Maintenance and Care

Scheduled Maintenance

Number of times, maintenance was performed.

Maintenance Item

Brake lines, hoses and connections

Vacuum brake booster and

With vac-

hose

uum booster

Brake and clutch fluid level

With electri-

Brake fluid

cal booster

Disc brakes

Tire rotation

Rotate every 16,000 km (10,000 miles).

Tire inflation pressure and tire wear^*4

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

Driveshaft dust boot

Bolts and nuts on chassis and body

Exhaust system and heat shields

Emergency flat tire repair kit (if equipped)^*5

Inspect annually.

Replace every 48,000 km (30,000 miles) or 24

Cabin air filter

months.

Function of all lights

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

R: Replace

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22

may cause serious damage to the engine and cooling system.

^*3

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*4

Inspect a spare tire if equipped.

^*5

Check the tire repair fluid expiration date every year when performing the periodic maintenance.

Replace the tire repair fluid bottle with new one before the expiration date.

6-5

Maintenance and Care

Scheduled Maintenance

USA and Puerto Rico Residents (Severe Driving Scheduled Maintenance):

Number of months or kilometers (miles), whichever comes first.

Months

× 1000 km

× 1000 miles

Engine oil & filter ^*1

Maintenance Interval (other than engine oil

1st

2nd

3rd

4th

& filter replacement)^*2

Chart symbols:

R: Replace

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Follow Maintenance Interval listed in Normal Driving Scheduled Maintenance.

▼ Scheduled Maintenance (Canada)

Vehicles utilizing the vehicle status monitor feature:

The vehicle status monitor feature alerts you of engine oil replacement by turning on

the wrench indicator light or displaying a message in the instrument panel, or both.

Every engine oil replacement must be done when the display/wrench indication

comes on. The display/wrench indication will come on before reaching the maxi-

mum interval of 16,000 km (10,000 miles), or 12 months (after the previous main-

tenance).

If you are following 8,000 km (5,000 miles) or 6 months maintenance interval, set

the vehicle status monitor manually.

Refer to the owner's manual section of mazda.ca for the Mazda Connect owner's

manual or contact an Authorized Mazda Dealer if necessary.

Canada residents

Number of months or kilometers (miles), whichever comes first.

Months

Maintenance Interval

×1000 km

×1000

miles

Replace when the wrench indicator light is ON.

Engine oil & filter^*1*2

(Upper limit interval is 16,000 km (10,000 miles) or 12

months.)

6-6

Maintenance and Care

Scheduled Maintenance

Number of months or kilometers (miles), whichever comes first.

Months

Maintenance Interval

×1000 km

×1000

miles

SKYACTIV-G

Replace every 64,000 km (40,000 miles).

2.5T

Spark plugs

Except SKY-

ACTIV-G

Replace every 120,000 km (75,000 miles).

2.5T

Air filter

Replace every 56,000 km (35,000 miles) or 36 months.

Drive belts^*3

Engine coolant level

Replace at first 192,000 km (120,000 miles) or 120

Engine coolant^*4

months; after that, every 96,000 km (60,000 miles) or 60

months.

Fuel lines & hoses^*5

Hoses and tubes for emission^*5

Brake lines, hoses and connections

Vacuum brake booster and

With vac-

hose

uum booster

With electri-

Brake fluid

cal booster

I/C

Disc brakes

C/L

Tire rotation

Rotate every 8,000 km (5,000 miles).

Tire inflation pressure and tire wear^*6

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

Body condition inspection for rust, corro-

sion and perforation

Driveshaft dust boot

Bolts and nuts on chassis and body

Exhaust system and heat shields

Emergency flat tire repair kit (if equip-

Inspect annually.

ped)^*7

Cabin air filter

Replace every 40,000 km (25,000 miles) or 24 months.

6-7

Maintenance and Care

Scheduled Maintenance

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

R: Replace

C: Clean

L: Lubricate

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

If you drive your vehicle under any of the following conditions, replace the engine oil & filter every

8,000 km (5,000 miles) or 6 months, whichever comes first.

1. The vehicle is idled for long periods or driven at low speeds, such as with police cars, taxis, or

driver's education school vehicles.

2. Driving under dusty conditions.

3. Driving for long periods in cold temperatures or driving regularly for short distances only.

4. Driving under extremely high temperature conditions.

5. Driving continuously in mountainous regions.

^*3

Also inspect the air conditioner drive belts, if equipped.

