Mazda 3 Hatchback (2021 year). Manual in english - page 17

If Trouble Arises

Flat Tire

NOTE

WARNING

When raising the jack head into the

jacking position and aligning the

Do not jack up the vehicle higher

groove in the jack head with the rail

than is necessary:

under the vehicle body, the top of

Jacking up the vehicle higher than is

the jack head contacts the vehicle's

necessary is dangerous as it could

underbody without the rail

destabilize the vehicle resulting in

contacting the bottom of the

an accident.

groove.

7.

Insert the jack lever and attach the

Do not start the engine or shake

lug wrench to tire jack.

the vehicle while it is jacked up:

Starting the engine or shaking the

vehicle while it is jacked up is

dangerous as it could cause the

vehicle to fall off the jack resulting

in an accident.

Never go under the vehicle while it

is jacked up:

Going under the vehicle while it is

jacked up is dangerous as it could

result in death or serious injury if

the vehicle were to fall off the jack.

8.

Turn the jack handle clockwise and

9.

Remove the lug nuts by turning

raise the vehicle high enough so

them counterclockwise; then

that the spare tire can be installed.

remove the wheel and center cap.

Before removing the lug nuts, make

sure your Mazda is firmly in

▼ Locking Lug Nuts

position and that it cannot slip or

move.

If your Mazda is equipped with the

optional antitheft wheel lug nuts, a

special key must be used to unlock the

locking lug nut for each wheel. The key

is stored in the glove compartment,

center console storage, storage box, or

trunk. Register the key and lug nuts

with the lock manufacturer by filling

out the registration card and mailing it

in using the accompanying envelope. If

the key is lost, consult an Authorized

Mazda Dealer or use the lock

manufacturer’s order form to order a

new key.

7-11

If Trouble Arises

Flat Tire

Antitheft wheel lug nuts cannot be

▼ Mounting the Spare Tire

installed on a steel wheel spare tire.

1. Remove dirt and grime from the

When installing a temporary spare tire,

mounting surfaces of the wheel and

use one of the original lug nuts in place

hub, including the hub bolts, with a

of the locking lug nut. The original lug

cloth.

nuts are stored inside your Mazda.

1. Antitheft lug nut

2. Special key

To remove an antitheft lug nut

WARNING

1. Obtain the special key for the

antitheft lug nut.

Make sure the mounting surfaces

2. Place the special key on top of the

of the wheel, hub and lug nuts are

antitheft lug nut, and be sure to

clean before changing or replacing

hold the key square to it. If you

tires:

hold the key at an angle, you may

When changing or replacing a tire,

damage both key and nut. Do not

not removing dirt and grime from

use a power impact wrench.

the mounting surfaces of the wheel,

3. Place the lug wrench on top of the

hub and hub bolts is dangerous.

key and apply pressure. Turn the

The lug nuts could loosen while

wrench counterclockwise.

driving and cause the tire to come

off, resulting in an accident.

To install the antitheft lug nut

2.

Mount the spare tire.

1. Place the special key on top of the

3.

Install the lug nuts with the beveled

nut, and be sure to hold the key

edge inward; tighten them by hand.

square to it. If you hold the key at

an angle, you may damage both key

and nut. Do not use a power

impact wrench.

2. Place the lug wrench on top of the

special key, apply pressure, and

turn it clockwise.

Nut tightening torque

108―147 (12―14,

N·m (kgf·m, ft·lbf)

80―108)

7-12

If Trouble Arises

Flat Tire

WARNING

WARNING

Do not apply oil or grease to lug

Always securely and correctly

nuts and bolts and do not tighten

tighten the lug nuts:

the lug nuts beyond the

Improperly or loosely tightened lug

recommended tightening torque:

nuts are dangerous. The wheel

Applying oil or grease to lug nuts

could wobble or come off. This

and bolts is dangerous. The lug nuts

could result in loss of vehicle

could loosen while driving and

control and cause a serious

cause the tire to come off, resulting

accident.

in an accident. In addition, lug nuts

and bolts could be damaged if

Be sure to reinstall the same nuts

tightened more than necessary.

you removed or replace them with

4.

Turn the jack handle

metric nuts of the same

counterclockwise using the lug

configuration:

wrench and lower the vehicle.

Because the wheel studs and lug

5.

Use the lug wrench to tighten the

nuts on your Mazda have metric

nuts in the order shown.

threads, using a non-metric nut is

dangerous. On a metric stud, it

would not secure the wheel and

would damage the stud, which

could cause the wheel to slip off

and cause an accident.

6.

(Aluminum wheel equipped

vehicle)

Remove the center cap by tapping

it from the backside of the wheel

using the lug wrench.

If you are unsure of how tight the

7.

Store the damaged tire in the trunk

nuts should be, have them

(4-door) or luggage compartment

inspected at an Authorized Mazda

(5-door).

Dealer.

Nut tightening torque

108―147 (12―14,

N·m (kgf·m, ft·lbf)

80―108)

8. Secure the damaged tire to the

vehicle using the following method.

