

traction could result in an accident.

help increase tire life and distribute

wear more evenly.

If a tire wears evenly, a wear indicator

will appear as a solid band across the

tread.

Replace the tire when this happens.

1. Forward

Do not include (TEMPORARY USE

ONLY) spare tire in rotation.

1. New tread

Inspect the tires for uneven wear and

2. Worn tread

damage. Abnormal wear is usually

3. Tread wear indicator

caused by one or a combination of the

following:

You should replace the tire before the

band crosses the entire tread.

^ Incorrect tire pressure

8-29

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

NOTE

▼ Safety Practices

Tires degrade over time, even when

The way you drive has a great deal to

they are not being used on the road. It

do with your tire mileage and safety.

is recommended that tires generally be

So cultivate good driving habits for

replaced when they are 6 years or

your own benefit.

older. Heat caused by hot climates or

frequent high loading conditions can

^ Observe posted speed limits and

accelerate the aging process. You

drive at speeds that are safe for the

should replace the spare tire when you

existing weather conditions

replace the other road tires due to the

^ Avoid fast starts, stops and turns

aging of the spare tire. The period in

^ Avoid potholes and objects on the

which the tire was manufactured (both

road

week and year) is indicated by a 4-digit

^ Do not run over curbs or hit the tire

number.

against the curb when parking

Refer to Tire Labeling on page 8-23.

CAUTION

If you feel a sudden vibration or ride

disturbance while driving or you

suspect your tire or vehicle has been

damaged, immediately reduce your

speed. Drive with caution until you can

safely pull off the road. Stop and

inspect the tire for damage. If the tire

is under-inflated or damaged, deflate

it, remove the tire and rim and replace

it with your spare tire. If you cannot

detect a cause, have the vehicle towed

to the nearest vehicle or tire dealer to

have the vehicle inspected.

8-30

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Overloading makes a vehicle harder to

Vehicle Loading

drive and control. It also increases the

distance required for stopping. In cases

▼ Vehicle Loading

of serious overloading, brakes can fail

completely, particularly on steep

WARNING

grades. The load a tire will carry safely

is a combination of the size of the tire,

Do not tow a trailer with this vehicle:

its load range, and corresponding

Towing a trailer with this vehicle is

inflation pressure.

dangerous because it has not been

Never overload the vehicle and always

designed to tow a trailer and doing so

observe the vehicle's weight ratings

will affect the drive system which could

from the vehicle's Safety Certification

result in vehicle damage.

and Tire and Load Information labels.

This section will guide you in the

Base Curb Weight is the weight of the

proper loading of your vehicle, to keep

vehicle including a full tank of fuel

your loaded vehicle weight within its

and all standard equipment. It does

design rating capability. Properly

not include passengers, cargo, or

loading your vehicle will provide

optional equipment.

maximum return of vehicle design

performance. Before loading your

Vehicle Curb Weight is the weight of

vehicle, familiarize yourself with the

your new vehicle when you picked it

following terms for determining your

up from your dealer plus any

vehicle's weight ratings, from the

aftermarket equipment.

vehicle's Safety Certification Label and

Tire and Load Information Label:

PAYLOAD

WARNING

Overloaded Vehicle:

Overloading a vehicle is dangerous.

The results of overloading can have

serious consequences in terms of

passenger safety. Too much weight on

a vehicle's suspension system can

cause spring or shock absorber failure,

brake failure, handling or steering

problems, irregular tire wear, tire

failure or other damage.

8-31

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Payload is the combination weight of

The cargo weight limit decreases

cargo and passengers that the vehicle

depending on the number of vehicle

is designed to carry. The maximum

occupants. The cargo weight limit can

payload for your vehicle can be found

be calculated by subtracting the total

on the Tire and Load Information label

weight of the vehicle occupants from

on the driver's door frame or door

the “combination weight of occupants

pillar. Look for “THE COMBINATION

and cargo should never exceed” value

WEIGHT OF OCCUPANTS AND

on the tire label.

CARGO SHOULD NEVER EXCEED XXX

kg or XXX lbs” for your maximum

Examples: Based on a single occupant

payload. The payload listed on the tire

weight of 68 kg (150 lbs), and a value

label is the maximum payload for the

of 385 kg (849 lbs) for the

vehicle as built by the assembly plant.