If the vehicle is operated primarily under any of the following conditions, inspect the drive belts more

often than the recommended intervals.

a) Driving under dusty conditions.

b) The vehicle is idled for long periods or driven at low speeds.

c) Driving for long periods in cold temperatures or driving regularly for short distances only.

d) Driving under extremely high temperature conditions.

e) Driving continuously in mountainous regions.

f) Driving for long period in extremely wet or heavy rain condition.

^*4

Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22

may cause serious damage to the engine and cooling system.

^*5

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*6

Inspect a spare tire if equipped.

^*7

Check the tire repair fluid expiration date every year when performing the periodic maintenance.

Replace the tire repair fluid bottle with a new one before the expiration date.

6-8

Maintenance and Care

Scheduled Maintenance

▼ Scheduled Maintenance (Mexico)

Vehicles utilizing the vehicle status monitor feature:

The vehicle status monitor feature alerts you of maintenance needs by turning on the

wrench indicator light or displaying a message in the instrument panel, or both.

Every maintenance must be done when the display/wrench indication comes on.

The display/wrench indication will come on before reaching the maximum interval

of 10,000 km, or 6 months (after the previous maintenance).

If you drive your vehicle under any of the following conditions, follow the Severe

Driving Scheduled Maintenance and replace the engine oil and filter every 5,000 km

or 3 months, whichever comes first.

Otherwise, follow the Normal Driving Scheduled Maintenance intervals.

1. The vehicle is idled for long periods or driven at low speeds, such as with police

cars, taxis, or driver's education school car.

2. Driving under dusty conditions.

3. Driving for long periods in cold temperatures or driving regularly for short distan-

ces only.

4. Driving under extremely high temperature conditions.

5. Driving continuously in mountainous regions.

If you are following the Severe Driving Scheduled Maintenance (5,000 km or 3

months oil replacement interval), set the vehicle status monitor manually.

Refer to the Information section in the Mazda Connect Owner's Manual. Please

contact an Authorized Mazda Dealer if necessary.

Mexico Residents (Normal Driving Scheduled Maintenance):

Number of times, maintenance was performed.

Maintenance Item

Engine oil & filter^*1

SKYACTIV-G

2.5T

Replace every 64,000 km

Spark plugs

Except SKY-

ACTIV-G

Replace every 120,000 km.

2.5T

Air filter

Drive belts

Engine coolant level

Replace at first 192,000 km or 120 months; after that,

Engine coolant^*2

every 96,000 km or 60 months.

Fuel lines & hoses^*3

Hoses and tubes for emission^*3

Fuel filter

Replace every 60,000 km.

6-9

Maintenance and Care

Scheduled Maintenance

Number of times, maintenance was performed.

Maintenance Item

Brake lines, hoses and connections

Vacuum brake booster and

With vacuum

hose

booster

Brake and clutch fluid level

Brake fluid

Disc brakes

Tire rotation

Rotate every 10,000 km.

Tire inflation pressure and tire wear^*4

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

Driveshaft dust boot

Bolts and nuts on chassis and body

Exhaust system and heat shields

Emergency flat tire repair kit (if equipped)^*5

Inspect annually.

Cabin air filter

Replace every 40,000 km or 24 months.

Function of all lights

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

R: Replace

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22

may cause serious damage to the engine and cooling system.

^*3

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*4

Inspect a spare tire if equipped.

^*5

Check the tire repair fluid expiration date every year when performing the periodic maintenance.

Replace the tire repair fluid bottle with new one before the expiration date.

6-10

Maintenance and Care

Scheduled Maintenance

Mexico Residents (Severe Driving Scheduled Maintenance):

Number of months or kilometers , whichever comes first.

Months

× 1000 km

Engine oil & filter^*1

Maintenance Interval (other than engine oil

1st

2nd

3rd

4th

& filter replacement)^*2

Chart symbols:

R: Replace

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Follow Maintenance Interval listed in Normal Driving Scheduled Maintenance.

6-11

Maintenance and Care

Owner Maintenance

As explained in the Introduction (page

Owner Maintenance

6-2), several procedures can be done

Precautions

only by a qualified service technician

with special tools.