7-13

If Trouble Arises

Flat Tire

(Vehicles with flat tire hold-down

NOTE

bolt (excluding vehicles with

The longer bolt is used as the

sub-woofer for 5-door))

bolt for securing the flat tire,

1. Spread apart the tabs on the

and the shorter one is used as

spare tire hold-down bolt that

the bolt for securing the spare

was removed when removing

tire. When installing a bolt,

the spare tire and remove the

check the bolt's length.

bolt for securing the spare tire.

3. Secure the damaged tire to the

vehicle using the flat tire

hold-down bolt.

1. Tabs

2. Bolt for securing spare tire

(Vehicles with flat tire hold-down

3. Spare tire hold-down bolt

bolt and with sub-woofer for

5-door))

2. Remove the bolt for securing the

1. Remove the bolt for securing the

flat tire from its stored position

flat tire from its stored position.

and install it in place of the

2. Secure the damaged tire to the

removed spare tire hold-down

vehicle using the flat tire

bolt.

hold-down bolt.

1. Flat tire hold-down bolt

2. Sub-woofer

1. Bolt for securing the flat tire

2. Spare tire hold-down bolt

7-14

If Trouble Arises

Flat Tire

(Vehicles without flat tire

(Wheel cover)

hold-down bolt)

1. Align the notch on the wheel

1. Secure the damaged tire to the

cover with the tire valve of the

vehicle using the spare tire

wheel and install the wheel

hold-down bolt removed when

cover to the wheel.

removing the spare tire.

1. Notch

9. Place the trunk mat (4-door) or

2. Tire valve

luggage mat (5-door) on the

damaged tire.

CAUTION

Always align the notch on the

wheel cover with the tire valve

of the wheel. Otherwise, it

could cause damage to the

wheel cover and the tire valve.

(Center cap)

1. Align the center cap with the

center hole of the wheel and

install the center cap to the

wheel.

10.Remove the tire blocks and store

the tools and jack.

11.Check the inflation pressure. Refer

to Tires on page 9-10.

12.Have the flat tire repaired or

replaced as soon as possible.

13.After repairing or replacing the flat

tire, install the wheel cover

(vehicles with steel wheels) or

center cap (vehicles with aluminum

wheels) using the following

procedure.

7-15

If Trouble Arises

Battery Runs Out

Connect the negative cable to a good ground point away from the battery:

Connecting the end of the second jumper cable to the negative (-) terminal of the

discharged battery is dangerous.

A spark could cause the gas around the battery to explode and injure someone.

Route the jumper cables away from parts that will be moving:

Connecting a jumper cable near or to moving parts (cooling fans, belts) is

dangerous. The cable could get caught when the engine starts and cause serious

injury.

CAUTION

Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and

other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in

series or a 24 V motor generator set).

1. Move the booster vehicle so that its battery is as close as possible to your

vehicle's battery.

2. Make sure that the power such as for the headlights and air conditioner is turned

off.

3. Remove the battery cover.

4. Turn off the booster vehicle's engine and connect the jumper cables in the

following order.

Make sure that the jumper cables are securely connected so that they do not

disconnect due to engine vibrations.

7-18

If Trouble Arises

Battery Runs Out

1st lead

Positive (+) terminal on the discharged battery

Positive (+) terminal on booster vehicle's battery

2nd lead

Negative (-) terminal on booster vehicle's battery

Location shown in the figure (do not connect to the negative (-) terminal of

the battery)

5. Start the booster vehicle's engine and rev the engine.

6. Start the engine of your vehicle. Run the engines for about 3 minutes to

temporarily charge the battery of your vehicle.

7. Disconnect the jumper cables in the reverse order of their connection.

8. Install the battery cover.

9. Have your vehicle inspected by an Authorized Mazda Dealer as soon as possible.

7-19

If Trouble Arises

Emergency Starting

Starting a Flooded Engine

Push-Starting

▼ Starting a Flooded Engine

▼ Push-Starting

If the engine fails to start, it may be

Do not push-start your Mazda.

flooded (excessive fuel in the engine).

WARNING

Follow this procedure:

Never tow a vehicle to start it:

1. If the engine does not start within 5

Towing a vehicle to start it is

seconds on the first try, wait 10

dangerous. The vehicle being towed

seconds and try again.

could surge forward when its engine

2. Make sure the parking brake is on.

starts, causing the 2 vehicles to collide.

3. Depress the accelerator all the way

The occupants could be injured.

and hold it there.

4. Depress the clutch pedal (manual

transmission) or the brake pedal

CAUTION

(automatic transmission), then

Do not push-start a vehicle that has a

press the push button start. If the

manual transmission. It can damage

engine starts, release the

the emission control system.

accelerator immediately because

the engine will suddenly rev up.

5. If the engine fails to start, crank it

NOTE

without depressing the accelerator.

You cannot start a vehicle with an

automatic transmission by pushing it.

If the engine still does not start using

the previous procedure, have your

vehicle inspected by an Authorized

Mazda Dealer.