“combination weight of occupants and

If any aftermarket or dealer installed

cargo should never exceed”:

equipment has been installed on the

The cargo weight limit with one

vehicle, the weight of the equipment

occupant is 385 kg (849 lbs) － 68 kg

must be subtracted from the payload

(150 lbs) = 317 kg (699 lbs)

listed on the tire label in order to be

The cargo weight limit with two

accurate.

occupants is 385 kg (849 lbs) － (68 ×

2) kg ( (150 × 2) lbs) = 249 kg (549

SAMPLE

lbs)

If the weight of the occupant increases,

the cargo weight limit decreases by

that much.

GAW (Gross Axle Weight) is the total

weight placed on each axle (front and

rear) - including vehicle curb weight

and all payload.

CARGO

GAWR (Gross Axle Weight Rating) is

the maximum allowable weight that

can be carried by a single axle (front or

rear). These numbers are shown on

Cargo Weight includes all weight

the Safety Compliance Certification

added to the Base Curb Weight,

Label located on the driver's door

including cargo and optional

frame or door pillar. The total load on

equipment.

each axle must never exceed its

GAWR.

GVW

8-32

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

GVW (Gross Vehicle Weight) is the

GCW (Gross Combination Weight) is

Vehicle Curb Weight + cargo +

the weight of the loaded vehicle

passengers.

(GVW).

GVWR (Gross Vehicle Weight Rating)

GCWR (Gross Combination Weight

is the maximum allowable weight of

Rating) is the maximum allowable

the fully loaded vehicle (including all

weight of the vehicle - including all

options, equipment, passengers and

cargo and passengers - that the vehicle

cargo). The GVWR is shown on the

can handle without risking damage.

Safety Compliance Certification Label

The GCW must never exceed the

located on the driver's door frame or

GCWR.

door pillar. The GVW must never

exceed the GVWR.

WARNING

SAMPLE

Never Exceed GVWR or GAWR

Specifications:

Exceeding the GVWR or the GAWR

specified on the certification label is

dangerous. Exceeding any vehicle

rating limitation could result in a

serious accident, injury, or damage to

the vehicle.

Do not use replacement tires with

WARNING

lower load carrying capacities than the

originals because they may lower the

Never Exceed Axle Weight Rating

vehicle's GVWR and GAWR

Limits:

limitations. Replacement tires with a

Exceeding the Safety Certification

higher limit than the originals do not

Label axle weight rating limits is

increase the GVWR and GAWR

dangerous and could result in death or

limitations.

serious injury as a result of substandard

Never exceed the GVWR or the GAWR

vehicle handling, performance, engine,

specified on the certification label.

transmission and/or structural

damage, serious damage to the

vehicle, or loss of control.

Always keep the vehicle within the axle

weight rating limits.

GCW

8-33

Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

Steps for Determining the Correct Load Limit

▼ Steps for Determining the Correct Load Limit

Steps for Determining Correct Load Limit-

(1) Locate the statement “The combined weight of occupants and cargo should

never exceed XXX kg or XXX lbs.” on your vehicle's placard.

(2) Determine the combined weight of the driver and passengers that will be riding

in your vehicle.

(3) Subtract the combined weight of the driver and passengers from XXX kg or XXX

lbs.

(4) The resulting figure equals the available amount of cargo and luggage load

capacity. For example, if the “XXX” amount equals 1400 lbs. and there will be

five 150 lb passengers in your vehicle, the amount of available cargo and

luggage load capacity is 650 lbs. (1400 － 750 (5 × 150) = 650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded on the

vehicle. That weight may not safely exceed the available cargo and luggage load

capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to

your vehicle. Consult this manual to determine how this reduces the available

cargo and luggage load capacity of your vehicle.

8-34

Specifications

Identification Numbers

▼ Chassis Number

Vehicle Information

Open the cover shown in the figure to

Labels

check the chassis number.

▼ Vehicle Identification Number

The vehicle identification number

legally identifies your vehicle. The

number is on a plate attached to the

cowl panel located on the left corner

of the dashboard. This plate can easily

be seen through the windshield.