▼ Owner Maintenance Precautions

Improper owner maintenance during

The owner or a qualified service

the warranty period may affect

technician should make these vehicle

warranty coverage. Refer to

inspections at the indicated intervals to

Introduction (page 6-2) for owner's

ensure safe and dependable

responsibility in protecting your

operation.

investment. For details, read the

separate Mazda Warranty statement

Bring any problem to the attention of

provided with the vehicle. If you are

an Authorized Mazda Dealer or

unsure about any servicing or

qualified service technician as soon as

maintenance procedure, have it done

possible.

by an Authorized Mazda Dealer.

When Refueling

There are strict environmental laws

^ Brake and clutch fluid level (page

regarding the disposal of waste oil and

6-21)

fluids. Please dispose of your waste

^ Engine coolant level (page 6-20)

properly and with due regard to the

^ Engine oil level (page 6-19)

environment.

^ Washer fluid level (page 6-22)

At Least Monthly

We recommend that you entrust the oil

and fluid changes of your vehicle to an

^ Tire inflation pressures (page 6-34)

Authorized Mazda Dealer.

At Least Twice a Year (For Example,

Every Spring and Fall)

WARNING

You can do the following scheduled

Do not perform maintenance work if

maintenance items if you have some

you lack sufficient knowledge and

mechanical ability and a few basic

experience or the proper tools and

tools and if you closely follow the

equipment to do the work. Have

directions in this manual.

maintenance work done by a

^ Engine coolant (page 6-20)

qualified technician:

^ Engine oil (page 6-19)

Performing maintenance work on a

vehicle is dangerous if not done

properly. You can be seriously injured

Improper or incomplete service may

while performing some maintenance

result in problems. This section gives

procedures.

instructions only for items that are easy

to perform.

6-12

Maintenance and Care

Owner Maintenance

If you must run the engine while

Hood

working under the hood, make

certain that you remove all jewelry

▼ Hood

(especially rings, bracelets, watches,

and necklaces) and all neckties,

scarves, and similar loose clothing

WARNING

before getting near the engine or

cooling fan which may turn on

Always check that the hood is closed

unexpectedly:

and securely locked:

Working under the hood with the

A hood that is not closed and securely

engine running is dangerous. It

locked is dangerous as it could fly open

becomes even more dangerous when

while the vehicle is moving and block

you wear jewelry, loose clothing or

the driver's vision which could result in

have long hair or a long beard.

a serious accident.

Either can become entangled in

▼ Opening the Hood

moving parts and result in injury.

With the vehicle parked, pull the

release handle to unlock the hood.

Pull over to a safe location, then

switch the ignition off and make sure

the fan is not running before

attempting to work near the cooling

fan:

Working near the cooling fan when it is

running is dangerous. The fan could

continue running indefinitely even if

the engine has stopped and the engine

compartment temperature is high. You

Insert your hand into the hood

could be hit by the fan and seriously

opening, slide the latch lever in the

injured.

direction of the allow as shown in

the illustration, and lift up the

Do not leave items in the engine

hood.

compartment:

After you have finished checking or

doing servicing in the engine

compartment, do not forget and leave

items such as tools or rags in the

engine compartment.

Tools or other items left in the engine

compartment could cause engine

damage or a fire leading to an

unexpected accident.

6-13

Maintenance and Care

Owner Maintenance

3. Grasp the support rod in the

2. Lift the hood, grasp the padded

padded area and secure it in the

area on the support rod, and secure

support rod hole indicated by the

the support rod in the clip. Verify

arrow to hold the hood open.

that the support rod is secured in

the clip before closing the hood.

1. Pad

2. Support rod

▼ Closing the Hood

1. Check under the hood area to

make certain all filler caps are in

1. Clip

place and all loose items (e.g.

tools, oil containers, etc.) have

3. Lower the hood slowly to a height

been removed.

of about 20 cm (7.9 in) above its

closed position and then let it drop.

CAUTION

When closing the hood, do not push it

excessively such as by applying your

weight. Otherwise, the hood could be

deformed.

6-14

Maintenance and Care

Owner Maintenance

Only use SAE 0W-20 oil “Certified For

Engine Oil

Gasoline Engines” by the American

Petroleum Institute (API).

▼ Engine Oil

Oil with this trademark symbol

conforms to the current engine and

NOTE

emission system protection standards

Changing the engine oil should be

and fuel economy requirements of the

performed by an Authorized Mazda

International Lubricant Standardization

Dealer.

and Approval Committee (ILSAC),

Refer to Introduction on page 6-2 for

comprised of U.S. and Japanese

owner's responsibility in protecting

automobile manufacturers.

your investment.