7-20

If Trouble Arises

Overheating

Open the hood ONLY after steam is

Overheating

no longer escaping from the engine:

Steam from an overheated engine is

▼ Overheating

dangerous. The escaping steam could

If the engine coolant temperature

seriously burn you.

gauge indicates overheating and the

If the engine coolant temperature

high engine coolant temperature

gauge indicates overheating and the

warning indication is displayed, the

high engine coolant temperature

vehicle loses power or you hear a loud

warning indication is displayed:

knocking or pinging noise, the engine

is probably too hot.

1.

Drive safely to the side of the road

WARNING

and park off the right-of-way.

2.

Put a vehicle with an automatic

transmission in park (P), a manual

transmission in neutral.

3.

Apply the parking brake.

Pull over to a safe location, then

4.

Turn off the air conditioner.

switch the ignition off and make sure

5.

Check whether coolant or steam is

the fan is not running before

escaping from the engine

attempting to work near the cooling

compartment.

fan:

Working near the cooling fan when it is

If steam is coming from the engine

running is dangerous. The fan could

compartment:

continue running indefinitely even if

Do not go near the front of the

the engine has stopped and the engine

vehicle. Stop the engine.

compartment temperature is high. You

Wait until the steam dissipates,

could be hit by the fan and seriously

then open the hood and start the

injured.

engine.

If neither coolant nor steam is

escaping:

Do not remove either

Open the hood and idle the engine

cooling system cap when the engine

until it cools.

and radiator are hot:

When the engine and radiator are hot,

CAUTION

scalding coolant and steam may shoot

out under pressure and cause serious

If the cooling fan does not operate

injury.

while the engine is running, the

engine temperature will increase.

Stop the engine and call an

Authorized Mazda Dealer.

7-21

If Trouble Arises

Overheating

6. Make sure the cooling fan is

2. Cooling fan

operating, then turn off the engine

3. Cooling system cap

after the temperature has

decreased.

If you find no problems, the engine is

7. When cool, check the coolant level.

cool, and no leaks are obvious:

If it is low, look for coolant leaks

Carefully add coolant as required

from the radiator and hoses.

(page 6-20).

If you find a leak or other damage, or

CAUTION

if coolant is still leaking:

If the engine continues to overheat or

Stop the engine and call an Authorized

frequently overheats, have the cooling

Mazda Dealer.

system inspected. The engine could be

SKYACTIV-G 2.0 and SKYACTIV-G

seriously damaged unless repairs are

2.5

made. Consult an Authorized Mazda

Dealer.

1. Cooling system cap

2. Cooling fan

3. Coolant reservoir

SKYACTIV-G 2.5T

1. Coolant reservoir

7-22

If Trouble Arises

Emergency Towing

Towing Description

WARNING

▼ Towing Description

Always tow an AWD vehicle with all

four wheels off the ground:

We recommend that towing be done

Towing an AWD vehicle with either the

only by an Authorized Mazda Dealer

front or rear wheels on the ground is

or a commercial tow-truck service.

dangerous as the drive train could be

damaged, or the vehicle could trail

Proper lifting and towing are necessary

away from the tow truck and cause an

to prevent damage to the vehicle.

accident. If the drive train has been

Particularly when towing an AWD

damaged, transport the vehicle on a

vehicle, where all the wheels are

flatbed truck.

connected to the drive train, proper

transporting of the vehicle is absolutely

essential to avoid damaging the drive

system. Government and local laws

must be followed.

CAUTION

¾ Do not tow the vehicle pointed

backward with driving wheels on the

1. Wheel dollies

ground. This may cause internal

damage to the transmission.

A towed FWD vehicle should have its

drive wheels (front wheels) off the

ground. If excessive damage or other

conditions prevent this, use wheel

dollies.

When towing a FWD vehicle with the

rear wheels on the ground, release the

parking brake.

Refer to Electric Parking Brake (EPB) on

page 4-66.

A towed AWD vehicle must have all its

wheels off the ground.

7-23

If Trouble Arises

Emergency Towing

¾ Do not tow with sling-type

Tiedown Hooks

equipment. This could damage your

vehicle. Use wheel-lift or flatbed

▼ Tiedown Hooks

equipment.

CAUTION

Do not use the front and rear tiedown

eyelets for towing the vehicle.

They have been designed only for

securing the vehicle to a transport

vessel during shipping.

¾ If the parking brake cannot be

Using the eyelets for any other purpose

released when towing the vehicle,

could result in the vehicle being

transport the vehicle with all front

damaged.

and rear wheels raised off the ground

1. Remove the tiedown eyelet and the

as shown in the figure. If the vehicle

lug wrench from the luggage

is towed without raising the wheels

compartment (page 7-3).

off the ground, the brake system

2. Wrap a flathead screwdriver or

could be damaged.

similar tool with a soft cloth to

prevent damage to a painted

bumper, and open the cap located

on the front or rear bumper.

Front

(4-Door)

1. Wheel dollies

7-24

*Some models.