▼ Vehicle Emission Control

Information Label (U.S.A. and

Canada)

▼ Motor Vehicle Safety Standard

Label (U.S.A. and Canada)

▼ Tire Pressure Label

9-2

Specifications

▼ Engine

Specification

Item

SKYACTIV-G 2.0

SKYACTIV-G 2.5

SKYACTIV-G 2.5T

Type

DOHC-16V in-line, 4-cylinder

83.5 × 91.2 mm (3.29 ×

Bore × Stroke

89.0 × 100 mm (3.50 × 3.94 in)

3.59 in)

Displacement

1,997.6 ml (1,997.6 cc)

2,488.5 ml (2,488.5 cc)

Compression

10.5

13.0

ratio

▼ Electrical System

Item

Classification

Battery^*1

12V-60Ah/20HR or 12V-65Ah/20HR

SKYACTIV-G 2.0,

Mazda Genuine spark

PE5R-18-110 or PE5S-18-110

Spark-plug num-

SKYACTIV-G 2.5

plug^*2

ber

Mazda Genuine spark

SKYACTIV-G 2.5T

PY8V-18-110

plug^*2

^*1

Check the battery installed on the vehicle and use a battery with an equal or higher performance.

However, the performance of the battery may vary even among the same battery types, consult an

Authorized Mazda Dealer for replacement.

^*2

This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized

Mazda Dealer for details.

CAUTION

When cleaning the iridium plugs, do not use a wire brush. The fine particulate

coating on the iridium alloy and platinum tips could be damaged.

9-4

Specifications

▼ Lubricant Quality

Lubricant

Classification

Engine oil

Refer to Recommended Oil on page 6-17.

Coolant

FL-22 type

Manual transmission oil

Mazda Long Life Gear Oil G7

Automatic transmission fluid

Mazda Genuine ATF FZ

Transfer case oil

Mazda Long Life Hypoid Gear Oil SG1

Rear differential oil

Mazda Long Life Hypoid Gear Oil SG1

Brake/Clutch fluid

SAE J1703 or FMVSS116 DOT-3

NOTE

Refer to Introduction on (page 6-2) for owner's responsibility in protecting your

investment.

▼ Capacities

(Approximate Quantities)

Item

Capacity

SKYAC-

With oil filter replacement

4.2 L (4.4 US qt, 3.7 Imp qt)

TIV-G 2.0

Without oil filter replacement

4.0 L (4.2 US qt, 3.5 Imp qt)

SKYAC-

With oil filter replacement

4.5 L (4.8 US qt, 4.0 Imp qt)

Engine oil

TIV-G 2.5

Without oil filter replacement

4.3 L (4.5 US qt, 3.8 Imp qt)

SKYAC-

With oil filter replacement

4.8 L (5.1 US qt, 4.2 Imp qt)

TIV-G 2.5T

Without oil filter replacement

4.6 L (4.9 US qt, 4.0 Imp qt)

SKYAC-

Manual transmission

6.3 L (6.7 US qt, 5.5 Imp qt)

TIV-G 2.0

Automatic transmission

6.5 L (6.9 US qt, 5.7 Imp qt)

SKYAC-

Manual transmission

6.3 L (6.7 US qt, 5.5 Imp qt)

Coolant

TIV-G 2.5

Automatic transmission

6.6 L (7.0 US qt, 5.8 Imp qt)

SKYAC-

For engine

8.3 L (8.8 US qt, 7.3 Imp qt)

TIV-G 2.5T

For water-cooled charge air cooler

1.6 L (1.7 US qt, 1.4 Imp qt)

Manual trans-

SKYACTIV-G 2.0

1.70 L (1.80 US qt, 1.50 Imp qt)

mission oil

SKYACTIV-G 2.5

1.65 L (1.74 US qt, 1.45 Imp qt)

SKYACTIV-G 2.0

7.6 L (8.0 US qt, 6.7 Imp qt)

Automatic

SKYAC-

With Cylinder Deactivation

7.9 L (8.3 US qt, 7.0 Imp qt)

transmission

TIV-G 2.5

Without Cylinder Deactivation

7.6 L (8.0 US qt, 6.7 Imp qt)

fluid

SKYACTIV-G 2.5T

8.0 L (8.5 US qt, 7.0 Imp qt)

Transfer case oil

0.35 L (0.37 US qt, 0.31 Imp qt)

9-5

Specifications

Item

Capacity

Rear differential oil

0.35 L (0.37 US qt, 0.31 Imp qt)

50.0 L (13.2 US gal, 11.0 Imp

FWD

U.S.A. and

gal)

Canada

48.0 L (12.7 US gal, 10.6 Imp

AWD

gal)

Fuel tank

FWD

51.0 L (13.5 US gal, 11.2 Imp

gal)

Mexico

48.0 L (12.7 US gal, 10.6 Imp

AWD

gal)

Check oil and fluid levels with dipsticks or reservoir gauges.