▼ Recommended Oil

U.S.A., Canada

SKYACTIV-G 2.0 and SKYACTIV-G

2.5

Use ILSAC GF-V or higher/ SAE

0W-20 engine oil.

Mazda Genuine Oil is used in your

Mazda vehicle. Mazda Genuine

SKYACTIV-G 2.5T

0W-20 Oil is required to achieve

optimum fuel economy.

Use SAE 5W-30 engine oil.

Mazda Genuine Oil is used in your

For maintenance service, Mazda

Mazda vehicle. Mazda Genuine

recommends Mazda Genuine Parts

5W-30 Oil is required to achieve

and Oil.

optimum fuel economy.

For maintenance service, Mazda

recommends Mazda Genuine Parts

and Oil.

6-17

Maintenance and Care

Owner Maintenance

Only use SAE 5W-30 oil “Certified For

For maintenance service, Mazda

Gasoline Engines” by the American

recommends Mazda Genuine Parts.

Petroleum Institute (API).

Oil with this trademark symbol

conforms to the current engine and

emission system protection standards

and fuel economy requirements of the

International Lubricant Standardization

and Approval Committee (ILSAC),

comprised of U.S. and Japanese

automobile manufacturers.

(Mexico)

SKYACTIV-G 2.0 and SKYACTIV-G

2.5

Use API SM or higher, or ILSAC GF-IV

or higher/SAE 5W-30 engine oil. If SAE

Except U.S.A., Canada

5W-30 engine oil is not available, use

SAE 5W-20 engine oil.

Use SAE 5W-30 engine oil.

Oil container labels provide important

The quality designation SM, or ILSAC

information.

must be on the label.

A chief contribution this type of oil

makes to fuel economy is reducing the

amount of fuel necessary to overcome

engine friction.

SKYACTIV-G 2.5T

Use SAE 5W-30 engine oil. If SAE

5W-30 engine oil is not available, use

SAE 0W-30 or SAE 10W-30 engine oil.

The quality designation SM or SN, or

ILSAC must be on the label.

6-18

Maintenance and Care

Owner Maintenance

▼ Inspecting Engine Oil Level

5. Pull it out again and examine the

level.

NOTE

The level is normal if it is between

the MIN and MAX marks.

^ If the engine oil level warning

If it is near or below MIN, add

indication/warning light turns on,

enough oil to bring the level to

add 1 L (0.26 US gal, 0.22 Imp gal)

MAX.

of engine oil.

1. Be sure the vehicle is on a level

CAUTION

surface.

Do not overfill the engine oil. This

2. Warm up the engine to normal

may cause engine damage.

operating temperature.

6. Make sure the O-ring on the

3. Turn it off and wait at least 5

dipstick is positioned properly

minutes for the oil to return to the

before reinserting the dipstick.

oil pan.

7. Reinsert the dipstick fully.

4. Pull out the dipstick, wipe it clean,

and reinsert it fully.

1. MAX

2. OK

3. MIN

6-19

Maintenance and Care

Owner Maintenance

NOTE

Engine Coolant

Changing the coolant should be done

by an Authorized Mazda Dealer.

▼ Inspecting Coolant Level

Inspect the antifreeze protection and

coolant level in the coolant reservoir at

WARNING

least once a year―at the beginning of

the winter season―and before

Do not use a match or live flame in

traveling where temperatures may drop

the engine compartment. DO NOT

below freezing.

ADD COOLANT WHEN THE ENGINE

IS HOT:

Inspect the condition and connections

A hot engine is dangerous. If the

of all cooling system and heater hoses.

engine has been running, parts of the

Replace any that are swollen or

engine compartment can become very

deteriorated.

hot. You could be burned. Carefully

inspect the engine coolant in the

The coolant should be at full in the

coolant reservoir, but do not open it.

radiator and between the FULL and

LOW marks on the coolant reservoir

when the engine is cool.

SKYACTIV-G 2.0 and SKYACTIV-G

Pull over to a safe location, then

2.5

switch the ignition off and make sure

the fan is not running before

attempting to work near the cooling

fan:

Working near the cooling fan when it is

running is dangerous. The fan could

continue running indefinitely even if

the engine has stopped and the engine

compartment temperature is high. You

could be hit by the fan and seriously

injured.