If Trouble Arises

Emergency Towing

(5-Door)

NOTE

Remove the cap completely and

store it so as not to lose it.

3. Securely install the tiedown eyelet

using the lug wrench.

Front

(4-Door)

Rear

(4-Door)

1. Lug wrench

2. Tiedown eyelet

(5-Door)

(5-Door)

1. Lug wrench

2. Tiedown eyelet

Rear

CAUTION

Do not use excessive force as it may

damage the cap or scratch the

painted bumper surface.

7-25

If Trouble Arises

Emergency Towing

(4-Door)

1. Lug wrench

2. Tiedown eyelet

(5-Door)

1. Lug wrench

2. Tiedown eyelet

4. Hook the tying rope to the tiedown

eyelet.

CAUTION

If the tiedown eyelet is not securely

tightened, it may loosen or

disengage from the bumper when

tying the vehicle. Make sure that

the tiedown eyelet is securely

tightened to the bumper.

7-26

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Brake System Warning Indication/

▼

If a Warning Light Turns

Warning Light

On or Flashes

▼ If a Warning Light Turns On or

Flashes

If any warning light turns on/flashes,

take appropriate action for each light.

This warning has the following

There is no problem if the light turns

functions:

off, however if the light does not turn

Warning light inspection

off or turns on/flashes again, consult

an Authorized Mazda Dealer.

For an operation check, make sure that

The details for some warnings can be

the light turns on when the ignition is

viewed on the center display or

switched on, and turns off a few

multi-information display in the

seconds later or when the engine is

instrument cluster.

started.

Center display

When the light turns on

1. Select “Information” on the home

If the brake system warning light

screen.

remains illuminated the brake fluid

2. Select “Vehicle Status Monitor”.

may be low or there could be a

3. Select the applicable warning to

problem with the brake system. Park

view the warning details.

the vehicle in a safe place immediately

and contact an Authorized Mazda

NOTE

Dealer.

You can also display the currently

Refer to Inspecting Brake/Clutch Fluid

occurring warning by sliding the

Level on page 6-21.

commander knob to the left while on

the home screen of the center display.

WARNING

Multi-information display

Do not drive with the brake system

1. Press the INFO switch on the

warning light illuminated. Contact an

steering switch to display the

Authorized Mazda Dealer to have the

warning indication screen.

brakes inspected as soon as possible:

Refer to Multi-information Display

Driving with the brake system warning

on page 4-14.

light illuminated is dangerous. It

indicates that your brakes may not

work at all or that they could

completely fail at any time. If this light

remains illuminated, after checking

that the parking brake is fully released,

have the brakes inspected

immediately.

7-27

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Charging System Warning

CAUTION

Indication/Warning Light

¾ In addition, the effectiveness of the

braking may diminish so you may

need to depress the brake pedal

more strongly than normal to stop

the vehicle.

If the warning light illuminates while

driving, it indicates a malfunction of

▼ Electronic Brake Force Distribution

the alternator or of the charging

System Warning

system.

Drive to the side of the road and park

off the right-of-way. Consult an

Authorized Mazda Dealer.

CAUTION

If the electronic brake force

Do not continue driving when the

distribution control unit determines

charging system warning light is

that some components are operating

illuminated because the engine could

incorrectly, the control unit may

stop unexpectedly.

illuminate the brake system warning

light and the ABS warning light

▼ Engine Oil Warning Indication/

simultaneously. The problem is likely to

Warning Light

be the electronic brake force

distribution system.

WARNING

Do not drive with both the brake

This warning light indicates low engine

system warning light and ABS warning

oil pressure.

light illuminated. Have the vehicle

towed to an Authorized Mazda

CAUTION

Dealer to have the brakes inspected as

soon as possible:

Do not run the engine if the oil

Driving when the brake system warning

pressure is low. Otherwise, it could

light and ABS warning light are

result in extensive engine damage.

illuminated simultaneously is

If the light illuminates or the warning

dangerous.

indication is displayed while driving:

When both lights are illuminated, the

1. Drive to the side of the road and

rear wheels could lock more quickly in

park off the right-of-way on level

an emergency stop than under normal

ground.

circumstances.

2. Turn off the engine and wait 5

minutes for the oil to drain back

into the oil pan.

7-28

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

3. Inspect the engine oil level (page

CAUTION

6-19). If it's low, add the

appropriate amount of engine oil

Do not drive the vehicle with the high

while being careful not to overfill.

engine coolant temperature warning

light illuminated. Otherwise, it could

CAUTION

result in damage to the engine.

Do not run the engine if the oil

▼ Power Steering Malfunction

level is low. Otherwise, it could

Indication/Indicator Light

result in extensive engine damage.

4. Start the engine and check the

warning light.

If the light remains illuminated even

though the oil level is normal or after

The message is displayed if the electric

adding oil, stop the engine

power steering has a malfunction.

immediately and have your vehicle

If the message is displayed, stop the

towed to an Authorized Mazda Dealer.

vehicle in a safe place and do not

operate the steering wheel. There is no

▼ High Engine Coolant Temperature

problem if the indication turns off

Warning Indication

when the engine is restarted after

some time has passed. If the indication

displays even after the engine is

restarted, contact an Authorized

Mazda Dealer if the message is

displayed continuously.