▼ Dimensions

4-Door

Item

Vehicle specification

Overall length

4,662 mm (183.5 in)

Overall width

1,797 mm (70.7 in)

Overall height

1,445 mm (56.9 in)

Front tread

1,568 mm (61.7 in)

FWD

1,581 mm (62.2 in)

Rear tread

AWD

1,580 mm (62.2 in)

Wheelbase

2,726 mm (107.3 in)

5-Door

Item

Vehicle specification

Overall length

4,459 mm (175.6 in)

Overall width

1,797 mm (70.7 in)

Overall height

1,440 mm (56.7 in)

Front tread

1,568 mm (61.7 in)

FWD

1,581 mm (62.2 in)

Rear tread

AWD

1,580 mm (62.2 in)

Wheelbase

2,726 mm (107.3 in)

9-6

Specifications

▼ Weights

U.S.A. and Canada

SKYACTIV-G 2.0

(4-Door)

Weight

Item

Manual transmission

Automatic transmission

GVWR (Gross Vehicle Weight

1,804 kg (3,977 lbs)

1,825 kg (4,023 lbs)

Rating)

GAWR (Gross Axle

Front

966 kg (2,130 lbs)

989 kg (2,180 lbs)

Weight Rating)

Rear

843 kg (1,858 lbs)

841 kg (1,854 lbs)

(5-Door)

Weight

Item

Manual transmission

Automatic transmission

GVWR (Gross Vehicle Weight

1,810 kg (3,990 lbs)

1,833 kg (4,041 lbs)

Rating)

GAWR (Gross Axle

Front

965 kg (2,127 lbs)

989 kg (2,180 lbs)

Weight Rating)

Rear

848 kg (1,870 lbs)

847 kg (1,867 lbs)

SKYACTIV-G 2.5

(4-Door)

Weight

Item

FWD

AWD

GVWR (Gross Vehicle Weight

1,850 kg (4,079 lbs)

1,910 kg (4,211 lbs)

Rating)

GAWR (Gross Axle

Front

1,016 kg (2,240 lbs)

1,030 kg (2,271 lbs)

Weight Rating)

Rear

839 kg (1,850 lbs)

885 kg (1,951 lbs)

(5-Door)

Weight

FWD

Item

Automatic transmis-

AWD

Manual transmission

sion

GVWR (Gross Vehicle Weight

1,822 kg (4,017 lbs)

1,849 kg (4,076 lbs)

1,915 kg (4,222 lbs)

Rating)

GAWR (Gross Axle

Front

987 kg (2,176 lbs)

1,016 kg (2,240 lbs)

1,046 kg (2,306 lbs)

Weight Rating)

Rear

838 kg (1,847 lbs)

836 kg (1,843 lbs)

872 kg (1,922 lbs)

9-7

Specifications

SKYACTIV-G 2.5T

(4-Door)

Item

Weight

GVWR (Gross Vehicle Weight

1,950 kg (4,299 lbs)

Rating)

GAWR (Gross Axle

Front

1,066 kg (2,350 lbs)

Weight Rating)

Rear

889 kg (1,960 lbs)

(5-Door)

Item

Weight

GVWR (Gross Vehicle Weight

1,950 kg (4,299 lbs)

Rating)

GAWR (Gross Axle

Front

1,085 kg (2,392 lbs)

Weight Rating)

Rear

868 kg (1,914 lbs)

Mexico

SKYACTIV-G 2.5

(4-Door)

Weight

Item

Manual transmission

Automatic transmission

GVW (Gross Vehicle Weight)

1,861 kg (4,103 lbs)

1,870 kg (4,123 lbs)

(5-Door)

Weight

Item

Manual transmission

Automatic transmission

GVW (Gross Vehicle Weight)

1,848 kg (4,074 lbs)

1,870 kg (4,123 lbs)

SKYACTIV-G 2.5T

Item

Weight

GVW (Gross Vehicle Weight)

1,950 kg (4,299 lbs)

9-8

Specifications

▼ Light Bulbs

Exterior light

Mazda 3 Hatchback (2021 year). Manual in english - page 19