Do not remove either

cooling system cap when the engine

and radiator are hot:

When the engine and radiator are hot,

scalding coolant and steam may shoot

out under pressure and cause serious

injury.

6-20

Maintenance and Care

Owner Maintenance

SKYACTIV-G 2.5T

Brake/Clutch Fluid

▼ Inspecting Brake/Clutch Fluid

Level

WARNING

If the brake/clutch fluid level is low,

have the brakes inspected:

A low brake/clutch fluid level is

dangerous.

A low level could indicate brake lining

wear or a brake system leak which

could cause the brakes to fail and lead

If it is at or near LOW, add enough

to an accident.

coolant to the coolant reservoir to

provide freezing and corrosion

The brakes and clutch draw fluid from

protection and to bring the level to

the same reservoir.

FULL.

Inspect the fluid level in the reservoir

Securely tighten the coolant reservoir

regularly. It should be kept between

tank cap after adding coolant.

the MAX and MIN lines.

The level normally drops with

CAUTION

accumulated distance, a condition

associated with wear of brake and

¾ Radiator coolant will damage paint.

clutch linings. If it is excessively low,

Rinse it off quickly if spilled.

have the brake/clutch system

¾ If the “FL22” mark is shown on or

inspected by an Authorized Mazda

near the cooling system cap, use of

Dealer.

FL-22 is recommended when

replacing engine coolant. Using

engine coolant other than FL-22 may

cause serious damage to the engine

and cooling system.

If the coolant reservoir is empty or new

coolant is required frequently, consult

an Authorized Mazda Dealer.

6-21

Maintenance and Care

Owner Maintenance

Inspect fluid level in the washer fluid

Washer Fluid

reservoir; add fluid if necessary.

▼ Inspecting Washer Fluid Level

WARNING

Use only windshield washer fluid or

plain water in the reservoir:

Using radiator antifreeze as washer

fluid is dangerous. If sprayed on the

windshield, it will dirty the windshield,

affect your visibility, and could result in

an accident.

The top of the float should be between

Using Washer Fluid Without

F and E.

Anti-freeze Protection in Cold

Weather:

Use plain water if washer fluid is

Operating your vehicle in temperatures

unavailable.

below 4 °C (40 °F) using washer fluid

But use only washer fluid in cold

without anti-freeze protection is

weather to prevent it from freezing.

dangerous as it could cause impaired

windshield vision and result in an

NOTE

Front and rear washer fluid is supplied

accident. In cold weather, always use

washer fluid with anti-freeze

from the same reservoir.

protection.

NOTE

State or local regulations may restrict

the use of volatile organic compounds

(VOCs), which are commonly used as

anti-freeze agents in washer fluid. A

washer fluid with limited VOC content

should be used only if it provides

adequate freeze resistance for all

regions and climates in which the

vehicle will be operated.

6-22

Maintenance and Care

Owner Maintenance

Body Lubrication

Wiper Blades

▼ Body Lubrication

▼ Wiper Blades

All moving points of the body, such as

door and hood hinges and locks,

CAUTION

should be lubricated each time the

¾ Hot waxes applied by automatic car

engine oil is changed. Use a

washers have been known to affect

nonfreezing lubricant on locks during

the wiper's ability to clean windows.

cold weather.

¾ To prevent damage to the wiper

blades, do not use gasoline,

Make sure the hood's secondary latch

kerosene, paint thinner, or other

keeps the hood from opening when

solvents on or near them.

the primary latch is released.

¾ When the wiper lever is in the AUTO

position and the ignition is switched

ON, the wipers may move

automatically in the following cases:

¾ If the windshield above the rain

sensor is touched.

¾ If the windshield above the rain

sensor is wiped with a cloth.

¾ If the windshield is struck with a

hand or other object.

¾ If the rain sensor is struck with a

hand or other object from inside

the vehicle.

Be careful not to pinch hands or

fingers as it may cause injury, or

damage the wipers. When washing

or servicing the vehicle, make sure

the wiper lever is in the OFF

position.

6-23

Maintenance and Care

Owner Maintenance

¾ Before lifting the windshield wiper

▼

Replacing Windshield Wiper

blades off the windshield, always

Blades

follow the procedure for moving the

When the wipers no longer clean well,

windshield wiper blades. Otherwise,

the blades are probably worn or

a wiper blade, wiper arm, or the

cracked.

hood could be damaged.