Displays if the engine coolant

temperature has increased excessively.

NOTE

“Elevated Engine Coolant Temp. Drive

^ If the message is displayed, the

Slowly” displayed

power steering will not operate

normally. In this case, the steering

Drive slowly to reduce engine load

wheel can still be operated,

until you can find a safe place to stop

however, the operation may feel

the vehicle and wait for the engine to

heavy compared to normal, or the

cool down.

steering wheel could vibrate when

“Excessive Engine Coolant Temp. Stop

turning.

the Vehicle in a Safe Location”

^ Repeatedly jerking the steering

displayed

wheel left and right while the vehicle

is stopped or moving extremely

This indicates the possibility of

slowly will cause the power steering

overheating. Park the vehicle in a safe

system to go into protective mode

place immediately and stop the

which will make the steering feel

engine.

heavy, but this does not indicate a

Refer to Overheating on page 7-21.

problem. If this occurs, park the

vehicle safely and wait several

minutes for the system to return to

normal.

7-29

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ ABS Warning Indication/Warning

▼

Brake Control System Warning

Light

Indication/Warning Light

If the ABS warning light stays on while

The warning light illuminates when the

you're driving, the ABS control unit has

system has a malfunction. Have your

detected a system malfunction. If this

vehicle inspected at an Authorized

occurs, your brakes will function

Mazda Dealer.

normally as if the vehicle had no ABS.

▼ Electric Parking Brake (EPB)

Should this happen, consult an

Indication/Indicator Light

Authorized Mazda Dealer as soon as

possible.

NOTE

^ When the engine is jump-started to

charge the battery, uneven rpm

occurs and the ABS warning light

This warning has the following

may illuminate. If this occurs, it is the

functions:

result of the weak battery and does

Parking brake warning/Indicator light

not indicate an ABS malfunction.

inspection

Recharge the battery.

^ The brake assist system does not

The light illuminates when the parking

operate while the ABS warning light

brake is applied with the ignition

is illuminated.

switched to START or ON. It turns off

when the parking brake is released.

▼ Master Warning Indication

When the light is flashing

The light flashes if the Electric Parking

Brake (EPB) has a malfunction. If the

light remains flashing even if the

Electric Parking Brake (EPB) switch is

The indication displays if the system

operated, consult an Authorized

has a malfunction.

Mazda Dealer as soon as possible.

Check the reason for the indication

displaying on the center display or

multi-information display.

Refer to If a Warning Light Turns On or

Flashes on page 7-27.

7-30

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Brake Override Warning Indication

WARNING

If the check engine light turns on, do

not disconnect the battery cables.

If the battery cables are disconnected

This message is displayed when the

and then reconnected, the engine

accelerator pedal and brake pedal are

could be damaged and catch on fire.

depressed at the same time while

driving.

▼ Automatic Transmission Warning

Release the accelerator pedal and

Indication/Warning Light*

depress the brake pedal.

▼ Check Engine Indication/Light

The indication/light illuminates when

the transmission has a problem.

If this light illuminates while driving,

CAUTION

the vehicle may have a problem. It is

important to note the driving

If the automatic transmission warning

conditions when the light illuminated

indication/light illuminates, the

and consult an Authorized Mazda

transmission has an electrical problem.

Dealer.

Continuing to drive your Mazda in this

The check engine light may illuminate

condition could cause damage to your

in the following cases:

transmission. Consult an Authorized

Mazda Dealer as soon as possible.

^ The engine's electrical system has a

problem.

▼ AWD Warning Indication/

^ The emission control system has a

Warning Light*

problem.

^ The fuel-filler cap is missing or not

tightened securely.

^ The fuel tank level being very low or

approaching empty.

If the check engine light remains on, or

“AWD Malfunction. Front Wheel

it flashes continuously , do not drive at

Drive Only. Have the Vehicle

high speeds and consult an Authorized

Inspected” is displayed/When the

Mazda Dealer as soon as possible.

light is turned on

The indication is displayed/the light

turns on under the following

conditions. The system may have a

malfunction. Have the vehicle checked

at an Authorized Mazda Dealer.

*Some models.

7-31

If Trouble Arises

Warning/Indicator Lights and Warning Sounds



When there is a malfunction in the

▼ TCS/DSC Indication/Indicator

AWD system.

Light (Turns on)

“Excessive AWD System Load. Drive

Slowly Until Warning Light Turns Off.

Vehicle Now in Front Wheel Drive” is

displayed/When the light is flashing

The indication is displayed/the light

If the light stays on, the TCS, DSC or

flashes under the following conditions.

the brake assist system may have a

Park the vehicle in a safe place and

malfunction and they may not operate

check that the warning indication light

correctly. Take your vehicle to an

turns off/ the warning light stops

Authorized Mazda Dealer.

flashing, and then drive the vehicle.

Contact an Authorized Mazda Dealer

▼ Air Bag/Front Seat Belt

if the indication is continuously

Pretensioner System Warning

displayed.

Indication/Warning Light

^ When the differential oil temperature

is excessively high.

^ When there is a large difference

between the front and rear wheel

rotation, such as when trying to

A system malfunction is indicated if the

remove the vehicle from mud.

warning light constantly flashes,

“Mismatched Tire Diameters. Vehicle

constantly illuminates or does not

Now in Front Wheel Drive” is

illuminate at all when the ignition is

displayed/When the light is turned on

switched ON. If any of these occur,

consult an Authorized Mazda Dealer

The indication is displayed/the light

as soon as possible. The system may

turns on under the following

not operate in an accident.

conditions. Inspect the tire sizes or tire

pressures on all 4 wheels. Contact an

WARNING

Authorized Mazda Dealer if the

indication remains on or the warning

Never tamper with the air bag/

light remains illuminated.

pretensioner systems and always have

^ When any of the tire diameter is

an Authorized Mazda Dealer perform

different.

all servicing and repairs:

^ When any of the tire pressure is

Self-servicing or tampering with the

incorrect.

systems is dangerous. An air bag/

pretensioner could accidentally

activate or become disabled causing

serious injury or death.

7-32

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Tire Pressure Monitoring System

▼

KEY Warning Indication/Warning

(TPMS) Warning Indication/

Light (Red)

Warning Light (Flashing)

“Keyless Entry System Malfunction.

If there is a problem with the TPMS or

Have the Vehicle Inspected” is

the voltage of a tire pressure sensor

displayed

decreases, the TPMS warning light

flashes and a message is displayed on

This message is displayed if the

the multi-information display. Have

advanced keyless entry & push button

your vehicle inspected by an

start system has a problem.

Authorized Mazda Dealer.

Contact an Authorized Mazda Dealer.

WARNING

CAUTION

If the message is indicated, or the push

Do not drive the vehicle at high

button start indicator light (amber)

speeds if the TPMS warning light turns

flashes, the engine may not start. If the

on or flashes:

engine cannot be started, try starting it

Driving the vehicle at high speeds

using the emergency operation for

while the TPMS warning light is turned

starting the engine, and have the

on or flashing is dangerous because

vehicle inspected at an Authorized

the brake performance and the

Mazda Dealer as soon as possible.

steering wheel operability will be

Refer to Emergency Operation for

reduced. If the vehicle is driven at high

Starting the Engine on page 4-9.

speeds or the brakes are suddenly

applied, it could lead to an accident.

Gradually apply the brakes to lower the

vehicle's speed.

Do not ignore the TPMS warning light

when it is turned on or flashing:

Continuing to drive the vehicle while

ignoring the illumination/flashing of

the TPMS warning light is dangerous

because a tire may burst which could

lead to an accident. Take appropriate

measures as soon as possible.

7-33

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

“Key Not Detected” is displayed

▼ High Beam Control System (HBC)

Warning Indication/Warning Light

^ If the presence of the key cannot be

(Amber)*

detected (dead battery, battery

malfunction, no key), it is displayed

when the driver attempts to start the

engine (push button start operation,

brake pedal depression).

^ Displayed when it is determined that

a key that was in the vehicle has

The light remains turned on if there is a

been removed from the vehicle. (Key

problem with the system. Have your

taken out warning. Other than

vehicle inspected at an Authorized

IG-OFF).

Mazda Dealer.

▼ Security Indicator Light

▼ i-ACTIVSENSE Warning

Indication/Warning Light*

If the security indicator light flashes

continuously while you are driving, do

The indication displays if the system

not shut off the engine. Go to an

has a malfunction.

Authorized Mazda Dealer and have it

Check the reason for the indication

checked. If the engine is shut off while

displaying on the center display or

the indicator light is flashing, you will

multi-information display.

not be able to restart it.

Refer to If a Warning Light Turns On or

Make sure the key is within the

Flashes on page 7-27.

operational range for signal

▼ Exterior Light Warning Indication/

transmission. Switch the ignition off,

Warning Light

and then restart the engine. If the

engine does not start after 3 or more

tries, contact an Authorized Mazda

Dealer.

NOTE

Because the electronic codes are reset

This light illuminates if there is a

when the immobilizer system is

malfunction in the exterior lights

repaired, the keys are needed. Make

(except license plate lights). Have your

sure to bring all the keys to an

vehicle inspected by an Authorized

Authorized Mazda Dealer so that they

Mazda Dealer.

can be programmed.

7-34

*Some models.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Check Fuel Cap Warning

CAUTION

Indication/Warning Light

Do not drive the vehicle while an

exterior light has a malfunction. Poor

visibility, and not being able to signal

braking and turns may cause an

accident. In addition, if the vehicle is

driven with the lights not turned on, it

If the check fuel cap warning light

may conflict with laws and regulations

illuminates while driving, the fuel-filler

due to poor maintenance.

cap may not be installed properly.