Replace them.

Refer to the Replacing Windshield

Wiper Blades (page 6-24) section

CAUTION

for the procedure on how to move

the windshield wiper blades to the

¾ To prevent damaging a windshield

service position.

wiper blade, wiper arm, or the hood,

perform the following procedure.

Contamination of either the

windshield or the blades with foreign

¾ Before lifting the windshield wiper

matter can reduce wiper effectiveness.

blades off the windshield, always

Common sources are insects, tree sap,

move them to the service position.

and hot wax treatments used by some

¾ When putting the windshield

commercial car washes.

wiper blades back on the

windshield, make sure that they

If the blades are not wiping properly,

are in the service position before

clean the window and blades with a

switching the ignition ON and

good cleaner or mild detergent; then

operating the windshield wipers.

rinse thoroughly with clean water.

¾ Replace with Mazda genuine wiper

Repeat if necessary.

blades. If they are replaced with

wiper blades other than a Mazda

genuine product, they may not wipe

with the same efficiency as the

genuine product.

¾ To prevent damage to the wiper

arms and other components, do not

try to sweep the wiper arm by hand.

¾ Do not bend the blade rubber

unnecessarily when replacing it.

Otherwise, the metal stiffener in the

blade may deform and the

windshield wiper operation may be

adversely affected.

¾ Do not hold a wiper blade by its end

when raising the wiper arm.

Otherwise, the part may deform and

the wiping performance may lower.

6-24

Maintenance and Care

Owner Maintenance

NOTE

Slide the blade component in the

direction of the arrow while

^ You can replace the wiper blades

pressing the wiper arm tab to

yourself, however you cannot replace

remove the blade component from

the wiper arms.

the wiper arm.

If you want to replace the wiper

arms, consult an Authorized Mazda

Dealer.

^ Forcefully lowering the wiper arms

could damage the wiper arm and

blade, and may scratch or crack the

windshield.

Replace the wiper blades using the

following procedure.

1. Move the wipers to the service

positions using the following

procedure.

a) Switch the ignition ON.

Pull the blade rubber in the

b) Switch the ignition OFF.

direction of the arrow and slide it

c) Press up the wiper switch to the

to a position where the blade

MIST position 2 times within 30

holder groove can be checked.

seconds after switching the

ignition OFF.

When the procedure is

completed, the wipers operate

and they stop at the service

positions.

2. Raise the wiper arms.

CAUTION

To prevent damage to the

windshield let the wiper arm down

easily, do not let it slap down on

the windshield.

6-25

Maintenance and Care

Owner Maintenance

After pulling the blade rubber in the

11.Move the wipers to their initial

direction of the arrow and sliding

positions using the following

the blade rubber to a position to

procedure.

check the blade holder groove,

a) Make sure that the wipers are set

slide the blade rubber end in the

on the windshield.

opposite direction.

b) Switch the ignition ON.

c) Press up the wiper switch to the

MIST position 1 time.

When the procedure is

completed, the wipers operate

and they stop at the initial

positions.

▼ Replacing Rear Window Wiper

Blade (5-Door)

When the wiper no longer cleans well,

the blade is probably worn or cracked.

Replace it.

CAUTION

To prevent damage to the wiper arm

and other components, do not move

the wiper by hand.

1. Remove the cover.

Make sure that the blade rubber is

correctly installed to the blade

holder.

Slide the blade component and

install it to the wiper arm.

10.Slowly lower the wiper arms onto

the windshield.

6-27

Maintenance and Care

Owner Maintenance

2. Remove the stopper and raise the

4. Pull down the blade rubber and

wiper arm.

slide it out of the blade holder.

5. Remove the metal stiffeners from

3. Firmly rotate the wiper blade to the

the blade rubber and install them in

right until it unlocks, then remove

the new blade.

the blade.

CAUTION

Do not bend or discard the

stiffeners. You need to use them

CAUTION

again.

To prevent damage to the rear

6. Carefully insert the new blade

window, do not let the wiper arm

rubber.

fall on it.

Then install the blade assembly in

the reverse order of removal.

6-28

Maintenance and Care

Owner Maintenance

Battery

Wear eye protection and

▼ Battery

protective gloves to prevent contact

with battery fluid:

WARNING

Spilled battery fluid is dangerous.