▼ Low Fuel Warning Indication/

Action to be taken

Warning Light

Stop the engine and reinstall the

fuel-filler cap.

Refer to Refueling on page 3-28.

▼ Engine Oil Level Warning

Indication/Warning Light

The warning indication/warning light

displays/turns on when the ignition is

switched ON and the remaining fuel is

about 9 L (2.3 US gal, 1.9 Imp gal) or

the remaining distance to empty is 50

km (31 miles) or shorter. The warning

This warning light indicates that the

light flashes when the vehicle

engine oil level is around the MIN

continues to be driven with the

mark (page 6-19).

warning indication/warning light

displayed/turned on and the

CAUTION

remaining fuel in the tank is near

empty.

Do not continue to drive the vehicle

with the engine oil level warning

NOTE

indication/warning light displayed/

The light illumination timing may vary

turned on. If the vehicle continues to

because fuel inside the fuel tank moves

be driven with an insufficient amount

around according to the driving

of engine oil, it could cause damage to

conditions and the vehicle posture.

the engine.

Action to be taken

Action to be taken

Add fuel. If the light is flashing, refuel

Add 1 L (0.26 US gal, 0.22 Imp gal) of

as soon as possible.

engine oil (page 6-17).

7-35

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Seat Belt Warning Indication/

Action to be taken

Warning Light (Front seat)

Fasten the seat belts.

▼ Seat Belt Warning Light (Rear seat)

(Red)

The seat belt warning light turns on if

If the rear seat belts are not fastened

the driver or front passenger's seat is

while the ignition is switched ON , the

occupied and the seat belt is not

driver and the passenger are alerted by

fastened with the ignition switched

the warning light.

ON.

The warning light operates even if there

If the driver or front passenger's seat

is no passenger on the rear seat.

belt is unfastened (only when the front

passenger's seat is occupied) and if the

NOTE

vehicle is driven at about 20 km/h (12

If a rear seat belt is not fastened by a

mph) or faster, or about 10 km/h (6

certain period of time after the engine

mph) or faster for a continuous 30

has been started, the warning light

seconds, with the seat belt unfastened,

turns off.

the warning light flashes for a certain

Action to be taken

period. After a short time, the warning

light stops flashing, but remains

Fasten the seat belts.

illuminated.

▼ Low Washer Fluid Level Warning

NOTE

Indication/Warning Light*

^ The warning light flashes for about 6

seconds if the driver or front

passenger's seat is not fastened

when the ignition is switched ON.

(Except Mexico)

^ Placing heavy items on the front

This warning light indicates that little

passenger's seat may cause the front

washer fluid remains.

passenger's seat belt warning

Action to be taken

function to operate depending on

the weight of the item.

Add washer fluid (page 6-22).

^ To allow the front passenger

occupant classification sensor to

function properly, do not place and

sit on an additional seat cushion on

the front passenger's seat. The

sensor may not function properly

because the additional seat cushion

could cause sensor interference.

^ If a small child is seated on the front

passenger's seat, the warning light

may not operate.

7-36

*Some models.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

▼ Door-Ajar/Trunk lid-Ajar/

WARNING

Liftgate-Ajar Warning Indication/

Warning Light

Do not drive the vehicle at high

speeds if the TPMS warning light turns

on or flashes:

Driving the vehicle at high speeds

while the TPMS warning light is turned

on or flashing is dangerous because

the brake performance and the

steering wheel operability will be

reduced. If the vehicle is driven at high

speeds or the brakes are suddenly

applied, it could lead to an accident.

The light turns on if any door/trunk

Gradually apply the brakes to lower the

lid/liftgate is not closed securely.

vehicle's speed.

Action to be taken

Do not ignore the TPMS warning light

Close the door/trunk lid/liftgate

when it is turned on or flashing:

securely.

Continuing to drive the vehicle while

▼ Tire Pressure Monitoring System

ignoring the illumination/flashing of

(TPMS) Warning Indication/

the TPMS warning light is dangerous

Warning Light (Turns on)

because a tire may burst which could

lead to an accident. Take appropriate

measures as soon as possible.

NOTE

While the TPMS is learning the tire

If a tire pressure decreases below the

positions, such as immediately after a

specified air pressure, the TPMS

tire position has been changed, the tire

warning light turns on.

pressure at the tire position prior to it

At the same time, a message and the

being changed is displayed until the

tire pressure of each tire are displayed

system completes the learning. For this

on the multi-information display

reason, the tire pressures displayed for

alternately. In addition, the tire (s) with

the tire positions may be different from

low air pressure is displayed in yellow.

the actual tire pressures at the tire

positions.

Action to be taken

Adjust the tire pressures to the

appropriate pressures.

Refer to Tire Inflation Pressure on page

6-34.

7-37

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Message Indicated on Multi-information Display

▼ Message Indicated on Multi-information Display

If there is a notification from the vehicle, a message is displayed on the

multi-information display. Check the information and take the necessary action.

1. Multi-information display

If the warning light turns on/flashes simultaneously or a symbol is indicated on the

display, check the information regarding the warning light or symbol.

Refer to If a Warning Light Turns On or Flashes on page 7-27.

Display^*1*2

Content

Action to be taken

This message is indicated when there

Depress the brake pedal. Cancel the

is a problem with the brake related

Depress Brake Pedal.

AUTOHOLD function and have your

system while the vehicle is being held

Brake Hold Disabled

vehicle inspected at an Authorized

in a stop position by the AUTOHOLD

Mazda Dealer.

function.

This message indicates the possibility

Steep Slope. Continue

of the vehicle not being held in the

Depress and hold your foot on the

Pressing Brake Pedal to

stopped position by the AUTOHOLD

brake pedal.

Hold Stopped Position

function, such as on steep slopes.

This message is indicated when the

Depress Brake Pedal and

Operate the Electric Parking Brake

Electric Parking Brake (EPB) switch is

Operate Switch to Re-

(EPB) switch while depressing the

operated without depressing the

lease Elec. Parking Brake

brake pedal.

brake pedal.

This message is indicated when the

Depress Brake Pedal and

cancel operation is done without de-

Cancel the AUTOHOLD function stop

Operate Switch to Re-

pressing the brake pedal while the

hold control while depressing the

lease

vehicle is being held in the stopped

brake pedal.

position by the AUTOHOLD function.

7-39

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Display^*1*2

Content

Action to be taken

This message is indicated when the

Mazda Radar Cruise Control

Mazda Radar Cruise

(MRCC), Mazda Radar Cruise Con-

Have your vehicle inspected by an

Control Canceled. Drive

trol with Stop & Go function (MRCC

Authorized Mazda Dealer.

Safely

with Stop & Go function), and the

Traffic Jam Assist (TJA) have been can-

celed other than by the driver.

This message is indicated when the

Distance & Speed Alert

Distance & Speed Alert (DSA) have

Have your vehicle inspected by an

Operation Canceled

been canceled other than by the driv-

Authorized Mazda Dealer.

Drive Safely

er.

Cruise Control Opera-

This message is indicated when the

Have your vehicle inspected by an

tion Canceled. Drive

Cruise Control have been canceled

Authorized Mazda Dealer.

Safely

other than by the driver.

This message is indicated after the

Emergency Braking Acti-

Smart Brake Support (SBS) brakes op-

vated. Depress Brake

Depress the brake pedal.

erate and when the Smart Brake Sup-

Pedal to Hold Stop

port (SBS) is canceled.

Touch the key against push button

This message is indicated when the

Touch Key Fob to Push

start to start the engine.

key battery is weak (battery dead or

Button Start Switch

Refer to Engine Start Function When

damaged key).

Key Battery is Dead on page 4-8.

This message is indicated when the

When starting the engine, press the

Depress Brake Pedal to

push button start is pressed without

push button start with the brake ped-

Start Vehicle

depressing the brake pedal.

al depressed.

This message is indicated when the

When starting the engine, press the

Depress Clutch Pedal to

push button start is pressed without

push button start with the clutch

Start Vehicle

depressing the clutch pedal.

pedal depressed.

This message is indicated when the

Check Gear Selector

selector lever is shifted to the P or R

Check the selector lever position.

Lever Position

position while driving.

This message is indicated when AU-

Close Door and Fasten

TOHOLD is about to operate and a

When the AUTOHOLD is turned on,

Seat Belt

door is opened or a seat belt is unfas-

close the doors and fasten seat belts.

tened.

Wiper Blades Must Be

This message is indicated when the

Return the wiper arms to the initial

on Windshield Before

ignition is switched ON with the wip-

positions.

Operating

er arms at the service positions.

7-40

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Display^*1*2

Content

Action to be taken

This message is indicated when there

Windshield Wiper Range

is snow or dirt accumulation on the

Remove foreign matter from the

of Motion Reduced. Re-

windshield and the wiper operation

windshield.

move Obstruction(s)

range is narrowed.

This message is indicated when the

Vehicle Not Switched

Switch the ignition OFF before leaving

driver’s door is opened without

Off

the vehicle.

switching the ignition OFF.

Displays when the push button start

Gear Selector Lever Not

is pressed while the selector lever is

Shift the selector lever to the P posi-

in Park

in a position other than P, and the ig-

tion and then switch the ignition OFF.

nition is switched to ACC.

Excessive Transmission

This message is indicated when the

Drive slowly to reduce load on the

Temperature. Drive

internal temperature of the automatic

automatic transmission.

Slowly

transmission is high.

Excessive Transmission

This message is indicated when the

Park the vehicle in a safe place imme-

Temp. Stop Vehicle in a

automatic transmission fluid temper-

diately and contact an Authorized

Safe Location

ature is abnormally high.

Mazda Dealer.

^*1

A pop-up is displayed when a warning occurs.

^*2

One screen displays four rows. If the entire message cannot be displayed on the screen, it switches to

another screen.

7-41

Content      ..     15      16      17      18     ..