Battery fluid contains SULFURIC ACID

Wash hands after handling the battery

which could cause serious injuries if it

and related accessories:

gets in eyes, or on the skin or clothing.

Battery posts, terminals and related

If this happens, immediately flush your

accessories contain lead and lead

eyes with water for 15 minutes or wash

compounds, chemicals known to the

your skin thoroughly and get medical

State of California to cause cancer and

attention.

reproductive harm.

Always keep batteries out of

Read the following precautions

the reach of children:

carefully before using the battery or

Allowing children to play near batteries

inspecting to ensure safe and correct

is dangerous. Battery fluid could cause

handling:

serious injuries if it gets in the eyes or

on the skin.

Always wear eye protection

when working near the battery:

Keep flames and sparks away

Working without eye protection is

from open battery cells and do not

dangerous. Battery fluid contains

allow metal tools to contact the

SULFURIC ACID which could cause

positive (+) or negative (-) terminal of

blindness if splashed into your eyes.

the battery when working near a

Also, hydrogen gas produced during

battery. Do not allow the positive (+)

normal battery operation, could ignite

terminal to contact the vehicle body:

and cause the battery to explode.

Flames and sparks near open battery

cells are dangerous. Hydrogen gas,

produced during normal battery

operation, could ignite and cause the

battery to explode. An exploding

battery can cause serious burns and

injuries. Keep all flames including

cigarettes and sparks away from open

battery cells.

6-29

Maintenance and Care

Owner Maintenance

▼ Battery Maintenance

Keep all flames and sparks

away from open battery cells because

hydrogen gas is produced from open

battery cells while charging the

battery or adding battery fluid:

Flames and sparks near open battery

cells are dangerous. Hydrogen gas,

produced during normal battery

operation, could ignite and cause the

battery to explode. An exploding

battery can cause serious burns and

To get the best service from a battery:

injuries. Keep all flames including

cigarettes and sparks away from open

^ Keep it securely mounted.

battery cells.

^ Keep the top clean and dry.

^ Keep terminals and connections

NOTE

clean, tight, and coated with

Before performing battery

petroleum jelly or terminal grease.

maintenance, remove the battery

^ Rinse off spilled electrolyte

cover.

immediately with a solution of water

and baking soda.

^ If the vehicle will not be used for an

extended time, disconnect the

battery cables and charge the battery

every 6 weeks.

▼ Battery Replacement

Contact an Authorized Mazda Dealer

for battery replacement.

6-30

Maintenance and Care

Owner Maintenance

The following conditions indicate that

Key Battery Replacement

the battery power is low:

▼ Key Battery Replacement

^ A message, “Low Key Fob Battery.

Replace Battery” is displayed on the

If the buttons on the transmitter are

multi-information display when the

inoperable and the operation indicator

ignition is switched OFF.

light does not flash, the battery may be

^ The system does not operate and the

dead.

operation indicator light on the

Replace with a new battery before the

transmitter does not flash when the

transmitter becomes unusable.

buttons are pressed.

^ The system's operational range is

CAUTION

reduced.

¾ Make sure the battery is installed

Incorrect battery replacement

correctly. Battery leakage could occur

operation may damage the key.

if it is not installed correctly.

Replacing the battery at an Authorized

¾ When replacing the battery, be

Mazda Dealer is recommended. If

careful not to touch any of the

replacing the battery by yourself,

internal circuitry and electrical

follow the instruction.

terminals, bend the electrical

terminals, or get dirt in the

Replacing the key battery

transmitter as the transmitter could

1. Remove the lower cover while

be damaged.

pressing the knob in the direction

¾ There is the danger of explosion if

of the arrow.

the battery is not correctly replaced.

¾ Dispose of used batteries according

to the following instructions.

¾ Insulate the plus and minus

terminals of the battery using

cellophane or equivalent tape.

¾ Never disassemble.

¾ Never throw the battery into fire or

water.

¾ Never deform or crush.

¾ Replace only with the same type

battery (CR2032 or equivalent).

6-31

Maintenance and Care

Owner Maintenance

2. Press in the tab to unlock the upper

5. Remove the cap using the

cover.

tape-wrapped flathead screwdriver.

6. Remove the battery using

tape-wrapped flathead screwdriver.

3. Insert a tape-wrapped flathead

screwdriver into the gap and slide it

in the direction of the arrow.

4. Twist the flathead screwdriver in the

7. Insert a new battery into the

direction of the arrow and remove

transmitter so that the positive pole

the upper cover.

is facing up.

8. Install the cap.

6-32

Maintenance and Care

Owner Maintenance

9. Install the upper cover.

Tires

▼ Tires

For reasons of proper performance,

safety, and better fuel economy, always

maintain recommended tire inflation

pressures and stay within the

recommended load limits and weight

distribution.

WARNING

10.Insert the tabs of the lower cover

into the slots of the transmitter and

install the lower cover.

Using Different Tire Types:

Driving your vehicle with different

types of tires is dangerous. It could

cause poor handling and poor braking;

leading to loss of control.

Except for the limited use of the

temporary spare tire, use only the

same type tires (radial, bias-belted,

bias-type) on all four wheels.

Using Wrong-Sized Tires:

Using any other tire size than what is

specified for the vehicle (page 9-10)

is dangerous. It could seriously affect

ride, handling, ground clearance, tire

clearance, and speedometer

calibration. This could cause you to

have an accident. Use only tires that

are the correct size specified for the

vehicle.

6-33

Maintenance and Care

Owner Maintenance

▼ Tire Inflation Pressure

^ Overinflation can produce a harsh

ride, uneven and accelerated tire

wear, and a greater possibility of

WARNING

damage from road hazards.

Keep your tire pressure at the correct

Always inflate the tires to the correct

levels. If one frequently needs

pressure:

inflating, have it inspected.

Overinflation or underinflation of tires

is dangerous. Adverse handling or

▼ Tire Rotation

unexpected tire failure could result in a

serious accident.

WARNING

Refer to Tires on page 9-10.

Rotate tires periodically:

Use only a Mazda-genuine tire valve

Irregular tire wear is dangerous. To

cap:

equalize tread wear for maintaining

Use of a non-genuine part is

good performance in handling and

dangerous as the correct tire air

braking, rotate the tires periodically or

pressure cannot be maintained if the

sooner if irregular wear develops.

tire valve becomes damaged. If the

Please refer to Scheduled maintenance

vehicle is driven under this condition,

for your tire rotation interval.

the tire air pressure will decrease

which could result in a serious

During rotation, inspect them for

accident. Do not use any part for the

correct balance.

tire valve cap that is not a

Mazda-genuine part.

Inspect all tire pressures monthly

(including the spare) when the tires are

cold. Maintain recommended

pressures for the best ride, handling,

and minimum tire wear.

Refer to the specification charts (page

9-10).

NOTE

1. Forward

^ Always check tire pressure when tires

Do not include (TEMPORARY USE

are cold.

ONLY) spare tire in rotation.

^ Warm tires normally exceed

recommended pressures. Do not

release air from warm tires to adjust

the pressure.

^ Underinflation can cause reduced

fuel economy, uneven and

accelerated tire wear, and poor

sealing of the tire bead, which will

deform the wheel and cause

separation of tire from rim.

6-34

Maintenance and Care

Owner Maintenance

Also, inspect them for uneven wear

▼ Replacing a Tire

and damage. Abnormal wear is usually

caused by one or a combination of the

WARNING

following:

^ Incorrect tire pressure

Always use tires that are in good

^ Improper wheel alignment

condition:

^ Out-of-balance wheel

Driving with worn tires is dangerous.

^ Severe braking

Reduced braking, steering, and

traction could result in an accident.

After rotation, inflate all tire pressures

Replace all four tires at the same

to specification on page 9-10 and

inspect the lug nuts for tightness.

time:

Replacing just one tire is dangerous. It

CAUTION

could cause poor handling and poor

braking resulting in loss of vehicle

Rotate unidirectional tires and radial

control. Mazda strongly recommends

tires that have an asymmetrical tread

that you replace all four tires at the

pattern or studs only from front to rear,

same time.

not from side to side. Tire performance

If a tire wears evenly, a wear indicator

will be reduced if rotated from side to

will appear as a solid band across the

side.

tread.

Replace the tire when this happens.

1. New tread

2. Worn tread

3. Tread wear indicator

You should replace the tire before the

band crosses the entire tread.

6-35

Mazda 3 Hatchback (2021 year). Manual in english - page 15
